Hot Dipped Galvanized Razor Blade Barbed Wire Bto-22 Concertina Double Strand Razor Wire Mesh
Introducing our Premium Blade Razor Wire Security Barrier, a robust and efficient solution designed to enhance security across various applications. Crafted from premium materials and featuring a unique spiral design, this razor wire offers unparalleled protection and deterrence against unauthorized access and intrusions.
Razor Barbed wire is a kind of modern security fencing materials fabricated with high-tensile wire.
Razor wire can be installed as deterrent to the perimeter intruders with piecing and cutting razor blades mounted at the top of the wall. Its high resistance allows greater spacing between the fencing posts.
It used for grass boundary, railway, highway isolation protection
Material:Galvanized wire, PVC coated wire, Stainless steel wire, Hot Dipped Galvanized Sheet.
Razor wire is a mesh of metal strips with sharp edges whose purpose is to prevent passage by humans.
Razor wire is much sharper than the standard barbed wire.
Applications:
Razor Barbed Wire used in mainly serves in protecting of grass boundary, railway, highway and also widely used in military, jail, industry, agriculture, animal husbandry, dwelling house, plantation for fencing.
Specification:
| Reference Number |
Thickness
(mm)
|
Wire Dia
(mm)
|
Bard Length
(mm)
|
Bard Width
(mm)
|
Bard Distance
(mm)
|
| BTO-10 |
0.5±0.05 |
2.5±0.05 |
10±1 |
13± |
16±1 |
| BTO-12 |
0.5±0.05 |
2.5±0.05 |
12±1 |
15±1 |
26±1 |
| BTO-18 |
0.5±0.05 |
2.5±0.05 |
18±1 |
15±1 |
33±1 |
| BTO-22 |
0.5±0.05 |
2.5±0.05 |
22±1 |
15±1 |
34±1 |
| BTO-28 |
0.5±0.05 |
2.5±0.05 |
28±1 |
15±1 |
53+1 |
| BTO-30 |
0.5±0.05 |
2.5±0.05 |
30±1 |
21±1 |
54±1 |
| CBT-60 |
0.5±0.05 |
2.5±0.05 |
60±1 |
32±1 |
100±1 |
| CBT-65 |
0.5±0.05 |
2.5±0.05 |
65±1 |
21±1 |
100±2 |
Categories:
Razor Barbed Wire is roughly divided into spiral, straight line, spiral cross type three forms.Blade thorn rope according to different installation methods can be divided into:
1. (snake belly) spiral blade thorn rope,
2. linear blade thorn rope,
3. flat blade thorn rope,
4. blade thorn rope welding net and so on.
Packing & Delivery:
1. sheet is packed by pallet or strapped into bundle.
2. sheet in carton or wooden case.
3. rolls in water-proof paper+plastic film.
Producing department:
ANPING SHUXIN MANUFACTORY CO.,LTD,established in 2013.We are located in Anping county,Hebei province.Know as the hometown of Chinese wire mesh.
We are professional manufacturer and have professional technological.
Our mainly product: Chicken Cage, wire mesh basket, wire mesh container, defensive barrier, Gabion, razor wire, and barbed wire etc.
If you want to customize,please contact us.
