High Quality Electric Galvanized Razor Barbed Wire BTO22 450mmx10kg Per Roll

Large Image : High Quality Electric Galvanized Razor Barbed Wire BTO22 450mmx10kg Per Roll

Product Details:

Place of Origin:	Hebei,China
Brand Name:	KN
Certification:	ISO CE
Model Number:	KN-R06

Payment & Shipping Terms:

Minimum Order Quantity:	100 rolls
Price:	USD12.68-USD32.98
Packaging Details:	Customized
Delivery Time:	7-15 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	5000 pcs/week

Contact Now

Detailed Product Description

Concertina Cross Type:	Single Cross ( Without Clips)	Color:	Silver
Quality:	High, Top, Brand New	Coil Type:	Cross Type Concertina Wire
Razor Barb Spacing:	100±2mm	Barb Width:	13mm-32mm
Corrosionresistance:	High	Usage:	Security Fencing
Razor Blade Style:	Razor Blade Style	Barb Spacing:	26-100mm
Strand Structure:	Single Strand	Frame Material:	Metal
Alias:	Razor Wire Mesh Fence	Shape:	Spiny
Rollweight:	15 Kg
Highlight:	electric galvanized razor barbed wire , BTO22 razor barbed wire roll , 450mm razor barbed wire with warranty

High Quality Electric Galvanized Razor Barbed Wire BTO22 450mmx10kg Per Roll

Product description

Razor barbed wire scurity fencing

Razor barbed wire is also named concertina coils or razor type barbed wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With beautiful and sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
Razor type barbed wire is widely used in high-grade residence district, warehouses and other sites requiring severe fencing and security. Razor wire can be classified into straight type razor wire, concertina coils, crossed type and flat type according to the installation models.

High Quality Electric Galvanized Razor Barbed Wire BTO22 450mmx10kg Per Roll 0

High Quality Electric Galvanized Razor Barbed Wire BTO22 450mmx10kg Per Roll 1

Product Details

Razor Blade Style and Specs
Reference Number	Blade Thickness	Wire Dia	Blade Length	Blade Width	Blade Spacing
BTO-10	0.5±0.05	2.5±0.1	10±1	13±1	26±1

BTO-12	0.5±0.05	2.5±0.1	12±1	15±1	26±1

BTO-18	0.5±0.05	2.5±0.1	18±1	15±1	33±1

BTO-22	0.5±0.05	2.5±0.1	22±1	15±1	34±1

BTO-28	0.5±0.05	2.5	28	15	45±1

BTO-30	0.5±0.05	2.5	30	18	45±1

CBT-60	0.6±0.05	2.5±0.1	60±2	32±1	100±2

CBT-65	0.6±0.05	2.5±0.1	65±2	21±1	100±2

Barbed Tape Wire Specification
Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
500mm	56	12-13M	CBT-60.65	Single coil
700mm	56	13-14M	CBT-60.65	Single coil
960mm	56	14-15M	CBT-60.65	Single coil
450mm	56	8-9M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
500mm	56	9-10M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
600mm	56	10-11M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
600mm	56	8-10M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
700mm	56	10-12M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
800mm	56	11-13M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
900mm	56	12-14M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
960mm	56	13-15M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
980mm	56	14-16M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type

High Quality Electric Galvanized Razor Barbed Wire BTO22 450mmx10kg Per Roll 2

Security Fencing System Type One: Anti-Climb Razor Mesh High Security Fence

Razor Mesh Security Fence is a multi-functional, high security mesh fencing made of straight-blade netting welded together.
Anti-climb fence with flat panel of crossed razor wire welded mesh in diamond or oblong square holes. The razor mesh fencing is virtually impossible to climb or cut without standard tools. The diamond pattern or square pattern combined with vertical opposing barbs act as an entrapment while retaining a neat appearance. The welded blade barrier is designed for commercial, government and safety uses.
Materials of razor mesh:
Stainless steel, hot dipped galvanized steel or pvc coated steel.
The benefits of Welded Razor Wire Fence:
Anti-climb;
High-strength steel core very difficult to cut off;
Powerful security fence barriers with neat appearance;
Packed in rolls easy for transport;
Extremely simple to install.
Types according to surface treatment:

1. Stainless Steel High Security Fence Panels

2. Hot Dipped Galvanised Anti-Climb Fence

3. Plastic Powder Coated Steel Mesh Security Fencing

Common Sizes:
Welded Diamond Mesh size : 75x150mm, 100x200mm, 150x300mm
Oblique Square mesh size : 150mm, 200mm, 300mm
The rectangular mesh size: 100mmx150mm
Uses:
Razor Mesh is installed as high security fencing throughout the world at airports, water reservoirs, warehouses,
electrical sub-stations, border fences, oil depots, electrical sub-stations and factories.
