Geotextile Lined Military Defensive Barriers Bastions For Police Training Centre

Geotextile Lined Military Defensive Barriers Bastions For Police Training Centre
Geotextile Lined Military Defensive Barriers Bastions For Police Training Centre Geotextile Lined Military Defensive Barriers Bastions For Police Training Centre Geotextile Lined Military Defensive Barriers Bastions For Police Training Centre

Large Image :  Geotextile Lined Military Defensive Barriers Bastions For Police Training Centre

Product Details:
Place of Origin: HB
Brand Name: SHUXIN
Certification: CE, ISO, SGS, SASO, PVOC,COC, FM A, FM E, CO
Model Number: SHUXIN-Training
Payment & Shipping Terms:
Minimum Order Quantity: 50 UNIT
Price: Negotiated
Packaging Details: Wooden Pallet
Delivery Time: 15 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram,Paypal, T/A
Supply Ability: 200 Units per week

Geotextile Lined Military Defensive Barriers Bastions For Police Training Centre

Description
Raw Material: Low Carbon Steel Iron Wire Geotextile: 250 G/㎡ Or 300 G/㎡ Standard
Sample: Free In Small Sample Apeture: 3" (76.2mm×76.2mm)
Color: Beige Color ( Have Colour Difference) Surface Treatment: Hot Dipped Galvanized
High Light:

defence barrier

,

bastion barrier

Welded Stackbale Geotextile Lined Defensive Barrier Bastaions Wall for Police Training Centre



Defensive Barrier Bastions is constituted by Welded Mesh Panel, helical Wire and non-woven geotextile cloth.Which assembled together form a rectangle wire mesh container. It can filled with sand, earth, stone to heavy its weight to stand against the impact. Nowadays, more and more people accept the Military Defensive Bastion as protection fence.



Military Defensive Bastion are mainly used in military and flood control for its modular structure and quick setup. For military, a gabion Box with 24 inches thickness can stop rifle bullets, shell fragments and other shrapnel. While for flood protection, gabion Basket can be assembled soonest and come into use.



Brief Introduction for Defensive Barrier Bastion Wall:



Material: Galvanized steel wire or Galfan / zinc-5%aluminum wire

Service Life: 15-20 years

Wire diameter: 3.0mm- 6.0mm

Aperture: 3" (76.2mm × 76.2mm ) Standard

Color of geotextile: Grey and Military, Beige, Sand Color and so on.

Weight of Geotextile: 250 g/m2 or 300 g/m2

Finish:hot dipped galvanized,Galfan wire.

Welded method:welded after galvanized or galvanized after welded



The Standard Technical Specifications from SX 1 to SX 19



Welded Military Gabion Box
Model Height Width Length
SX-1 54"(1.37M) 42"(1.06M) 32'9"(10M)
SX-2 24"(0.61M) 24"(0.61M) 4'(1.22M)
SX-3 39"(1.00M) 39"(1.00M) 32'9"(10M)
SX-4 39"(1.00M) 60"(1.52M) 32'9"(10M)
SX-5 24"(0.61M) 24"(0.61M) 10'(3.05M)
SX-6 66"(1.68M_ 24"(0.61M) 10'(3.05M)
SX-7 87"(2.21M) 84"(2.13M) 91'(27.74M)
SX-8 54"(1.37M) 48"(1.22M) 32'9"(10M)
SX-9 39"(1.00M) 30"(0.76M) 30'(9.14M)
SX-10 87"(2.21M) 60"(1.52M) 100'(32.50M)
SX-11 48"(1.22M) 12"(0.30M) 4'(1.22M)
SX-12 84"(2.13M) 42"(1.06M) 108'(33M)
SX-19 108"(2.74M) 42"(1.06M) 10'5"(3.18M)



The Application for Military Defensive Barrier Bastions



Flood Control

1. Flood Prevention Barrier

    From a simple perimeter wall to a complex base infrastructure, SHUXIN products provide rapid expeditionary protection

2. Permanent or Semi-permanent Dike

    Welded Gabion Barriers can as the Dike against the Flood permanently or Semi-Permanently.

3. Flood Control Retaining Wall

    Wiht sand and earth in it, Defensive Barrier can as a retaining Wall to against the flood.

4. Protection Engineering of Seaside Area

    Military Gabion Barrier is more and more homemade at the seaside area as Protection Fence

5. Protecting Existing Structures

6. Coastal Erosion Control



The Advantages of  Deensive Barrier Bastion Wall:



1. Lifetime

    The unit must be made of a Wire Mesh basket which is manufactured from Galvanised coated, welded mesh. The mesh must be made of rust protected alloy materials.The Wire Mesh must have a guaranteed life of not less than 5 years while exposed to environment and 10 years when in store.



2. Collapsible

    Mesh Panel is joint by spring which is a circle, Mesh Panle can turn 360° unobstructed, so, when shiping the goods, it is collapsible to save space.



3. Strong Protection

    Thickner Mesh Panle together with thickner geotextile combined a strong Protection wall.



4. Fast and Simple Operation

    A security wall using Sand earth-filled barrier can be filled by two persons and a standard front-end loader in just 20 minutes, the equivalent sized wall of 1,500 sandbags will take 10 persons up to 7 hours to fill and build.
