Iron Wire Mesh Gabion Box Retaining Wall Galvanized / Pvc Coated Blocks 1mx1m

Large Image : Iron Wire Mesh Gabion Box Retaining Wall Galvanized / Pvc Coated Blocks 1mx1m

Product Details:

Place of Origin:	China
Brand Name:	apkn111
Certification:	ISO,CE,SGS,COC
Model Number:	slw01

Payment & Shipping Terms:

Minimum Order Quantity:	100pc
Price:	Negotiated
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 pc per day

Contact Now

Iron Wire Mesh Gabion Box Retaining Wall Galvanized / Pvc Coated Blocks 1mx1m

Description

Name:	Gabion Basket	Wire Gauge:	2.0mm-4.0mm
Aperture:	80*100mm	Lacing Wire:	2.2mm
Surface Treatment:	Pvc Coated Or Galvanized	Mesh Shape:	Hexagonal Hole
Feature:	Anti-corrosion
Highlight:	iron gabion box retaining wall , galvanized gabion box retaining wall , gabion baskets 1mx1m

Iron Wire Mesh Galvanized Gabion / PVC Coated Gabions Baskets Prices Retaining Wall Blocks

Iron Wire Mesh Galvanized Gabion / PVC Coated Gabions Baskets Prices Retaining Wall Blocks

Gabion box (mesh size): 80100mm 100120mm	Mesh Wire diameter	2.7mm	zinc coating:60g,245g, ≥270g/m2
	Edge wire diameter	3.4mm	zinc coating:60g,245g, ≥270g/m2
	Tie wire diameter.	2.2mm	zinc coating:60g,≥220g/m2
Gabion mattress (mesh size): 60*80mm	Mesh wire diameter.	2.2mm	zinc coating:60g, ≥220g/m2
	Edge wire diameter.	2.7mm	zinc coating:60g,245g, ≥270g/m2
	Tie wire diameter.	2.2mm	zinc coating:60g, ≥220g/m2
special sizes Gabion are available	Mesh wire diameter	2.0~4.0mm	superior quality,competitive price and considerate service
	Edge wire diameter	2.7~4.0mm
	Tie wire diameter	2.0~2.2mm

Surface treatment:

Electrical galvanized (zinc coating: 10g/m2), Hot dipped Galvanized: (zinc coating: 300g/m2), Aluminium Alloy, PVC coated (pvc thickness: 1.0mm Iron Wire Mesh Gabion Box Retaining Wall Galvanized / Pvc Coated Blocks 1mx1m 1

More Sizes Available, also accept customized production size


Packing & Delivery
Packing & Del
1.With plastic weaving bags outside
2.With wooden pallet cloth
3..Less transport freight. It can be folded together for transport and further installation.
For 2*1*1 m :
1*20 gp :1000 pcs (11000sqm)
1*40 hq:1700 pcs (18700sqm)

Gabion Cage Applications :

• Control and guide of water or flood

• Flood bank or guiding bank

• Prevention of rock breaking

• Water and soil protection

• Bridge protection

• Strengthening structure of soil

• Protection engineering of seaside area

• Seaport engineering

• Isolation walls

• Protection of road
