Woven Wire Mesh 2.0mm Gabion Retaining Wall Box Stone Filled

Basic Properties
Place of Origin: CHINA
Brand Name: SHUXIN
Certification: CE SGS ISO COC
Model Number: GABION
Trading Properties
Minimum Order Quantity: 100 pc
Price: Negotiated
Standard Packaging: pallet
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union,
Supply Ability: 500 pc per day
Product Summary
Woven Wire Mesh Gabion Baskets Retaining Wall Design With Stone Filled Gabion Cages After being made into a box-shaped container, the net cage is filled with riprap and the like, which can be used for protecting and supporting seawalls, hillsides, roads and bridges, reservoirs and other civil ...

Product Details

Highlight:

2.0mm Gabion Retaining Wall

,

2.0mm Gabion Wall Baskets

,

Woven Gabion Retaining Wall

Wire Gauge: 2.0mm-4.0mm
Aperture: 80*100mm
Wire Size: 2.7 Mm /3.4/2.2 Mm
Surface Treatment: Green Pvc Coated
Mesh Shape: Weave Hexagonal
Package: Wooden Pallet
Product Description

 Woven Wire Mesh Gabion Baskets Retaining Wall Design With Stone Filled Gabion Cages




After being made into a box-shaped container, the net cage is filled with riprap and the like, which can be used for protecting and supporting seawalls, hillsides, roads and bridges, reservoirs and other civil engineering projects, and is a good material for flood control and flood fighting.



Product name: gabion wall cage



Gabion box/gabion basket is made of galvanized wire/ZnAl(Galfan)coated wire/PVC or PE coated wires,the mesh is hexagonal shape.



Gabion basket material : galvanized wire,ZnAl(Galfan) coated wire/PVC or PE coated wire



Gabion basket wire diameter : 2.0mm,2.2mm,2.7mm,3.05mm etc.



Gabion basket sizes: 1x1x1m,2x1x0.5m,2x1x1m,3x1x1m,3x1x0.5m,4x1x1m,4x1x0.5m,4x2x0.3m,

5x1x0.3m,6x2x0.3m etc.,customized is available.



Gabion size: 60*80mm,80*100mm,100*120mm,120*150mm,or customized



Gabion surface treatment: hot dip galvanized,aluminum alloy(galfan),PVC coated etc.



Gabion basket application: can be widely used in flood controling,retaining wall,river bank protection,slope protection etc.



Why choose our gabion box ?

Economic. Just fill the stone into the gabion and seal it.

Easy to install.

High zinc coating thus anti-rust and anti-corrosive.

Low cost and High security.

Good permeation can prevent the damage by hydrostatic pressure
Less transport freight. It can be folded together for transport and further installation.



Gabion Cage Applications:

Gabion Mattresses serves as a retaining wall, providing various prevention and protection works such as landslide prevention, erosion and scour protection as well as various type of hydraulic and coastal protection for river, sea and channel protection. This Gabion Mattress System is made up of a specially designed composite in order to maximize its performance through three phases of vegetative process from vegetated to vegetation establishment up to vegetation maturation

Hexagonal Wire Mesh Gabion Cage Specification
Length*Width*Height 2m x 1m x 1m, 3m x 1m x 1m, 4m x 1m x 1m, 2m x 1m x 0.5m, 4m x 1m x 0.5m or Customized
Mesh Size 60*80; 80*100; 100*120 as standard, or customized
Wire Diameter 2.00mm to 4.0m or customized
Surface Finish Electric Galvanized
Hot Dipped Galvanized
Galfan Coated
PVC Coated
Weaving Double Twist
PVC Coated Gabion Box Specification
Opening
(mm)
Wire Diameter(Metal Wire) (mm) Wire Diameter (PVC Coate)/ Inner/Outside(mm)
60X80 φ2.0-2.8 φ2.0/3.0-2.5/3.5
80X100 φ2.0-3.2 φ2.0/3.0-2.8/3.8
80X120 φ2.0-3.2 φ2.0/3.0-2.8/3.8
100X120 φ2.0-3.4 φ2.0/3.0-2.8/3.8
100X150 φ2.0-3.4 φ2.0/3.0-2.8/3.8
120X150 φ2.0-4.0 φ2.0/3.0-3.0/4.0





Woven Wire Mesh 2.0mm Gabion Retaining Wall Box Stone Filled

The packing:

woven bags of the above and bottom,high quality package or as customers requested In roll ,water proof paper in side and our side with weave bag;carton;wooden case;pallet. according to customers requirement.

The Shipping:

Production time :15-20 days after received your payments Transportation way : by see or by air Port: XinGang TianJin or as your order
