Product Details:
|
| Material: | Q235 | Width: | 1000-1800 Mm |
|---|---|---|---|
| Height: | 1000-2000 Mm | Surface Treatment: | Powder Coating |
| Color: | Blue, Red, Orange | Weight Capacity: | 1000-2500 Kg |
| Collapsible: | Yes | OEM/ODM: | Available |
| High Light: | stackable pallet racks,pallet storage racks |
||
Powder Coated Collapsible Stackable Steel Tire Storage Stacking Rack
Product Description
Stacking rack / Pallet is also called movable rack. Stationary type rack is made of formed steel which is stable and durable.Detachable type rack is made up with bottom and four upright posts. The bottom is made of formed steel and the upright post if made of square steel.
Steel Stacking Racks are collapsible, Low-cost Stacking Racks that reduce costly product damage associtaed withbulk stacking, offers better space utilization product identification and easier handling of product with forklifts, can be used for transport, handling, storage and other logistics in all aspects of storage. The new type ofsteel Stacking Racks used for storage cloth, Bar, and so on. It is stackable and the post can movable.
Specification
| Product Name | Stack Racks | ||
|
Standard Configuration |
External Size |
Internal Size |
Goods Size |
| 1400×900×1200 | 1300×850×1000 | 1200×800×900 | |
| 1400×900×1400 | 1300×850×1200 | 1200×800×1100 | |
| 1300×1200×1200 | 1200×1150×1000 | 1100×1100×900 | |
| 1300×1200×1400 | 1200×1150×1200 | 1100×1100×1100 | |
| 1400×1100×1200 | 1300×1050×1000 | 1200×1000×900 | |
| 1400×1100×1400 | 1300×1050×1200 | 1200×1000×1100 | |
| Raw Material | High quality steel Q235 | ||
| Material Thickness | 1.5mm, 1.8mm, 2.0mm, 2.5mm, 3.0mm | ||
| Load Capacity | 1000KG-2000KG per rack or cage | ||
| Stack Quantity | Up to 5 high racks or cages | ||
| Surface Treatment | Deoil, derusting and powder coat paint finish | ||
| Rack Colors | Standard blue, orange and customized available | ||
| Certificates | CE, ISO9001 | ||
| Quick Delivery | Within 15 workdays (negotiable), according to quantity | ||
Applications
The type Rack has been designed as relocatable, stackable racking able to utilize all areas of your storage facility. Special ‘V’ rails allow for fast placement and stable stacking.
The Rack has been fitted with removable mesh panels to each side and the rear for product protection and is suitable for placement of a standard pallet. The Rack has an added advantage of being nest able 10 high (when empty) for transport and storage and is stackable up to 4 high when fully loaded.
Features
1. Conveniently use, safe and reliable;
2. Especially suitable for classified storage and keeping of spare parts which are packaged by box or bulk;
3. Can be stacked together to save space,
Advantages
1. Foldable,it is convenient to shipping.
2. Can be stacked each other, the formation of three-dimensional storage capacity;
3. Save space, can be disassembled and stacked when not in use; can be stacked 5-6 layers when being used
4. Can be stacked multi level,can be move easily;
5. Can be arbitrarily arranged, easy to move.
