Product Details:
|
| Certification: | IOS9001 | Material: | Hot-Dip Gal. Wire Or Galfan Wire & Geotextiel |
|---|---|---|---|
| Welded Mesh Panel: | 4.0/5.0 X (3"X3") | Application: | Military Defence, Flood Barrier Etc |
| Mesh Size: | 50 X 50 Mm, 3''X3'' | Panel Size: | Can Be Customized |
| Color: | Earth Yellow, Military Green | Style: | Mil1- Mil10 |
| High Light: | flood control military barrier,heavy duty military barrier,mil 10 hesco military |
||
Flood Control Military Barrier Heavy Duty Defensive Hesco Barriers Mil 10 Military
Hot Dipped Galvanized Gabion Box with Geotextile is also named as bastion, defense wall,Sand Cage, Welded Gabion box, etc. It is a prefabricated, multi-cellular system,
made of Galvanized welded mesh and lined with non-woven geotextile. Units can be extended and joined using the provided joining pins. It is easy installed with using minimal manpower and commonly available equipment. After extended, it is filled into sand,stone,then Welded Gabion barrier like a defence wall or bunker,it is widely used for military fortification and flood control.Accessories Supplied With Carrier Units.
| Military Barrier | |||||
| Type | Height | Width | Length | Cell | Colour |
| SX-1 | 1.37m | 1.06m | 10.0m | 9 | Sand color, Military Green |
| SX-2 | 0.61m | 0.61m | 1.22m | 2 | Sand color, Military Green |
| SX-3 | 1.0m | 1.0m | 10.0m | 10 | Sand color, Military Green |
| SX-4 | 1.0m | 1.5m | 10.0m | 6 | Sand color, Military Green |
| SX-5 | 0.61m | 0.61m | 3.05m | 5 | Sand color, Military Green |
| SX-6 | 0.61m | 0.61m | 6.10m | 10 | Sand color, Military Green |
| SX-7 | 2.21m | 2.13m | 8.52m | 4 | Sand color, Military Green |
| SX-8 | 1.37m | 1.22m | 10.0m | 9 | Sand color, Military Green |
| SX-9 | 1.0m | 0.76m | 9.14m | 9 | Sand color, Military Green |
| SX-10 | 2.13m | 1.52m | 7.62m | 5 | Sand color, Military Green |
The Dimension / Specification for Military Barrier:
| Wire Diameter: | 5.0mm (Standard), 4.0mm |
| Mesh Hole: | 76.2*76.2mm (Standard), 80*80mm |
| Diameter of Spring: | 4.0mm |
| Diameter of Joint Pin: | 4.0mm |
| Cells per Set: | 1 cell, 2 cells, 3 cells, 4 cells, 5 cells |
| Color of Geotextile: | Military Green, Beige, Brown, Sand Color |
| Weight of Geotextile: | 300GSM (Standard) |
Mesh gabion box Application:
Perimeter Security and Defence Walls
Equipment Revetments
Personnel and Material Bunkers
Observation Points
Defensive Firing Positions
Explosives and Contraband Search Areas
Highway Checkpoints
Border Crossing Checkpoints
Protecting Existing Structures
Flood control retaining wall
Coastal Erosion
Protection engineering of seaside area.
The Advantages for Barrier:
1. Collapsible
It is assembled by Panel and Spring Wire, When Loading and transportation, It is Foldable into one piece.
2. Anti-Corrosion
The Raw material is Hot Dipped Galvanized Wire, it can use 10 years even more longer, fit for outside protection.
3. Easy Installation
After getting it, Just put it in the right place and open it, Full filled the sand and earth is okay. Even 2-3 persons can finish it.
4. Quick Displacements
When you want to use it in another place,Just to move it, It can use many times
5. Easy to repair
If some part is destroyed, Just left it and connect the new one is okay.
