Heavy Duty Razor Wire BTO-22 CBT-65 Concertina Razor Barbed Wire For Perimeter Security Fence

Heavy Duty Razor Wire BTO-22 CBT-65 Concertina Razor Barbed Wire For Perimeter Security Fence

Large Image :  Heavy Duty Razor Wire BTO-22 CBT-65 Concertina Razor Barbed Wire For Perimeter Security Fence

Product Details:
Place of Origin: CN
Brand Name: KN
Certification: CE ISO SGS COC PVOC
Model Number: KN- Razor Barbed Wire
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: USD 900-1000
Packaging Details: pallet
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50 ton day
Detailed Product Description
Product Name: Heavy Duty Razor Wire BTO-22 CBT-65 Concertina Razor Barbed Wire For Perimeter Security Fence Key Words: Razor Barbed Wire
Blade Thickness: 0.5mm, 0.6mm, 0.7mm, 0.8mm, 0.9mm, 1.0mm, Etc. Outside Diameter: 450mm - 980mm
Barb Width: 13mm-32mm Size: BTO-12 BTO-15 BTO-22 BTO-30 BTO-65
Type: Barbed Wire Coil, Razor Wire Mesh Wire Material: Hot Dipped Galvanized Wire
Certificat: Iso9001-2000 Surface: Galvanized/PVC Coated

Heavy Duty Razor Wire BTO-22 CBT-65 Concertina Razor Barbed Wire For Perimeter Security Fence



Product Overview

Our Heavy-Duty Concertina Razor Wire (BTO-22 & CBT-65) represents the pinnacle of physical perimeter security. Designed to prevent trespassing, scaling, and intrusions, this razor-sharp barbed wire creates an impassable visual and physical barrier. Formed by clipping adjacent loops of spiral razor wire together at regular intervals, it expands into a rigid, three-dimensional Concertina (scissored) structure that is virtually impossible to cut or penetrate without specialized industrial equipment.

Whether you need the standard efficiency of BTO-22 or the extreme psychological and physical deterrence of the long-blade CBT-65, our products ensure maximum security for high-risk zones.


Wire diameter
2mm 2.5mm 2.8mm ( customized )
Thickness
0.5 mm - 0.6 mm.
Razor length
12 mm - 21 mm.
Razor width
13 mm - 21 mm.
Barb spacing
26 mm - 100 mm.
Outside diameter
450 mm - 960 mm.
Number of loops
33 mm - 102 mm.
Standard length per coil
8 m - 16 m.
Razor barbed types
Single coil and cross type.
Outside Diameter
No. of Loops
Standard Length per Coil
Type
Notes
450mm
33
7-8m
CBT-60/65
Single coil
500mm
56
12-13m
CBT-60/65
Single coil
700mm
56
13-14m
CBT-60/65
Single coil
960mm
56
14-15m
CBT-60/65
Single coil
450mm
56
8-9m
BTO-12/22/25/30
Cross type
500mm
56
9-10m
BTO-12/22/25/30
Cross type
600mm
56
10-11m
BTO-12/22/25/30
Cross type
600mm
56
8-10m
BTO-12/22/25/30
Cross type
700mm
56
10-12m
BTO-12/22/25/30
Cross type
800mm
56
11-13m
BTO-12/22/25/30
Cross type
900mm
56
12-14m
BTO-12/22/25/30
Cross type
960mm
56
13-15m
BTO-12/22/25/30
Cross type
980mm
56
14-16m
BTO-12/22/25/30
Cross type



Features & Advantages

  • High Tensile Core Wire: The internal core wire uses 2.5mm high-tensile steel wire. It cannot be easily cut with standard hand tools and prevents the wire from sagging over time.

  • Corrosion & Weather Resistance: Heavily galvanized ($120-275text{g/m}^2$) or wrapped in stainless steel, our razor wire resists rust, acid rain, and extreme UV exposure, offering a service life exceeding 10-15 years.

  • Concertina Scissor Action: Loops are securely linked via heavy-duty steel clips. When expanded, it forms a dense, interlocking cylindrical mesh that eliminates any gaps for intruders to squeeze through.

  • Imposing Deterrence: The aggressive visual profile alone stops most intrusion attempts before they even start.

Technical Layout & Structural Options

Depending on your security requirements, our razor wire can be deployed in two distinct loop structures:

  • Crossed Type (Concertina): Adjacent loops are joined by stainless steel clips. When opened, they form an intersecting diamond-patterned cylinder. This is the heavy-duty option recommended for high security.

  • Single Coil Type: The wire runs in a simple spiral without clips. It offers a larger coverage area per roll but lower structural rigidity (best for standard low-risk perimeters).

Applications

  • Military Installations & Border Control

  • Prisons, Correctional Facilities & Detention Centers

  • Industrial Plants, Warehouses & Commercial Depots

  • Power Plants, Substations & Critical Infrastructure

  • Residential Property Wall Reinforcement (Topped on Chain Link or Welded Mesh)

Packaging & Delivery

Each roll is tightly compressed and securely wrapped with moisture-proof paper inside and a woven bag outside to prevent accidental damage during transit and handling.

Handles/cardboard accents can be customized upon wholesale request for safer unloading.

Heavy Duty Razor Wire BTO-22 CBT-65 Concertina Razor Barbed Wire For Perimeter Security Fence 0
