Product Details:
Payment & Shipping Terms:
|
| Features: | Easy Installation, Suitable For Any Terrain | Name: | Customized Gabion Basket |
|---|---|---|---|
| Material: | Galvanized Wire, PVC Wire, Galfan Wire | Weave: | Double Twist |
| Mesh Wire: | From 2.4mm To 3.4mm | Selvage Wire: | From 3.0mm To 3.9mm |
| Biding Wire: | Common Use 2.2mm | Mesh Hole: | 60*80mm, 80*100mm, Customized |
| Gabion Size: | 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 2*1*0.5m | Pakcage: | In Bundle ( After Compression) |
| Zinc Coating: | Around 275g, Or 60g | Usage: | Rive Protection, Retaing Wall, Flood Control |
| Shape Of Hole: | Hexagonal | Brand: | SHUXIN |
| Application: | Water Conservancy Project | Certificate: | ISO, And Other Documents To Do Customs Clearance |
| Sample: | Free Sample | Shipping: | 7 Days / Fast Shipping |
| Trade Term: | FOB,CNF,DDP | Payment: | Deposit Was Acceptable |
| Highlight: | gabion baskets 2m x 1m x 1m,anti rust gabion baskets 1mx1m,flood control gabion baskets 1mx1m |
||
South Africa Anti Rust Galfan Hexagonal Gabion Basket for Fllood Control Retaining Wall
Gabion Basket is a rectangle cage, made by Hexgonal Double Twisted Woven cloth, it can be 1*1*1m, 2*1*1m, 3*1*1m,4*1*1m and also 6*2*0.3m etc. we also can accept customized cage size.
Usually the material can be galvanized, PVC Coated and Galfan Coated. different material with different prices. Although Galfan Coated can last 2-3 times longer than Galvanized and PVC Coated , but it not meaning that Galfan coated is the most suitable for you. No matter which surface treatment is good, just choose the suitable one for you is okay.
| Name | Customized Gabion Basket |
| Material | Galvanized wire, PVC Wire, Galfan Wire |
| Weave |
Double Twist |
| Mesh Wire | From 2.4mm to 3.4mm |
| Selvage Wire | from 3.0mm to 3.9mm |
| Biding Wire | common use 2.2mm |
| Mesh Hole | 60*80mm, 80*100mm, customized |
| Gabion Size | 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 2*1*0.5m |
| Pakcage | In bundle ( after compression) |
| Zinc Coating | around 275g, or 60g |
| Usage | Rive protection, Retaing wall, flood control |
| Features | easy installation, suitable for any terrain |
| Shape of Hole | Hexagonal |
| Brand | SHUXIN |
Our Advantages:
| Gabion Basket Technical Data Sheet | ||||
| Mesh Hole | 80×100mm | 60×80mm | ||
| Mesh Diameter | 2.2 - 3.0 mm | 2.0 - 2.7 mm | ||
| Selvage Wire | 3.0 -3.9 mm | 3.0 - 3.7 mm | ||
| Lancing Wire | 2.2 mm | 2.2 mm | ||
| Gabion Basket Size | 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 2*1*0.5m etc | |||
| Material | Galvanized Wire, PVC Coated Wire, Galfan Coated Wire | |||
| Pakcage | usually 100 PCS/bundle, also depend on the size of gabion | |||
| Sample | Small Piece of sample is free. | |||
Features:
1. Easy to install, no special technology required.
2. 6 M/S strong anti - scour ability, able to withstand water, flow speeds up to 6 M/S
3. Good Ductility, no structural joints
4. High strength, withstand a wide range of deformation.
![]()
