Square Hole 76.2 X 76.2mm Defense Hesco Blast Walls

Basic Properties
Place of Origin: CN
Brand Name: SHUXIN
Certification: ISO:9001
Model Number: SX-2
Trading Properties
Minimum Order Quantity: 10 units
Price: Negotiated
Standard Packaging: Panel In Bundle, Accessories in Woven Bag
Delivery Time: 10 Working Days
Payment Terms: Western Union, L/C, T/T,Paypal
Supply Ability: 200 unit per day
Product Summary
Military sand wall hesco barrier Military Hesco Barrier Fill Sand Hesco Blast wall Material: Low-carbon steel wire Wire Diameter : 4-5.0mm Spring Diameter : 4.0-4.5mm Mesh Hole : 76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm Panel Size: 2.21× 2.13m, 1.37× 1.06m, 0.61× 0.61m, 1.37× 1.22m ...

Product Details

Highlight:

square hole hesco blast walls

,

76.2 x 76.2mm hesco blast walls

,

defense hesco blast walls

Hole Shape:: Square Hole
Aperture:: 76.2 X 76.2mm
Usage: Defense Barriers
Surface Treatment:: Hot Dipped Galvanized
Packing:: Pallet
Color:: Military Green,beige
Geotextile: 300 Gsm
Main Market: Kenya, Africa
Product Description

Military sand wall hesco barrier Military Hesco Barrier Fill Sand Hesco Blast wall







Material: Low-carbon steel wire
Wire Diameter : 4-5.0mm
Spring Diameter : 4.0-4.5mm
Mesh Hole : 76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm
Panel Size: 2.21× 2.13m, 1.37× 1.06m, 0.61× 0.61m, 1.37× 1.22m
Geotextile : In heavy duty non-woven polypropylene.
Finish : Hot Dipped Galvanized after /before welding, Galfan Coated before welding



                                     Hesco Barrier Specification

Model Height Width Length Internal Cells
SX-1(Mil 1) 54”(1.37m) 42”(1.06m) 32’9”(10m) 5+4=9 cells
SX-2(Mil 2) 24”(0.61m) 24”(0.61m) 4’(1.22m) 2 cells
SX-3(Mil 3) 39”(1.0m) 39”(1.0m) 32’9”(10m) 5+5=10 cells
SX-4(Mil 4) 39”(1.0m) 60”(1.52m) 32’9”(10m) 5+5=10 cells
SX-5(Mil 5) 24”(0.61m) 24”(0.61m) 10’(3.05m) 5 cells
SX-6(Mil 6) 66”(1.68m) 24”(0.61m) 10’(3.05m) 5 cells
SX-7(Mil 7) 87”(2.21m) 84”(2.13m) 91’(27.74m) 5+4+4=13 cells
SX-8(Mil 8) 54”(1.37m) 48”(1.22m) 32’9”(10m) 5+4=9 cells
SX-9(Mil 9) 39”(1.0m) 30”(0.76m) 30’(9.14m) 6+6=12 cells
SX-10(Mil 10) 87”(2.21m) 60”(1.52m) 100’(30.5m) 5+5+5+5+5=20 cells
SX-11(Mil 11) 48”(1.22m) 12”(0.30m) 4’(1.22m) 2 cells
SX-12(Mil 12) 84”(2.13m) 42”(1.06m) 108’(33m) 5+5+5+5+5+5=30 cells
SX-19(Mil 19) 108”(2.74m) 42”(1.06m) 10’5”(3.18m) 6 cells


Square Hole 76.2 X 76.2mm Defense Hesco Blast Walls



Square Hole 76.2 X 76.2mm Defense Hesco Blast Walls
