Product Details:
|
| Usage: | Civil, Military | Geotextile: | Heavy Duty Non-Woven Polypropylene, Color Can Be W |
|---|---|---|---|
| Brand Name: | Shuxin | Tensile Strength: | 16kN |
| Application: | Gabion Mesh, Gabions, Construction Wire Mesh | Hole Shape: | Square |
| Spring Wire Diameter: | 3mm-5.0mm | Tear Strength: | 0.42kN |
| Name 2: | Hesco Defense Wall | Technics: | Welded |
| Surface Treatment: | Galvanized, Galfan Coated | Packing: | Wrapped With Shrink Film Or Packed In Pallet |
| High Light: | hesco defensive barrier,galfan defensive barrier,hesco defensive military barrier |
||
Galfan or Galvanized Military Hesco Barrier Hesco Bastion Welded Gabion Army Defensive Bastion Army Bastion
Product feature:
1.Units can be both lined or unlined in other word it can be used together to any length, and can be stacked for
additional height.
2. The spiral hinged corners allows flat packing for ease of transportation
3. The welded mesh frame is of highly durable construction
4. The Galfan coated welded mesh frame is ideal for containing large amounts of the geavy fill material that
gives the system its strength.
5. The non-woven geotextile liner allowing a wide range of fill material
|
SHUXIN MIL1
|
54''(1.37m)
|
42''(1.06m)
|
32'9''(10m)
|
1*4+1*5 cells
|
|
SHUXIN MIL2
|
24''(0.61m)
|
24''(0.61m)
|
4'(1.22m)
|
2 cells
|
|
SHUXIN MIL3
|
39''(1.00m)
|
39''(1.00m)
|
32'9''(10m)
|
2*5 cells
|
|
SHUXIN MIL4
|
39''(1.00m)
|
60''(1.52m)
|
32'9''(10m)
|
2*5 cells
|
|
SHUXIN MIL5
|
24''(0.61m)
|
24''(0.61m)
|
10'(3.05m)
|
5 cells
|
|
SHUXIN MIL6
|
66''(1.68m)
|
24''(0.61m)
|
10'(3.05m)
|
5 cells
|
|
SHUXIN MIL7
|
87''(2.21m)
|
84''(2.13m)
|
91'(27.74m)
|
2*4+1*5 cells
|
|
SHUXIN MIL8
|
54''(1.37m)
|
48''(1.22m)
|
32'9''(9.14m)
|
1*4+1*5 cells
|
|
SHUXIN MIL9
|
39'(1.00m)
|
30''(0.76m)
|
30'(9.14m)
|
2*6 cells
|
|
SHUXIN MIL10
|
87''(2.21m)
|
60''(1.52m)
|
100'(30.5m)
|
4*5 cells
|
|
SHUXIN MIL11
|
48''(1.22m)
|
12''(0.3m)
|
4'(1.22m)
|
4 cells
|
|
SHUXIN MIL12
|
84''(2.13m)
|
42''(1.06m)
|
108'(33m)
|
6*5 cells
|
|
SHUXIN MIL19
|
108''(2.74m)
|
42''(1.06m)
|
10'5''(3.18m)
|
3 cells
|
Brief description:
Mesh gabion is also known as gabion barrier, gabion concertainer. It is made of steel welded mesh, spring coil, non-woven geotextile with other fittings to make a simple and strong multi-cellular system.
The finish of barrier is in pre galvanized,galfan coated,hot dipped galvanized to anti corrosion for long lifespan. The barrier is easy to move and install, so it is widely used in military defensive blast wall, flood control, erosion control, security fence barrier and garden decoration.
The hesco bastion is a modern gabion primarily used for flood control and military fortifications. It is made of a collapsible wire mesh container and heavy duty fabric liner, and used as a temporary to semi-permanent levee or blast wall against explosions or small-arms. It has seen considerable use in Iraq and Afghanistan,Dominican Republic, Afghanistan, Iraq, USA, France, Kenya, Iran, Saudi Arabia, Italy, Germany.Pakistan, Kazakhstan, Mali, Burkina Faso, Ghana, Mozambique
Specification:
| Port: | Tianjin, China |
|---|---|
| Production Capacity: | 300sets Per Day |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Material: | Galvanized Steel Wire |
|---|---|
| Application: | Gabion Mesh, Gabions, Construction Wire Mesh |
| Hole Shape: | Square |
| Usage: | Military Applications |
| Technics: | Welded |
| Surface Treatment: | Galvanized |
Material : galvanized wire,hot dipped galvanized wire,hot dipped galvanized after welding,galfan steel wire , Alu-zinc coated wire.
mesh wire diameter : 3mm,4mm,5mm,6mm and so on .
Mesh hole Size :50x50mm, 75x75mm, 76.2x76.2mm, 50x100mm, 100x100mm, as your request .
Spring wire diameter : 3mm,4mm,5mm,6mm etc .
army bastion Finished : Hot dipped galvanized and galfan .
steel wire barriers Geotextile : In heavy duty non-woven polypropylene .
steel wire barriers Geotextile color : beige-sand, olive green,gray etc .
steel wire barriers Geotextile thickness : 300g/m2, 350g/m2, 400g/m2 .
common size : 0.61x0.61x0.61m 2Cells, 1x1x1m 10Cells, 1.37x1.06x1.06m 9Cells, 1x1.5x1m 10Cells, 0.61x0.61x0.61m 5Cells, 1.68x0.61x0.61m 5Cells, 2.21x2.13x2.13m 13Cells, 1.37x1.22x1.10m 9Cells as your request .
Package: Warapped with shrink film then packed in pallet,and the last packed with steel belt .
Application:
∗Perimeter Security and Defence Walls,
∗Equipment Revetments,
∗ garden landscaping decorative
∗Personnel and Material Bunkers, Observation Points, Defensive Firing Positions
∗Guard Posts, Explosives and Contraband Search Areas, Highway Checkpoints,
∗Border Crossing Checkpoints, Protecting Existing Structures, Flood control retaining wall
∗Coastal Erosion, Protection engineering of seaside area.
Export term:FOB Tianjin port
CIF Port
Package:Wrapped with Shrink Film or Packed in Pallet
