Galvanized Concertina Razor Wire Cross Coil Double Loops

Basic Properties
Place of Origin: Hebei, China
Brand Name: ShuXin
Certification: CE, SGS
Model Number: BTO-22, CBT-60, CBT-65
Trading Properties
Minimum Order Quantity: 10 Tons
Standard Packaging: Packing into wooden box
Delivery Time: 7 working days
Supply Ability: 500 sets per month
Product Summary
Galvanized concertina cross coil razor barbed wire price/concertina double loops razor wire mesh for sale Anping Shuxin is specialized in barbed wire and razor wire producing and exporting. During twenty years developing, we have equipped with advanced production equipment, skilled workers, ...

Product Details

Highlight:

Galvanized concertina razor wire

,

concertina razor wire Cross Coil

,

Double Loops concertina razor wire

Type: Razor Concertina Barbed Wire
Size: 45cm -100cm Coil Diameter
Brand Name: SHUXIN
Model Number: BTO-22 Razor Barbed Wire
Surface Treatment: Galvanized
Razor Type: Cross Razor
Barb Length: 10mm-65mm
Barb Width: 11mm-33mm
Barb Spacing: 25mm-100mm
All Type: BTO-10,11, 18, 20, 22, CBT-60, CBT-65 Etc
Packing: In Rolls, In Carton
Sample: Available
Product Description

Galvanized concertina cross coil razor barbed wire price/concertina double loops razor wire mesh for sale


Anping Shuxin is specialized in barbed wire and razor wire producing and exporting.

During twenty years developing, we have equipped with advanced production equipment, skilled workers, professional sales representatives and considerate after sales service.

These contributes our high quality products and long term cooperation with our customers.



Razor Barbed wire is a kind of modern security fencing materials fabricated with high-tensile wire.

Razor wire can be installed as deterrent to the perimeter intruders with piecing and cutting razor blades mounted at the top of the wall. Its high resistance allows greater spacing between the fencing posts.

It used for grass boundary, railway, highway isolation protection



Material:Galvanized wire, PVC coated wire, Stainless steel wire, Hot Dipped Galvanized Sheet.
Razor wire is a mesh of metal strips with sharp edges whose purpose is to prevent passage by humans.
Razor wire is much sharper than the standard barbed wire.



Applications:



Razor Barbed Wire used in mainly serves in protecting of grass boundary, railway, highway and also widely used in military, jail, industry, agriculture, animal husbandry, dwelling house, plantation for fencing.



Specification:



Reference Number

Thickness

(mm)

Wire Dia

(mm)

Bard Length

(mm)

Bard Width

(mm)

Bard Distance

(mm)

BTO-10 0.5±0.05 2.5±0.05 10±1 13± 16±1
BTO-12 0.5±0.05 2.5±0.05 12±1 15±1 26±1
BTO-18 0.5±0.05 2.5±0.05 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.05 22±1 15±1 34±1
BTO-28 0.5±0.05 2.5±0.05 28±1 15±1 53+1
BTO-30 0.5±0.05 2.5±0.05 30±1 21±1 54±1
CBT-60 0.5±0.05 2.5±0.05 60±1 32±1 100±1
CBT-65 0.5±0.05 2.5±0.05 65±1 21±1 100±2



Razor Barbed Wire Coil and Unit Loops



Outside Diameter No.of Loops Standard Length Per Coil Type Notes
450mm 33 8M CBT-65 Single coil
500mm 41 10M CBT-65 Single coil
700mm 41 10M CBT-65 Single coil
960mm 53 13M CBT-65 Single coil
500mm 102 16M BTO-10.15.22 Cross type
600mm 86 14M BTO-10.15.22 Cross type
700mm 72 12M BTO-10.15.22 Cross type
800mm 64 10M BTO-10.15.22 Cross type
960mm 52 9M BTO-10.15.22 Cross type



Packing & Delivery:



1. sheet is packed by pallet or strapped into bundle.
2. sheet in carton or wooden case.
3. rolls in water-proof paper+plastic film.

Galvanized Concertina Razor Wire Cross Coil Double Loops



Producing department:



ANPING SHUXIN MANUFACTORY CO.,LTD,established in 2013.We are located in Anping county,Hebei province.Know as the hometown of Chinese wire mesh.
We are professional manufacturer and have professional technological.
Our mainly product: Chicken Cage, wire mesh basket, wire mesh container, defensive barrier, Gabion, razor wire, and barbed wire etc.
If you want to customize,please contact us.



Galvanized Concertina Razor Wire Cross Coil Double Loops
