Mil Series Military Barrier Sand Wall Security Hesco Bastion For Army

Certification
Good quality Military Barrier for sales
Good quality Military Barrier for sales
Product received on time. Product quality is good. costumer service is very accommodating. hassle free transaction. will not hesitate to order again next time.

—— Ventas

The quality is reliable! Thanks.Product received on time.

—— Buena

Great Seller!!!!! Working with you is very reassuring, don't worry about any quality problems.

—— Peter

I have been very happy and trustworthy suppliers for many years.

—— Sworld

I'm Online Chat Now

Mil Series Military Barrier Sand Wall Security Hesco Bastion For Army

China Mil Series Military Barrier Sand Wall Security Hesco Bastion For Army supplier
Mil Series Military Barrier Sand Wall Security Hesco Bastion For Army supplier Mil Series Military Barrier Sand Wall Security Hesco Bastion For Army supplier

Large Image :  Mil Series Military Barrier Sand Wall Security Hesco Bastion For Army

Product Details:

Place of Origin: CN
Brand Name: SHUXIN
Certification: COC ISO PVOC
Model Number: SX-mil 1

Payment & Shipping Terms:

Minimum Order Quantity: 100 Sets
Price: Negotiated
Packaging Details: Pallet
Delivery Time: 20 Working Days
Payment Terms: L/C, , T/T, Western Union, MoneyGram, Paypal
Supply Ability: 100 sets per 1 day
Contact Now
Detailed Product Description
Material: HDP Galvanized Wire Wire Diamenter: 5.0mm/4.0mm
Hole Size: 3"*3" Sureface Treatment: Hot Dipped Galvanized
Application: Army Military And River Pretection Geotextile: 300gsm Sand Color
Spring: 4.0mm Color: Green, Brown

HESCO MIL Series Military Sand Wall Security Hesco Bastion For Army

As its name indicated, at the beginning, HESCO Barriers mainly used on Military, for Army Protection,military fortifications, Anti-Explosion Wall and etc.It is made of Collapsible Welded Gabion Mesh and UV Protection Heavy Geotextile lined, The common Surface Treatment is Hot Dipped Galvanized before welding, HDP Galvanized after welding, and Galfan Coated. Both of them have a long using life. It has seen considerable use in Iraq, Afghanistan and Africa.

The Dimension / Specification for Military HESCO Barrier:


Product Name

Hesco Barrier

Product Type

Welded Mesh

Material

Galvanized Steel Wire or Galfan/zinc-5% Aluminum Wire

Wire Diameter

4.0, 5.0mm, Spring Wire Diameter: 4mm

Geotextile

250g-400g

Geotextile colour

Sand clolor, Brown, Gray,and Military Green.

Mesh hole

76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm












  Brief Introduction for Usage method:

1. Usually the HESCO Barriers packed in Pallet and 5 cells per set,After getting it, make it stand.
2. To Pull them, make them opened and in a line to achieve the length you want, If more cells use Joint Pin
3. Full Fill the sand and earth in it and compaction
4. If you want more High and Wide of it, You can stack the HESCO Barrier on each other.

History of development for Military HESCO Bastion in Shuxin Factory:

1. We found HESCO Barrier in the early 2008, and the first cooperated Company is Located In Guangzhou,China, One trading company. They found the HESCO Barrier for Afghanistan Army.From that on, We knew more and Special on it.

2. In order to supply high quality HESCO Barrier to our customers (Because It involves security issues), We Buy the most advanced Equipment for it, from now on, We do not have quality problem any all.

3. As the development of HESCO Barrier, It has a lot of usage, not only for Military, also for Flood and homemade protection. So we have more and more orders about it, Most of them for big tender and project.

The Size Sheet for Military HESCO Barrier:


MODELHeightWidthLengthNO. of Cells
SX-14'6"(1.37M)3'6"(1.06M)32'(10M)9 cells(1*4, 1*5)
SX-27'(2.1M)3'6"(1.06M)108'(33M)30 cells(6*5)
SX-32'(0.61M)2'(0.61M)4'(1.21M)2 cells
SX-43'3"(1.0M)3'3"(1.0M)32'(10M)10 cells(2*5)
SX-52'(0.61M)2'(0.61M)10'(3.05M)5 cells
SX-65'6"(1.68M)2'(0.61M)10'(3.05M)5 cells
SX-77'3"(2.21M)7'(2.13M)90'(27.74M)13 cells(2*4,1*5)
SX-84'6"(1.37M)4'(1.22M)32'(10M)9 cells(1*4, 1*5)
SX-93'3"(1.0M)2'6"(0.76M)30'(9.14M)12 cells(2*6)
SX-107'(2.12M)5'(1.52M)95'(30.5M)20 cells(4*5)
SX-113'3"(1.0M3'3"(1.0M)3'3"(1.0M)1 Cell
SX-127'3"(2.21M)7'3"(2.21M)7'3"(2.21M)1 Cell


The Detailed Explanation of Application for HESCO Barrier:

1. Military Fortifications

Most Army Used HESCO Barrier build up a Military Fortifications, Because it can stack on each other, You can change the width and height by your demands. More easy and flexible.

2. Shooting Range

Nowadays, A lot of people use HESCO Barrier to build a shooting range, because its High Strength Defense, more safety.

3. Flood Control

We Mentioned above, The HESCO Barrier is more and more popular and Homemade. Most Countries Near the coastline choose the HESCO Barrier as Flood Protection Wall.Even around the hotel they stand up the HESCO Barrier for Protection Wall.

The Advantages for HESCO Barrier:

1. Collapsible

It is assembled by Panel and Spring Wire, When Loading and transportation, It is Foldable into one piece.

2. Anti-Corrosion

The Raw material is Hot Dipped Galvanized Wire, it can use 10 years even more longer, fit for outside protection.

3. Easy Installation

After getting it, Just put it in the right place and open it, Full filled the sand and earth is okay. Even 2-3 persons can finish it.

4. Quick Displacements

When you want to use it in another place,Just to move it, It can use many times

5. Easy to repair

If some part is destroyed, Just left it and connect the new one is okay.


SHUXIN company had been produce welded wire mesh products hesco barriers more than 15 years.
our products been supplied many countries's department of defense. and army force.

such as UAE Jordan, USA,Greece,Saudi Aria, Dubai,Kenya ....

and our factory had been verified onsite by world-leading inspection company SGS Group.
we have CE ISO certification. and we have confidence to become your stable and believable supplier in China.
Welcome inquiry for us about hesco barriers.Mil Series Military Barrier Sand Wall Security Hesco Bastion For Army
