Product Details:
|
| Product Name: | Gabion Basket | Material: | Zn-Al(Galfan) Coated Wire/PVC Coated Wire |
|---|---|---|---|
| Wire Diameter: | 2.7-3.4 Mm | Application: | Construction Wire Mesh,Cages,Protecting Mesh |
| Gabion Size: | 2*1*1 M /1*1*1 M | Hole Size: | 8*10 Cm /10*12 Cm |
| High Light: | 8*10 cm mesh stone gabion cages,river wall protection stone gabion cages,low carbon stone filled gabion walls |
||
Low-Carbon Iron Wire 8*10 Cm Mesh Wire Gabion Baskets For River Wall Protection
Stone Gabion Mesh are made of high quality steel wire, which has 2 types of fabrication: double or triple twist fabric. The fabric structures are flexible and variable. Compared with welded gabion baskets, woven gabion baskets have durability for a long service life.
Gabion are rectangular baskets made of heavily galvanized, double twisted, steel woven wire mesh. The single unit constructed baskets are assembled, laced together and then filled with stone to form a monolithic structure.
| Material | galvanized wire, Zn-Al(Galfan) coated wire/ PVC coated wire |
| Application |
can be widely used in flood controlling,retaining wall,river bank protection, slope protection . |
| Hole shape | Weave Hexagonal |
| Use life | About 30 years , |
| Processing | Bending, Cutting |
| Package | Wooden pallets |
| Gabion basket | |
| Mesh wire | 2.0mm-4.0mm |
| Mesh size | 60*80mm, 80*100mm, 90*110mm, 100*120mm, 120*150mm |
| Selvedge wire | thicker 0.5mm-1.0mm than mesh wire |
| Tie wire | 2.2mm, 2.5mm |
| Gabion size | 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 6*2*0.3m |
| Surface treatment | high zinc coated, HD galvanized, PVC coated |
Gabion basket application:
After being made into a box-shaped container, the net cage is filled with riprap and the like, which can be used for protecting and supporting seawalls, hillsides, roads and bridges, reservoirs and other civil engineering projects, and is a good material for flood control and flood fighting.
The construction combination and stone filling steps can be summarized as follows: Each unit structure is combined before placement The structure of the pad combination is placed at the construction site, and the cell structures are connected by tie wire. Rock fill in structure Cover the structure and fasten it with tie wie
The packing:
woven bags of the above and bottom,high quality package or as customers requested In roll ,water proof paper in side and our side with weave bag;carton;wooden case;pallet. according to customers requirement.
The Shipping:
Production time :7-10 days after received your payments Transportation way : by see or by air Port: XinGang TianJin or as your order
After the production of gabion cage is completed, in order to save volume, compression packaging can be bundled.
Less transport freight. It can be folded together for transport and further installation.
