Product Details:
|
| Features: | Easy Installation, Suitable For Any Terrain | Name: | Mesh Box Gabion Bakset |
|---|---|---|---|
| Material: | Galvanized Wire, PVC Wire, Galfan Wire | Weave: | Double Twist, Trible Twist |
| Mesh Wire: | From 2.4mm To 3.4mm | Selvage Wire: | From 3.0mm To 3.9mm |
| Biding Wire: | Common Use 2.2mm | Mesh Hole: | 60*80mm, 80*100mm, Customized |
| Gabion Size: | 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 2*1*0.5m | Pakcage: | In Bundle ( After Compression) |
| Zinc Coating: | Around 275g/sq.mt | Usage: | Rive Protection, Retaing Wall, Flood Control |
| High Light: | zinc coated wire mesh gabion box,hexagonal wire mesh gabion box,double twisted gabion cages and baskets |
||
275g Zinc Coated Hexagonal Double Twisted Mesh Box Gabion Basket for Sale
Gabion basket are wire mesh boxes, containers or baskets filled with rock to prevent soil erosion and to retain/contain soil particles. Flat Gabions, called River or es, are widely used in river courses where soil erosion is a problem over a large flat or sloped area in need of protection against soil loss or scour. They are used mostly in the civil engineering industry, especially in the construction of roadway drainage structures. Recently however, due to the environmental benefits associated with gabions, they are being used in many various applications and industries.
| Gabion Basket Technical Data Sheet | ||||
| Surface Treatment | Hot Dipped Galvanized | PVC Coated | ||
| Mesh Hole | 80 * 100 mm | 60 * 80 mm | 80 *100 mm | 60 * 80 mm |
| Mesh Wire | 2.2 - 3.0 mm | 2.0 - 2.7 mm | 2.2 / 3.2 - 3.0 / 4.0 mm | 2.0 /3.0 - 2.7 / 3.7 mm |
| Selvage Wire | 3.0 - 3.9 mm | 3.0 - 3.7 mm | 3.0 / 4.0 - 3.9 / 4.9 mm | 3.0 / 4.0 - 3.7 / 4.7 mm |
| Lacing Wire | 2.2 mm | 2.2 mm | 2.2 / 3.2 mm | 2.2 / 3.2 mm |
| Gabion Basket Size | 1 * 1 * 1 m, 2 * 1 * 1 m, 3 * 1 * 1 m, 4 * 1 * 1 *1 m, etc | |||
| Material | Q 195, Low Carbon Steel Wire, Galvanized Wire, PVC Coated Wire | |||
| Surface | hot dipped Galvanized, PVC Coated | |||
| Zinc Coating | 275 g/sq.mt | |||
| Package | usually 100 PCS/Bundle, also depending on the size of gabion basket you need. | |||
| Production Time | Uusally 7 days after getting payment. | |||
Features:
1. Easy to install, no special technology required.
2. 6 M/S strong anti - scour ability, able to withstand water, flow speeds up to 6 M/S
3. Good Ductility, no structural joints
4. High strength, withstand a wide range of deformation.
