2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh

2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh
2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh
2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh 2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh

Large Image :  2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh

Product Details:
Place of Origin: CHINA
Brand Name: SHUXIN
Certification: ISO,CE,SGS,
Model Number: SX-gabion basket-02
Payment & Shipping Terms:
Minimum Order Quantity: 1200PCS
Price: USD: 6-7/PCS
Packaging Details: Bundle and Container
Delivery Time: 6-7days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 PCS Per Week

2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh

Description
Name: Gabion Basket Material: Galvanized Wire, PVC Wire, Galfan Wire
Weave: Double Twist Mesh Wire: 2.5/2.8/3.0mm
Selvage Wire: 3.4mm Biding Wire: 2.2mm
Mesh Hole: 60*80mm, 80*100mm, 100mm*120mm Gabion Size: 6*2*0.3m, 2*1*1m, 3*1*1m, 4*1*1m
Warranty: ≥ 2 Years Application: Gabions Retaining Wall, Bank Protection
High Light:

2.5mm welded gabion baskets

,

hot dipped galvanized welded gabion baskets

,

welded gabion baskets 2x1x1

china gabion supplier 3.05mm 2x1x1m 8*10cm hexagonal stone gabion mesh/3x1x0.5m gabion baskets





The gabions are made of high corrosion resistant, high strength, ductile low carbon steel wire or PVC coated steel wire woven together using machinery. The diameter of the low carbon steel wire used varies according to ASTM and EN standards, depending on the design requirements. The tensile strength of the wire is not less than 38kg/m2 and the metal coating weight is generally higher than 245g/m2. The length of the twisted part of the double wire must not be less than 50 mm to ensure that the metal plating and PVC plating of the twisted part of the wire are not damaged.

2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh 0

Mesh Hole
PVC Coated Wire (Inner/Outside
Hot Dipped Galvanized Wire
Galfan Coated Wire
60*80mm
2.0mm/3.0mm-2.8mm/3.8mm
2.2mm-3.8mm
2.2mm-3.8mm
80*100mm
2.2mm/3.2mm-3.0mm/4.0mm
3.2mm-4.0mm
3.2mm-4.0mm
100*120mm
2.4mm/3.4mm-3.2mm/4.2mm
3.4mm-4.2mm
3.4mm-4.2mm
120*150mm
2.7mm/3.7mm-3.5mm/4.5mm
3.7mm-4.5mm
3.7mm-4.5mm
Length (M)
Width (M)
Height (M)
Diaphragm Quantity
1
1
1
0
2
1
1
1
3
1
1
2
4
1
1
3
6
1
1
5
2
1
0.5
1
3
1
0.5
2
3
2
0.3
5

2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh 1

It can be produced according to the design requirements of the drawings. Generally, the machine is up to 4m wide and any length. However, the conventional size of Renault pad in China is 6*2*0.3m, mesh: 6*8cm, wire diameter: 2.0mm. Materials: galvanized, galvanized PVC (PVC color is usually gray or green), Galfan commonly known as 5% or 10% zinc aluminum alloy, zinc aluminum alloy coated PVC. Zinc aluminum alloy material is the best quality of these products, and its service life is 70~80 years! The cage size is generally 2*1*1m 4*1*1m 1*1*1m, and the mesh pad size is generally 6*2*0.3m 6*2*0.17m 4*2*0.35m.

2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh 2

Gabion pad material:
(1) Galvanized steel wire: high-quality low-carbon steel wire, with a diameter of 2.0mm-4.0mm, and a tensile strength of not less than 380MPa. The surface of the steel wire is protected by hot galvanizing. The thickness of the galvanized protective layer is made according to the customer's requirements, and the maximum amount of galvanizing can reach 300g/m2.
(2) Zinc-5% aluminum mixed rare earth alloy steel wire: (also known as golfan) steel wire, which is a new material in the world in recent years, has corrosion resistance more than three times that of traditional pure galvanizing. The diameter of the steel wire can reach 2.0mm-4.0mm, and the tensile strength of the steel wire is not less than 380MPa.
(3) Galvanized steel wire wrapped with plastic: high-quality low-carbon steel wire is wrapped with a layer of PVC or PE protective layer on the surface of the steel wire, and then woven into gabion nets of various specifications. This protective layer will greatly increase the protection in highly polluted environment, and make it integrate with the surrounding environment through the selection of different colors.
(4) Zinc-5% aluminum mixed rare earth alloy steel wire wrapped with plastic: a layer of PVC or PE protective layer is wrapped on the surface of Zinc-5% aluminum mixed rare earth alloy steel wire, and then woven into gabion nets of various specifications. This protective layer will greatly increase the protection in highly polluted environment, and make it integrate with the surrounding environment through the selection of different colors.

2.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh 32.5mm 2x1x1 Welded Gabion Baskets Protection Hot Dipped Galvanized Mesh 4
