Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof

Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof
Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof
Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof

Large Image :  Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof

Product Details:
Place of Origin: Hebei,CHINA
Brand Name: SHUXIN
Certification: CE SGS ISO COC
Model Number: SX-Gabion
Payment & Shipping Terms:
Minimum Order Quantity: 100 pc
Price: Negotiated
Packaging Details: pallet
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 pc per day

Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof

Description
Wire Gauge: 2.0mm-4.0mm Aperture: 80*100mm
Lacing Wire: 2.2mm Surface Treatment: Pvc Coated Or Hot Galvanized
Mesh Shape: Hexagonal Hole Feature: Anti-corrosion,Easy To Install
High Light:

rust proof gabion wall cages

,

2mm gabion wall cages

,

rust proof galvanized gabion basket

Hexagonal Hot Dip Galvanized Gabion Basket / PVC Coated Gabion Wall Cages Mesh Box For Sale



Gabion Cage Description :



Gabion baskets, also called gabion boxes, are made of corrosion-resistant, high-strength and ductile galvanized wire or PVC coated wire through mechanical weaving. Wire material is zinc -5% aluminum alloy (galfan), low carbon steel, stainless steel or iron.

Gabion mattress is similar to gabion basket. But gabion mattress's height is lower than gabion basket, structure is flat and big. Gabion basket and gabion mattress are stone containers, uniformly partitioned into internal cells, interconnected with other containers and filled with stone at site to form flexible, permeable, monolithic structures to control and guide water or flood, protect dam or seawall, or used as retaining walls, channel lining and other applications.



Characteristics Metallic coated PVC coated Metallic coated PVC coated
Mesh type 8x10cm 6*8cm
Mesh openings

83mm x 114mm

8 x 10

83mm x 114mm

8 x 10

64mm x 83mm

6x8

64mm x 83mm

6x8

Mesh wire 2.7mm (0.106 in.) 3.05mm( 0.120 in.) 2.2mm (0.087 in.) 2.2mm (0.087 in.)
Selvage wire 3.4mm (0.134 in.) 3.8mm (0.150 in.) 2.7mm (0.105 in.) 2.7mm (0.105 in.)
Lacing wire 2.2mm (0.087 in.) 2.2mm (0.087 in.) 2.2mm (0.087 in.)

2.2mm(0.087 in.)





Introduction to the use of gabion baskets:



The structure can be used for side slope support, foundation pit support, mountain rock surface hanging net shotcrete, side slope vegetation (greening), railway highway isolation fence, it can also be made into box cages, net pads, used in rivers, rivers, Erosion protection of dams and seawalls, as well as cages for the closure of reservoirs and rivers.

●Control and guide rivers and floods

The most serious disaster of rivers is the destruction of river banks by water, which caused flooding, resulting in massive losses of lives and properties and massive soil erosion. The application of the ecological gabion net structure can permanently protect the river bed and bank.

●Channel canal bed

The construction of the channel involves the stability of the slope and river bed. It can effectively and permanently protect the river bank or riverbed, control the flow of water, prevent water loss, and has excellent effects in environmental protection and water quality maintenance.

●Slope protection

The application of ecological grid structure to river bank protection and slope toe protection is a very successful example. It gives full play to the advantages of ecological grid and achieves the ideal effect that other methods cannot achieve.


Gabion Cage Advantage:



1. The flexible structure can adapt to the changes of the slope without being destroyed, and has better safety and stability than the rigid structure;

2. Strong anti-scouring ability, can withstand the maximum water flow speed up to 6m/s;

3. The structure is inherently water-permeable, and has strong tolerance to the natural and filtering effects of groundwater. Suspended matter and silt in the water can be deposited in the rockfill, which is beneficial to the growth of natural plants. Restore the original ecological environment.



Gabion Basket Installation Process:



1. Ends,diaphragms,front and back panels are placed upright on the bottom section of wire mesh

2. Secure panels by screwing sprial binders through the mesh openings in adjacent panels

3. Stiffeners shall be placed across the corners, at 300mm from the corner. Providing a diagonal bracing,and crimped

4. Box gabion filled with graded stone by hand or with a shovel.

5. After filling,close the lid and secure with sprial binders at the diaphragms,ends,front and back.

6. When stacking tiers of the weled gabion,the lid of the lower tier may serve as base of the upper tier.Secure with sprial binders and add pre-formed stiffeners to exterior cells before filling with graded stones.



Hexagonal Hot Dip Galvanized Pvc Coated 2mm Gabion Wall Cages Rust Proof 0
