Pvc Coated Metal Gabion Baskets Retaining Wall

Pvc Coated Metal Gabion Baskets Retaining Wall
Pvc Coated Metal Gabion Baskets Retaining Wall
Pvc Coated Metal Gabion Baskets Retaining Wall Pvc Coated Metal Gabion Baskets Retaining Wall Pvc Coated Metal Gabion Baskets Retaining Wall Pvc Coated Metal Gabion Baskets Retaining Wall

Large Image :  Pvc Coated Metal Gabion Baskets Retaining Wall

Product Details:
Place of Origin: Hebei, China
Brand Name: SHUXIN
Certification: CE SGS ISO COC
Model Number: Gabion-Weave
Payment & Shipping Terms:
Minimum Order Quantity: 100 pcs
Price: Negotiated
Packaging Details: Packed in bundles.We have a lot of stock and can ship quickly.
Delivery Time: 2 work days
Payment Terms: T/T, Western Union, MoneyGram, D/A, D/P, L/C
Supply Ability: 30000 Square Meter/Square Meters per Day

Pvc Coated Metal Gabion Baskets Retaining Wall

Description
Features: High Corrosion Resistance, High Strength, Ductility Weave Style: PVC Coated Gabions Baskets Prices Retaining Wall
Color: Sliver,Green,Gray Surface Treatment: Galvanized, PVC Coated
Mesh Wire: 2.0mm-4.0mm Selvedge Wire: 3.4mm, 3.8mm
Lacing Wire: Common Use 2.2mm Zinc Coating: 240-260g/m2
Gabion Box Size: 1*1*1m / 2*1*1m / 3*1*1m / 2*1*0.5m Application: Earth-Retaining Wall, River Bank Gabion Protection
High Light:

pvc coated metal gabion baskets

,

retaining wall metal gabion baskets

,

metal gabion baskets 1mx1m

PVC Coated Low Iron Wire Mesh 2x1x1 Hexagonal Gabion Gabions Baskets Prices Retaining Wall





Gabion basket also named gabion box, is weaved by corrosion resistance, high strength and good ductility galvanized wire or PVC coating wire through mechanical. Wire's material is zinc-5% aluminum alloy (galfan), low carbon steel, stainless steel or iron.



Gabion mattress is similar to gabion basket. But gabion mattress's height is lower than gabion basket, structure is flat and big. Gabion basket and gabion mattress are stone containers, uniformly partitioned into internal cells, interconnected with other containers and filled with stone at site to form flexible, permeable, monolithic structures to control and guide water or flood, protect dam or seawall, or used as retaining walls, channel lining and other applications.



Gabion mesh/ gabion box material:

(1) Galvanized steel wire: diameter 2.0MM-4.0MM, tensile strength >380Mpa, zinc :240g / m2.

(2) Zinc 5% Aluminum - wire diameter 1.0MM-3.0MM, tensile strength >380Mpa.

(3) coated galvanized steel wire: low carbon steel wire PVC coated.

(4) Woven Mesh Opening: Hexagonal Wire Pattern 60*80mm, 80*100mm,100*120mm,

(5) Size: 1*1*1m,2*1*1m, 4*1*1x2m, other size can be produced as requested



Gabion box

(mesh size):

80*100mm

100*120mm

Mesh Wire diameter 2.7mm zinc coating:60g,245g, ≥270g/m2
Edge wire diameter 3.4mm zinc coating:60g,245g, ≥270g/m2
Tie wire diameter. 2.2mm zinc coating:60g,≥220g/m2

Gabion mattress

(mesh size):

60*80mm

Mesh wire diameter. 2.2mm zinc coating:60g, ≥220g/m2
Edge wire diameter. 2.7mm zinc coating:60g,245g, ≥270g/m2
Tie wire diameter. 2.2mm zinc coating:60g, ≥220g/m2



special sizes Gabion

are available



Mesh wire diameter 2.0~4.0mm

superior quality,competitive price and

considerate service

Edge wire diameter 2.7~4.0mm
Tie wire diameter 2.0~2.2mm
Weaving type Feature Material

Mesh size



Wire Gauge



Processing Service
Durable Three Normal Twist Corrosion Resistance Galvanized Iron Wire

80x100 cm

100x120cm

2.7mm-3.5mm Bending Cutting



Gabion Basket Application:



Control and guide of water or flood

Flood bank or guiding bank

Preventing of rock breaking

Water and soil protection

Bridge protection

Strengthening structure of soil

Protection engineering of seaside area



Pvc Coated Metal Gabion Baskets Retaining Wall 0

Gabion Basket Advantage:

Economic. Just fill the stone into the gabion and seal it.

Easy to install.

High zinc coating thus anti-rust and anti-corrosive.

Low cost and High security.

Good permeation can prevent the damage by hydrostatic pressure

Less transport freight. It can be folded together for transport and further installation.
