Galvanized Safety Protection Spike Rope PVC Coated Barbed Wire Mesh Fence Stock Fast Delivery

Basic Properties
Place of Origin: Hebei China
Brand Name: SHUXIN
Certification: CE SGS COC PVOC
Model Number: SX-B03
Trading Properties
Minimum Order Quantity: 100 pcs
Price: Consultation
Standard Packaging: Plastic bags + Wooden Pallet
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5000 sets per week
Product Summary
Galvanized Safety Protection Spike Rope PVC Coated Barbed Wire Mesh Fence Stock Fast Delivery Product Description Barbed wire, also known as bob wire, is the most important component of barbed wire fence system. It can be used individually to form the barbed wire fence, and it also can be attached ...

Product Details

Highlight:

security fence barbed wire

,

security fencing barbed wire

,

Secure Barbed Wire

Product Name: Galvanized Safety Protection Spike Rope PVC Coated Barbed Wire Mesh Fence Stock Fast Delivery
Surface Treatment: Galvanized
Razor Type: Single Razor
Type: Barbed Wire Coil
Barbed Length: 1.5-3cm
Wire Diameter: 1.6-3.2mm,customized
Usage: Farm Fencing, Airport Fencing, Building Fence Etc
Advantage: Safety ,Eco-friendly Weather Resistant
Product Description

Galvanized Safety Protection Spike Rope PVC Coated Barbed Wire Mesh Fence Stock Fast Delivery





Galvanized Safety Protection Spike Rope PVC Coated Barbed Wire Mesh Fence Stock Fast Delivery

Product Description

Barbed wire, also known as bob wire, is the most important component of barbed wire fence system.

It can be used individually to form the barbed wire fence, and it also can be attached onto various fences, such as chain link fence, welded wire mesh fence, expanded mesh fence or palisade fence for high level security barrier. With the features of sharp edge, high tensile strength and corrosion, rust resistance, they are widely used for prison fencing, airport fencing, farm fencing, ranch fencing, residence fencing, large construction site fencing and so on .

We supply both double twist barbed wire and single twist barbed wire with high quality. Barbed wire is common fence material. It’s not only used individually to barbed wire fence but also can be attached onto various fence mesh, such as Chain link fence, welded wire mesh panel. Barbed wire is used chiefly for fencing in livestock, keeping out trespassers. It is suitable for agriculture, animal boundary, military and prison protection, and security applications.



Features: Low cost, non-climb

Materials: Electro-galvanized wire, Hot-dipped galvanized wire, PVC Coated galvanized wire

Applications: Farm fencing, Airport fencing, Building fence etc.

Zinc coated: 40-60g/m2,8-20g/m2
Weight coil:5-50KG
Roll length:100m,200m,350m,400m,500m
Breaking load (Rupture):250KGF,350KGF
Barbed wire weave types: Double twist barbed wire, Traditonal Twist barbed wire, Single strand barbed wire
PVC PE coating thickness:0.4-0.6mm; different colors or length are available at customers request


Specification
GALVANIZED BARBED WIRE
Wire Diameter
(BWG)
Length per KG
Barb distance
3”
Barb distance
4”
Barb distance
5”
Barb space
6”
12 x 12
6.0617
6.7590
7.2700
7.6376
12 x 14
7.3335
7.9051
8.3015
8.5741
12.5 x 12.5
6.9223
7.7190
8.3022
8.7221
12.5 x 14
8.1096
8.8140
9.2242
9.5620
13 x 13
7.9808
8.8990
9.5721
10.0553
13 x 14
8.8448
9.6899
10.2923
10.7146
13.5 x 14
9.6079
10.6134
11.4705
11.8553
14 x 14
10.4569
11.6590
12.5423
13.1752
14.5 x 14.5
11.9875
13.3671
14.3781
15.1034
15 x 15
13.8927
15.4942
16.6666
17.5070
15.5 x 15.5
15.3491
17.1144
18.4060
19.3386



Barbed wire is twisted wires armed with barbs or sharp points. Double twist barbed wire consists of two wire strands together with four point barbs, placed at predetermined distance. Normally, the standard barbs distance are 3inch,4inch,5inch. Single twist barbed wire use high or low carbon wire as main wire with either two or four point barbs. Barbed wire produce with roll packing. In order to protect hands during load and unload, it is also usually installed with handle.

Barbed wire is a kind of modern security fencing materials,Barbed wire can be installed as deterrent to the perimeter intruders with piecing and cutting razor blades mounted at the top of the wall . Galvanized barbed wire offers a great protection against corrosion and oxidation caused by the atmosphere. Its high resistance allows greater spacing between the fencing posts.





Galvanized Safety Protection Spike Rope PVC Coated Barbed Wire Mesh Fence Stock Fast Delivery
