Welcome to Hebei KN Wire Mesh Co., Ltd.
+86 177 3408 2565

Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m Anti Tank Wire

Basic Properties
Place of Origin: Hebei,China
Brand Name: Hebei KN
Certification: ISO CE
Model Number: KN-10X10X1.4
Trading Properties
Minimum Order Quantity: 350 PCS
Price: USD90-100 each pc
Standard Packaging: packages
Delivery Time: 7-10 days
Payment Terms: T/T, Western Union
Supply Ability: 100 pcs each month
Product Summary
Inconspicuous Obstacle Fence Security Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m Anti Tank Wire For Ukraine Barely noticeable obstacle 10х10х1.4m is designed to provide effective obstruction of movement and hinder the advancement of state border violators. It helps to create favorable ...

Product Details

Highlight:

10х10х1.4m Anti Tank Wire

,

Barely Noticeable Obstacle Fence

,

Ukraine Anti Tank Wire

Product Name: Barely Noticeable Obstacle 10х10х1.4m
Size: 10x10x1.4 10x5x1.4
Material: 70# Steel Wire
Wire Diameter: 0.5 0.6 0.8 0.9mm
Certification: ISO CE
Installation: Supply Video Tfor Help
MOQ: 350 PCS
Founction: Barrier Fence
Key Words: Anti-tank Barrier
Product Description

Inconspicuous Obstacle Fence Security Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m Anti Tank Wire For Ukraine

Barely noticeable obstacle 10х10х1.4m is designed to

provide effective obstruction of movement and hinder the advancement of state border violators. It helps to create favorable conditions for blocking and detention of offenders by border patrols and reserves, as well as

restricts the impact of animals and people on signaling and control equipment.



These products are available for purchase with a

floor space of 100 m² and a set weight of up to 24 kg

Safe and Effective Functionality

  • Effective Obstruction: Despite its inconspicuous nature, this obstacle serves as a reliable barrier, providing the necessary protection and separation in areas where safety is a priority.
  • Smooth Edges and Surfaces: Designed with safety in mind, it features smooth edges to prevent injuries, making it suitable for public spaces, including those frequented by children and the elderly.
Barely noticeable obstacle 10х10х1.4m
Name of indicators Indicators
Weight of the set up to 32 kg
Overall dimensions when folded:
length 1200 mm
width 600 mm
 height 120 mm
Overall dimensions in unfolded form:
Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire Area 100 m²
. Height 1,1 - 1,4 m
Number of garlands 25 - 30 pc.
Number of rows of garlands 4
Wire diameter 0,5 - 0,9 mm
The set includes 40 steel rings and 40 metal stakes
Warranty period:
Continuous operation 3 year
Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire Storage 5 year



Characteristics of the wire:

Barely noticeable obstacle is made of steel rope wire that

complies with DIN 2078, EN 10264-2, GOST 7372, with a

diameter of 0.5 to 0.9 mm.

Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire



1) Does the company have an export certificate? yes
2) Does the company already export to Ukraine? yes
3) How many employees? 820
4) In which year did the company open? 2018
5) What is the company's revenue? (please provide the proof document) CNY 71,550,000
6) Does the seller work for the company? How many years ago? yes, 7 years
7) Is the company bank account the same as the Proforma Invoice? yes, same
8) Is the proforma invoice in the company's system? yes
9) How much does the company export per year? (please provide the proof document) CNY 60,620,390
10) What is the company's packaging method? plastic film outside
11) Is the company a factory? Or trading company? yes, factory
12) What certifications does the company have? And the products? CE ISO



1.Description



Inconspicuous wire obstacle are intended to impede movement, hinder the advance and maneuver of violators of the state border, provide border units and reserves with favorable conditions for blocking and detaining them, limit the action of animals and people on signaling and control means. Inconspicuous obstacle Wire woven into rings into a garland. When opened, it forms a ground covering of wire garlands, which prevents people from entering the closed facilityInconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire

Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire





2.Detailed information



The wire ring connection will form a four-layer space grid with a height of 1.4 meters, a length of 10 meters and a width of 10 meters. The kit consists of 40 connecting rings with a diameter of 0.8 mm annealing wire manufactured as standard GOST 3282-74 and 40 metal posts (25 cm long). The folding size is 1.2 x 0.6K 0.12m.



Product name Anti-Tank Barrier Netting
Size 10*10*1.3 M
Brand name  Hebei KN
Weight  24KG each pc
Material Annealed steel wire



3.Production process



Secure the start of the 0.9 mm wire to one of the tubes at the start of a row.Lay a row of ramps in the correct direction, then return in the opposite direction following the pattern of laying the ramps to close the row of ramps.

Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire



4.Installation



Secure the start of the 0.9 mm wire to one of the tubes at the start of a row.Lay a row of ramps in the correct direction, then return in the opposite direction following the pattern of laying the ramps to close the row of ramps. Rewind the start of the wire secured to the tube (secured by winding) onto the last turn of the closed ramp. Do not cut the wire at the end of the row! Each row is braided with a single wire along all 20 layers!



1.Stretch two rows of coils to their full length


2.Lay out each row outward

3.Two rows should make four

4.To fix the coil with nails, you need to fix it with a thick coil with nails

5.Hold on to the propeller and move the wire sufficiently as shown in the picture.

6.By this move and stretch the bottom it will shows thick lines, thin lines will extend upward,after fix the outermost layer of coils.



Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank WireInconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire

How to install? Attention!



It is impossible to put it back together after unraveling, so it is important to perform all the steps correctly, from the beginning it can be installed on the ground, on the roof, on the fence, and requires 4 to 8 people. The thickest diameter wire should be at the bottom, the tangle fixed to the ground with staples every 1-2 meters, and the wrapped rings above it connected with hooks to raise the wire mesh upward and give it the volume it needs.

Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire



5. Our company



we establishedin 2013 is a professional manufacturer engagedin the research, development, production, saleand service of Wire Mesh Container. We arelocated in Anping county hengshui city withconvenient transportation access. Dedicated tostrict quality control and thoughtful customerservice, our experienced staff members arealways available to discuss your requirementsand ensure full customer satisfaction. Ourproducts are also exported to clients in suchcountries and regions as Britain France,Germany, USA, UK Kenya, Zambia,PhilippinesThailand,Korea, New Guinea,Greece, Mexico.We also welcome OEM and ODM orders. Ourcompany always insist on the quality strives forthe survival, to the credibility of development theobjective, wholeheartedly for the domestic andforeign customers, with quality products andfirst- class service and foreign customers, withquality products and first-class service.



Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire

Inconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank WireInconspicuous Obstacle Fence Security Wire Mesh Barrier MZP Tangle Barely Noticeable Obstacle 10х10х1.4m  Anti Tank Wire
