Product Details:
Payment & Shipping Terms:
|
| Material: | Steel Wire, HDP Galvanized Sheet | Surface Treatment: | Hot Dipped Galvanized, Stainless Stell |
|---|---|---|---|
| Using Life: | Above 10 Years | Application: | Border Protection Fence, Prision Fence |
| Razor Type: | Single Razor, Cross Type, Flat Type | Sample: | Free |
| Type: | BTO-22, BTO-16, BTO-18, CBT-65, CBT-30 | Package: | Wooden Pallet, Water Proof Paper |
| Outer Diameter: | 45-110mm | Stock: | 8 Containers |
| Highlight: | stainless steel razor barbed wire,military anti-climb fence wire,BTO 22 razor barbed wire |
||
Cross Type Stainless Steel BTO 22 Razor Barbed Wire for Military Anti-Climb Fence
As a high-performance security barrier specially designed for military anti-climb scenarios, the Cross Type Stainless Steel BTO 22 Razor Barbed Wire integrates extreme deterrence, super durability and easy installation. It is made of high-quality stainless steel materials and adopts a scientific cross-type structure, which can form an impenetrable protective line for military camps, border posts, military bases and other key security areas, effectively resisting climbing, cutting and other illegal intrusion behaviors, and safeguarding the safety of military facilities and personnel.
![]()
<img alt="" src="
Core Advantages: Temporary, Recyclable & Easy-Install
Specification:
| Reference Number |
Thickness (mm) |
Wire Dia (mm) |
Bard Length (mm) |
Bard Width (mm) |
Bard Distance (mm) |
| BTO-10 | 0.5±0.05 | 2.5±0.05 | 10±1 | 13± | 16±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.05 | 12±1 | 15±1 | 26±1 |
| BTO-16 | 0.5±0.05 | 2.5-2.8 | 16±1 | 19±1 | 30±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.05 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.05 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5±0.05 | 28±1 | 15±1 | 53+1 |
| BTO-30 | 0.5±0.05 | 2.5±0.05 | 30±1 | 21±1 | 54±1 |
| CBT-60 | 0.5±0.05 | 2.5±0.05 | 60±1 | 32±1 | 100±1 |
| CBT-65 | 0.5±0.05 | 2.5±0.05 | 65±1 | 21±1 | 100±2 |
Razor Barbed Wire Coil and Unit Loops
| Outside Diameter | No.of Loops | Standard Length Per Coil | Type | Notes |
| 450mm | 33 | 8M | CBT-65 | Single coil |
| 500mm | 41 | 10M | CBT-65 | Single coil |
| 700mm | 41 | 10M | CBT-65 | Single coil |
| 960mm | 53 | 13M | CBT-65 | Single coil |
| 500mm | 102 | 16M | BTO-10.15.22 | Cross type |
| 600mm | 86 | 14M | BTO-10.15.22 | Cross type |
| 700mm | 72 | 12M | BTO-10.15.22 | Cross type |
| 800mm | 64 | 10M | BTO-10.15.22 | Cross type |
| 960mm | 52 | 9M | BTO-10.15.22 | Cross type |
Types of Razor Wire:
Razor Wire Fence
Concertina Razor Coils
Razor Wire Flat Wrap Coils
Welded Razor Wire
Razor Ribbon
Razor Wire Mobile Security Barrier
Galvanized Razor Wire
Straight Line Razor Wire Fence
Stainless Steel Razor Wire
Razor Wire Concertina
Double Concertina Razor Wire
Details of Razor Wire:
![]()
![]()
![]()
Workshop:
![]()
Above is our No.3 workshop, producing BTO-16, Packed with wooden box. daily output is 1/40HQ.
Packing & Delivery:
1. sheet is packed by pallet or strapped into bundle.
2. sheet in carton or wooden case.
3. rolls in water-proof paper+plastic film.
![]()
![]()
Razor Wire and Perimeter Security:
Detection at the perimeter enables security personnel to quickly assess and respond to security events while intruders remain delayed or caught up in the razor wire. Any attempt to cut, bypass or disturb the razor wire is immediately detected.
![]()
