Turkey PVC Coated 3*3*0.3m Gabion Mattress for River Bank Protection Wall

China Hebei KN Wire Mesh Co., Ltd. certification
China Hebei KN Wire Mesh Co., Ltd. certification
A very effective defensive barrier. Julia's service was excellent. She helped me solve many problems related to products and transportation.The journey to the factory was also very enjoyable.

—— David

A perfect after-sales service experience. I'm very grateful that Cora came to my company to solve my problem on-site.

—— Gabriel

The goods received are excellent and match the products I saw in the factory. I also had a pleasant experience with Lisa's reception.

—— Ranbir

A very good purchasing experience. The sales service level of melody is top-notch, and it helped me solve many problems.

—— Aydan

I would like to express my deepest gratitude to Cora for her warm hospitality. This was a very pleasant trip to China, and it has been of great help to me.

—— James

Product received on time. Product quality is good. costumer service is very accommodating. hassle free transaction. will not hesitate to order again next time.

—— Ventas

The quality is reliable! Thanks.Product received on time.

—— Buena

Great Seller!!!!! Working with you is very reassuring, don't worry about any quality problems.

—— Peter

I have been very happy and trustworthy suppliers for many years.

—— Sworld

A very good cooperation experience. The good product has enabled my project to proceed more smoothly.

—— Theodore

A perfectly seamless transaction experience. The service provided by KN is truly outstanding.

—— Matthew

I'm Online Chat Now

Turkey PVC Coated 3*3*0.3m Gabion Mattress for River Bank Protection Wall

Turkey PVC Coated 3*3*0.3m Gabion Mattress for River Bank Protection Wall

Large Image :  Turkey PVC Coated 3*3*0.3m Gabion Mattress for River Bank Protection Wall

Product Details:
Place of Origin: HB
Brand Name: KN
Certification: ISO, CE, SASO,CO,COC,PVOC
Model Number: KN-Gabion
Payment & Shipping Terms:
Minimum Order Quantity: 10000 ㎡
Price: Negotiated
Packaging Details: In Bundle or According to Customer Request
Delivery Time: 15 Working Days
Payment Terms: L/C, T/T, Western Union, , Trade Assurance, Paypal
Supply Ability: 5000 Tons per year
Detailed Product Description
Material: Hot Dipped Galvanized Wire, Galfan Wire Lacing Wire: 2.2mm, 2.4mm
Technology: Woven Surface Treatment: Hot Dipped Galvanized
Mesh Wire: 2.2mm To 3.0mm Selvedge Wire: 2.2mm To 2.7mm
Prodcution: 5 Container Per 7 Days Sample: Free
Daily Output: 10000 Sq.mt Package: Compress In Bundle To Save Space
Stock Size: 2*1*1m, 3*1*1m, Production Lines: 12 Lines
Highlight:

PVC coated gabion mattress

,

3x3m river bank protection wall

,

Turkey gabion box with warranty

Turkey PVC Coated 3*3*0.3m Gabion Mattress for River Bank Protection Wall​



This gabion box mattress strictly follows the commonly used engineering specifications in Turkey, with a standard dimension of 3*3*0.3m, which is convenient for on-site splicing, laying and rapid construction. The overall structure adopts double-twisted hexagonal mesh weaving technology, the mesh is uniform and firm, the steel wire has strong tensile toughness, and it will not loose or deform after filling natural stones. The thickened outer PVC layer improves wear resistance and anti-aging performance, adapting to the high-temperature sun exposure and rainy season soaking environment in Turkey’s Mediterranean and Black Sea coastal areas. The product has excellent water permeability, which can realize natural water and soil exchange, protect river ecological environment, and avoid wall collapse caused by water accumulation, greatly improving the safety and durability of river bank retaining walls.



Wire Thickness Specification:

Mesh type 8*10cm 6*8cm
Characteristics Metallic coated PVC coated Metallic coated PVC coated
Mesh openings 83mm x 114mm 83mm x 114mm 64mm x 83mm 64mm x 83mm
Mesh wire 2.7mm (0.106 in.) 3.05mm( 0.120 in.) 2.2mm (0.087 in.) 2.2mm (0.087 in.)
Selvage wire 3.4mm (0.134 in.) 3.8mm (0.150 in.) 2.7mm (0.105 in.) 2.7mm (0.105 in.)
Lacing wire 2.2mm (0.087 in.) 2.2mm (0.087 in.) 2.2mm (0.087 in.) 2.2mm(0.087 in.)



Size of Gabion Box:



Opening(mm)

Wire Diameter(Metal Wire)

mm

Wire Diameter (PVC Coated)

Inner/Outside(mm)

Strands
60X80 2.0-2.8 2.0/3.0-2.5/3.5 3
80X100 2.0-3.2 2.0/3.0-2.8/3.8 3
80X120 2.0-3.2 2.0/3.0-2.8/3.8 3
100X120 2.0-3.4 2.0/3.0-2.8/3.8 3
100X150 2.0-3.4 2.0/3.0-2.8/3.8 3
120X150 2.0-4.0 2.0/3.0-3.0/4.0 3



Size of Gabion Mattress:



Size Notes
Length(mm) Width(mm) Height(mm) Unit volume(m³)
2.00 1.00 0.30 1 0.60
3.00 1.00 0.30 2 0.90
4.00 1.00 0.30 3 1.20
2.00 1.00 0.50 1 1.00
3.00 1.00 0.50 2 1.50
4.00 1.00 0.50 3 2.00
1.00 1.00 1.00 0 1.00
1.50 1.00 1.00 0 1.50
2.00 1.00 1.00 1 2.00
3.00 1.00 1.00 2 3.00
4.00 1.00 1.00 3 4.00



Wide Application Scenarios

  • Turkey river bank retaining wall reinforcement and river slope anti-erosion protection
  • Reservoir, water channel and lake water conservancy anti-scour engineering
  • Black Sea coastal tidal flat protection and salt-fog corrosion resistance project
  • Highway and railway side slope stabilization and anti-collapse protection
  • Urban ecological water system renovation and landscape river protection works

One-Stop Customized Service

In addition to standard 3*3*0.3m Turkish-size gabion mattresses, we support personalized customization of wire diameter, mesh size, coating thickness, color and product size for all gabion box products. We provide free professional engineering solution consultation, parameter matching and construction suggestion guidance for Turkish customers. From order confirmation, production inspection, logistics tracking to after-sales technical support, we provide full-cycle one-stop service to help customers reduce project costs and improve construction efficiency.



Turkey PVC Coated 3*3*0.3m Gabion Mattress for River Bank Protection WallTurkey PVC Coated 3*3*0.3m Gabion Mattress for River Bank Protection WallTurkey PVC Coated 3*3*0.3m Gabion Mattress for River Bank Protection Wall
