Hot-dipped Galvanized Razor Wire for Enhanced Security and Safety

Basic Properties
Place of Origin: China
Brand Name: SHUXIN
Certification: CE ISO
Model Number: No.1
Trading Properties
Minimum Order Quantity: MQQ 10
Price: USD70
Standard Packaging: Export package
Delivery Time: 7 days
Payment Terms: D/A, L/C, D/P, T/T, Western Union,
Supply Ability: 1000 pcs per day
Product Summary
Model NO. GY-RBW464 Finish Hot Dipped Galvanized Razor Barbed Type Cross Razor Wire Gauge 12x12 BWG Barbed Distance 3" Barb Length 22mm Coil Outside Diameter 500mm Color Galvanized Color Surface Treatment Hot Galvanized, Heavy Zinc Coated, Powder Coated Samples Free Valid Certificate Test SGS ...

Product Details

Highlight:

barbed wire and razor wire

,

barbed wire razor

,

barbed wire razor wire

Barbed Width: 13mm, 15mm, 21mm, 32mm
Barbed Length: 10 12 18 22 28 30 60 65
Ventilation: Side Ventilation
Warranty: 1 Year
Packaging: Standard Export Packaging
Lifespan: 15 Years
Product Description



Model NO.
GY-RBW464
Finish
Hot Dipped Galvanized
Razor Barbed Type
Cross Razor
Wire Gauge
12x12 BWG
Barbed Distance
3"
Barb Length
22mm
Coil Outside Diameter
500mm
Color
Galvanized Color
Surface Treatment
Hot Galvanized, Heavy Zinc Coated, Powder Coated
Samples
Free Valid
Certificate Test
SGS
Delivery Time
15 Days or According to The Quantity













Razor Barbed Wire Concertina Razor Wire for Security Fence

Model Plate Thickness
mm
Core wire Diameter mm Barb Length
mm
Barb Width
Mm
Barb Spacing
mm
BTO-10 0 .5 +- 0.05 mm 2.5mm 10mm 13mm 26mm
BTO-12 0 .5 +- 0.05 mm 2.5mm 12mm 15mm 26mm
BTO-18 0 .5 +- 0.05 mm 2.5mm 18mm 15mm 38mm
BTO-22 0 .5 +- 0.05 mm 2.5mm 22mm 15mm 38mm
BTO-28 0 .5 +- 0.05 mm 2.5mm 28mm 15mm 53mm
BTO-30 0 .5 +- 0.05 mm 2.5mm 30mm 21mm 54mm
BTO-60 0 .6 +- 0.05 mm 2.5mm 60mm 32mm 102mm
BOT-65 0 .3 +- 0.05 mm 2.5mm 65mm 22mm 102mm

Hot-dipped Galvanized Razor Wire   for Enhanced Security and SafetyHot-dipped Galvanized Razor Wire   for Enhanced Security and Safety





Coil OD
(mm)
NO. of Loops NO. of Clips The Utmost
Length (m)
Barb Type Notes
450 mm 33 - 7-8 m CBT60 CBT65 Single Coil
500 mm 56 - 12-13 m CBT60 CBT65 Single Coil
700 mm 56 - 13-14 m CBT60 CBT65 Single Coil
960 mm 56 - 14-15 m CBT60 CBT65 Single Coil
450 mm 56 3 clips 8-9 m BTO12 18 22 28 30 Cross Type
500 mm 56 3 clips 9-10 m BTO12 18 22 28 30 Cross Type
600 mm 56 3 clips 10-11 m BTO12 18 22 28 30 Cross Type
600 mm 56 5 clips 8-10 m BTO12 18 22 28 30 Cross Type
700 mm 56 5 clips 10-12 m BTO12 18 22 28 30 Cross Type
800 mm 56 5 clips 11-13 m BTO12 18 22 28 30 Cross Type
900 mm 56 5 clips 12-14 m BTO12 18 22 28 30 Cross Type
960 mm 56 5 clips 13-15 m BTO12 18 22 28 30 Cross Type
980 mm 56 5 clips 14-16m BTO12 18 22 28 30 Cross Type







Hot-dipped Galvanized Razor Wire   for Enhanced Security and Safety



Hot-dipped Galvanized Razor Wire   for Enhanced Security and Safety
