Product Details:
|
| Mesh Hole:: | 3''*3'' | Material: | Hot Dipped Galvanized Wire |
|---|---|---|---|
| Hole Shape: | Square | Advantage: | Easy Assembled |
| Color: | White, Sand Color, Military Green | Diameter Of Spring:: | 4.00mm |
| High Light: | edge protection hesco blast walls,heavy zinc coating hesco blast walls,4.00mm hesco blast walls |
||
Easy To Install Heavy Zinc-Coating Defensive Barrier For Edge Barrier Protection
Introduction of Military Barriers :
Defensive Barrier Wall, also known as explosion-proof walls and flood-proof walls, are made of welded gabion nets and geotextiles, which are sewn and can hold fine sand, soil and stones can replace traditional military bunker sandbags, and can be recycled. product. Different from traditional gabion nets (stone baskets), it can not only contain stones, but also finer sand.
The filling materials are made on-site, which is especially suitable for use in the lower reaches of rivers or beaches where there is a lack of stone. With the help of advanced tools such as excavators and forklifts, the installation efficiency is dozens or even hundreds of times that of traditional sandbags. It can be used as military equipment and can be used for temporary bunkers, fortresses, and pre-war headquarters to replace traditional artificial trenches, effectively reducing soldiers and personnel casualties.
Defensive Barrier Wall specification:
| Model | Height | Width | Length | Internal Cells |
| SX-1 | 54”(1.37m) | 42”(1.06m) | 32’9”(10m) | 5+4=9 cells |
| SX-2 | 24”(0.61m) | 24”(0.61m) | 4’(1.22m) | 2 cells |
| SX-3 | 39”(1.0m) | 39”(1.0m) | 32’9”(10m) | 5+5=10 cells |
| SX-4 | 39”(1.0m) | 60”(1.52m) | 32’9”(10m) | 5+5=10 cells |
| SX-5 | 24”(0.61m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| SX-6 | 66”(1.68m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| SX-7 | 87”(2.21m) | 84”(2.13m) | 91’(27.74m) | 5+4+4=13 cells |
| SX-8 | 54”(1.37m) | 48”(1.22m) | 32’9”(10m) | 5+4=9 cells |
| SX-9 | 39”(1.0m) | 30”(0.76m) | 30’(9.14m) | 6+6=12 cells |
| SX-10 | 87”(2.21m) | 60”(1.52m) | 100’(30.5m) | 5+5+5+5=20 cells |
| SX-11 | 48”(1.22m) | 12”(0.30m) | 4’(1.22m) | 2 cells |
| SX-12 | 84”(2.13m) | 42”(1.06m) | 108’(33m) | 5+5+5+5+5+5=30 cells |
| SX-19 | 108”(2.74m) | 42”(1.06m) | 10’5”(3.18m) | 6 cells |
Defensive Mesh gabion box Application:
Perimeter Security and Defence Wall
Equipment Revetments
Personnel and Material Bunkers
Observation Points
Defensive Firing Positions
Guard Posts
Explosives and Contraband Search Areas
Highway Checkpoints
Border Crossing Checkpoints
Protecting Existing Structures
Flood control retaining wall
Coastal Erosion
Protection engineering of seaside area.
Defensive Barrier Wall advantage
1.Defensive Barrier Wall that has the ability to resist explosion shock waves and can limit the destructive effects of explosions within a certain range.
2.Compared with the reinforced concrete explosion-proof wall, it has the advantages of light weight, easy loading and unloading, recyclable and reusable.
3.The Defensive Barrier cage produced by our company has as many as 12 specifications, in various colors such as earthy gray, earthy yellow, grass green, etc., and can be flexibly combined to apply to different scenes or purposes.
