Product Details:
|
| Brand Name: | Shuxin | Delivery Time: | 7 Days |
|---|---|---|---|
| Material: | Q195,Q235 | Surface Treatment: | Hot Dipped Galvanized, PVC Coated |
| Application: | Tender Project | Advantages: | High Tensile Strength |
| Cage Size: | 1*1*1M, 1*1*2M,1*1*3M | Mesh Hole: | 7*9cm,6*8cm,8*10cm,10*12cm |
| Product Name: | 2x1x0.5m Hot Dip Galvanized Rock Basket | Selvedge Wire: | 3.4mm, 4.4 Mm |
| High Light: | 2.7mm gabion boxes,2x1x1m gabion boxes,zinc coating box gabion |
||
Galvanized Gabion 2x1x1 PVC Coated Gabion Basket 80×100mm mesh hole Gabion Boxes with 275 GSM Zinc Coating
Gabion box materials: Hot dipped galvanized wire and PVC coated galvanized wire, Galfan coated wire
Gabion box mesh wire: 2.0mm, 2.2mm, 2.7mm, 3.05mm, etc
Gabion box selvedge wire: 2.4mm, 2.7mm, 3.4mm, 3.8mm, etc
Gabion box mesh size: 6*8cm, 8*10cm, 10*12cm, etc
Gabion box lacing wire: 2.2mm, 5% of gabion weight
Gabion box zinc coating: 225, 245, 275g/m2, according to EN10224-2
Gabion box size: 1*1*1m, 2*1*0.5m, 2*1*1m, 3*1*1m, 4*2*0.3m, 6*2*0.3m,etc
Gabion box steel according to EN 102182, Tensile strength between 380N/mm2 and 500N/mm2
Quick View of Gabions Woven Wire Mesh Box Retaining Walls :
| Product Name | Gabion Wire Mesh Box Cage |
| Material | Low Carbon Steel Wire, Q195,Q235 |
| Process | Weave By Machine |
| Usage | Slope support, foundation pit support |
| Features | High corrosion resistance, high strength, ductility |
| Tensile Strength | 38kg/m2 |
The gabion basket offers an easy way to build a strong retaining wall wherever you need to keep out the wind, precipitation, etc. It doubles as a gabion planter, presenting a convenient way of creating a strong yet stylish raised vegetable, flower or plant bed in your garden.
This stable and durable gabion basket is made of rustproof and weather-resistant galvanized steel.
Specification Sheet of Gabions Woven Wire Mesh Box Retaining Walls :
| Wire Diameter | Mesh Hole | Size of Box Cage |
| 2.0mm-4.0mm | 60 * 80 mm |
2M * 1M * 1M 3M * 1M * 1M 4M * 1M * 1M 2M * 1M * 0.5M 4M * 1M * 0.5M |
| 80 * 100 mm | ||
| 80 * 120 mm | ||
| 100 *120 mm | ||
| 120 * 150mm | ||
| 90 * 110 mm | ||
| Surface Treatment: Galvanized, Hot Dipped Galvanized,Galfan Coated, PVC Coated | ||
PS: People often use Hot Dipped Galvanized, Or Galfan Coated Gabion Wire Mesh, The using life can be 20 years, it is more suitable.
Application:
Foldable Stone Filled Woven Gabion Wire Mesh Mainly used for river, bank slope, road slope slope protection structure. It can not only prevent riverbank from making water flow and storm and wave, but also achieve the natural convection and exchange function between water bodies and the soil beneath the slope to achieve ecological balance.
Advantages:
