6x8cm Hole Seawall Protection Pvc Coated Hexagonal Gabion Basket

6x8cm Hole Seawall Protection Pvc Coated Hexagonal Gabion Basket
6x8cm Hole Seawall Protection Pvc Coated Hexagonal Gabion Basket 6x8cm Hole Seawall Protection Pvc Coated Hexagonal Gabion Basket 6x8cm Hole Seawall Protection Pvc Coated Hexagonal Gabion Basket

Large Image :  6x8cm Hole Seawall Protection Pvc Coated Hexagonal Gabion Basket

Product Details:
Place of Origin: Hebei, China
Brand Name: SHUXIN
Certification: CE, SGS
Model Number: SX-GB01
Payment & Shipping Terms:
Minimum Order Quantity: 1000 square meter
Price: Negotiated
Packaging Details: pallet
Delivery Time: 15 work days
Payment Terms: T/T, Western Union
Supply Ability: Daily output: 30,000 square meters

6x8cm Hole Seawall Protection Pvc Coated Hexagonal Gabion Basket

Description
Material: Galvanized Wire Technique: Twisted Weaving
Wire Diameter: 2.0-4.00mm Hole Size: 6x8cm,8x10cm,10x12cm
Surface Treatment: PVC Coated, Hot Dipped Galvanized Cage Size: 1*1*1m, 2*1*1m, 3*1*1m
High Light:

6x8cm hole pvc coated gabion baskets

,

seawall protection hexagonal gabion basket

,

pvc coated hexagonal gabion basket

Seawall protection hexagonal gabion baskets mesh box PVC coated gabion basket for sale





Product Description



Gabion basket, also known as gabion box and gabion net, is a new type of ecological grid structure. It has been successfully applied to water conservancy projects, highways, railway projects and dike protection projects, and has well realized the organic combination of engineering structure and ecological environment. At the same time, compared with the traditional rigid structure, it has its own advantages and has become the preferred structural form for riverbed, landslide, debris flow, rockfall protection and environmental protection worldwide.



The gabion basket is made of twisted hexagonal woven mesh. The metal wire used to make gabion baskets is made of soft tensile heavy galvanized steel, and PVC coating can also be used for additional corrosion protection when the application requires. The double twisting of the woven wire mesh provides structural integrity, strength and continuity by increasing the non-loosening effect of preventing any accidental damage from spreading. Fastening wires are used to assemble and interconnect empty units and to close and fix stone filling units. Once assembled, the basket will be filled with stones at the scene.



Specification



Material Galvanized low carbon steel wire
Wire diameter Mesh wire:2.0mm-4.0mm
  Selvedge wire:3.4mm, 3.8mm
  Lacing wire:2.2mm, 2.5mm
Mesh size 60*80mm, 80*100mm, 100*120mm
Gabion size 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 6*2*0.3m
Surface treatment HD galvanized, PVC coated
Characteristics Easy to install, rust prevention, corrosion prevention, low cost, high safety and less goods to be transported.
Usage Water or flood control and guidance, prevention of rock breakage, coastal area protection projects, road protection.river gabion protection project
Packaging Packed in bundles or pallets or according to customer's requirements.




Feature

1. High versatility: Gabion Wall Cages can be stacked to create a retaining wall with vertical, sloping or stepped front face based on the requirements of your project. Meanwhile, woven gabion baskets can be mounted combining various plants for enhanced strength and more pleasing appearance.



2. Long lifespan: All of our Gabion Wall Cages are heavily galvanized, Zn-Al alloy plated with optional PVC coating to resistant against corrosion and maximum their lifespan. Normally, our galfan gabion and PVC gabion can last up to 120 years based on different exposure conditions.



3. Robust and flexible structure: woven gabion baskets have robust and flexible structure which enable them to prevent unraveling effectively and withstand forced from water and earth masses.



4. Good ductility, no structural joints.



Advantages



1. High Quality Material
2. Excellent permeability.
3. Good corrosion and rust resistance.
4. High tensile strength.
5. Good durability and long lifespan.

6. Adcanced Technique

7. Strict Quanlity Testing



Application



Gabion Baskets are also used for erosion control for bank stabilization, channel linings, and weirs. Their strength lies in their double twisted hexagonal mesh of steel wire which is reinforced by selvedges of heavier wire running along the edges and by transverse diaphragms. The wire will not unravel even when cut. Assembly is easy, requiring no specialized labour and they are easy to install.



They are ideal for any situation where a retaining structure is required which is also aesthetically pleasing and environmentally friendly. Since Gabion baskets are permeable, they integrate and adapt in harmony with their surroundings, allowing environmental growth and preservation.



6x8cm Hole Seawall Protection Pvc Coated Hexagonal Gabion Basket 0
