Product Details:
|
| Features: | Easy Installation, Suitable For Any Terrain | Name: | Retaining Wall Gabion Basket |
|---|---|---|---|
| Material: | Galvanized Wire, PVC Wire, Galfan Wire | Weave: | Double Twist, Trible Twist |
| Mesh Wire: | From 2.4mm To 3.4mm | Selvage Wire: | From 3.0mm To 3.9mm |
| Biding Wire: | Common Use 2.2mm | Mesh Hole: | 60*80mm, 80*100mm, Customized |
| Gabion Size: | 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 2*1*0.5m | Pakcage: | In Bundle ( After Compression) |
| Zinc Coating: | Around 275g/sq.mt | Usage: | Rive Protection, Retaing Wall, Flood Control |
| High Light: | hot dip galvanized gabion fence baskets,hexagonal woven mesh gabion fence baskets,retaining wall galvanised gabions |
||
Hot dip galvanized hexagonal woven mesh for retaining wall gabion basket
Gabion basket is made from high grade Low Carbon steel iron wire, heavy zinc coated wire, PVC coated wire though twisting and braiding by machine. as well as galfan coated units.
Galfan is a high performance galvanising process using a zinc/aluminium/mischmetal alloy coating. This offers significantly greater protection than traditional zinc galvanizing. Where the product is exposed to water courses or a saline environment, we strongly recommends a polymer coated galvanized unit for improved design life.
| Gabion Basket Technical Data Sheet | ||||
| Surface Treatment | Hot Dipped Galvanized | PVC Coated | ||
| Mesh Hole | 80 * 100 mm | 60 * 80 mm | 80 *100 mm | 60 * 80 mm |
| Mesh Wire | 2.2 - 3.0 mm | 2.0 - 2.7 mm | 2.2 / 3.2 - 3.0 / 4.0 mm | 2.0 /3.0 - 2.7 / 3.7 mm |
| Selvage Wire | 3.0 - 3.9 mm | 3.0 - 3.7 mm | 3.0 / 4.0 - 3.9 / 4.9 mm | 3.0 / 4.0 - 3.7 / 4.7 mm |
| Lacing Wire | 2.2 mm | 2.2 mm | 2.2 / 3.2 mm | 2.2 / 3.2 mm |
| Gabion Basket Size | 1 * 1 * 1 m, 2 * 1 * 1 m, 3 * 1 * 1 m, 4 * 1 * 1 *1 m, etc | |||
| Material | Q 195, Low Carbon Steel Wire, Galvanized Wire, PVC Coated Wire | |||
| Surface | hot dipped Galvanized, PVC Coated | |||
| Zinc Coating | 275 g/sq.mt | |||
| Package | usually 100 PCS/Bundle, also depending on the size of gabion basket you need. | |||
| Production Time | Uusally 7 days after getting payment. | |||
Features:
1. Easy to install, no special technology required.
2. 6 M/S strong anti - scour ability, able to withstand water, flow speeds up to 6 M/S
3. Good Ductility, no structural joints
4. High strength, withstand a wide range of deformation.
