Product Details:
|
| Material: | Galvanized Iron Wire | Application: | Explosive And Contraband Search Areas |
|---|---|---|---|
| Useful: | Ammunition Compounds | Usage: | Personnel And Material Bunkers |
| Defensive Firing Positions: | Defensive Firing Positions | Geotextile: | 300-350g/Sqm In Beige Or Green Color |
| High Quality: | Highway Checkpoints | Feature: | Flood Control |
| Obsercation: | Obsercation Points | Protection: | Existing Structures |
| Way Traffic Management: | High | Shipping Time: | 1-5 Work Days |
| High Light: | military hesco fence,galfan hesco fence,hesco fence mil6 |
||
Galfan Military Hesco Barrier Hesco Bastion Welded Gabion Army Defensive Bastion Army Bastion Hesco Defensive
Useful
Control and guide of water or flood.
Flood bank or guiding bank.
Security Barrier and Defence Wall
Water and soil protection.
Bridge protection.
Strengthening structure of soil.
Protecting engineering of seaside area.
The hesco bastion is a modern gabion primarily used for flood control and military fortifications. It is made of a collapsible wire mesh container and heavy duty fabric liner, and used as a temporary to semi-permanent levee or blast wall against explosions or small-arms. It has seen considerable use in Iraq and Afghanistan,Dominican Republic, Afghanistan, Iraq, USA, France, Kenya, Iran, Saudi Arabia, Italy, Germany.Pakistan, Kazakhstan, Mali, Burkina Faso, Ghana, Mozambique
Specification:
| Wire diameter | 3.85mm,4mm,5mm etc |
| Mesh Size | 75mmx75mm etc |
| Spring wire diameter | 3mm,4mm,5mm etc |
| Panel Finish | Hot dipped galvanized or Galfan coated |
| Geotextile | Heavy duty non-woven polypropylene, color can be white, beige-sand, olive green, etc |
| Packing Wrapped with shrink film or packed in pallet | |
| Technical Specification for Geotextile Fabric | |
| Color | Beige sand,Olive green,Grey |
| Mass(g/sqm) | 250,300,350 |
| Tensile strength | 16kN |
| Tear Strength | 0.42kN |
| CBR Puncture | 3.1kN |
|
UV strength retention
ASTM D4355
|
50% at 500hours (5 years use life in common environment) |
| 70% at 500hours (10 years use life in common environment) |
|
Trade Item
Delivery Terms:FOB, CIF
Payment Currency:USD, EUR, AUD,JPY, CAD, GBP, CNY
Payment Item:T/T, L/C, PayPal, Escrow
Nearest Port:Xingang port,Qingdao port
Delivery Time:General after 25days upon received T/T30% advance payment
Describe
Mesh gabion is also known as gabion barrier, gabion concertainer. It is made of steel welded mesh, spring coil, non-woven geotextile with other fittings to make a simple and strong multi-cellular system.
The finish of barrier is in pre galvanized,galfan coated,hot dipped galvanized to anti corrosion for long lifespan. The barrier is easy to move and install, so it is widely used in military defensive blast wall, flood control, erosion control, security fence barrier and garden decoration.
|
SHUXIN MIL1
|
54''(1.37m)
|
42''(1.06m)
|
32'9''(10m)
|
1*4+1*5 cells
|
|
SHUXIN MIL2
|
24''(0.61m)
|
24''(0.61m)
|
4'(1.22m)
|
2 cells
|
|
SHUXIN MIL3
|
39''(1.00m)
|
39''(1.00m)
|
32'9''(10m)
|
2*5 cells
|
|
SHUXIN MIL4
|
39''(1.00m)
|
60''(1.52m)
|
32'9''(10m)
|
2*5 cells
|
|
SHUXIN MIL5
|
24''(0.61m)
|
24''(0.61m)
|
10'(3.05m)
|
5 cells
|
|
SHUXIN MIL6
|
66''(1.68m)
|
24''(0.61m)
|
10'(3.05m)
|
5 cells
|
|
SHUXIN MIL7
|
87''(2.21m)
|
84''(2.13m)
|
91'(27.74m)
|
2*4+1*5 cells
|
|
SHUXIN MIL8
|
54''(1.37m)
|
48''(1.22m)
|
32'9''(9.14m)
|
1*4+1*5 cells
|
|
SHUXIN MIL9
|
39'(1.00m)
|
30''(0.76m)
|
30'(9.14m)
|
2*6 cells
|
|
SHUXIN MIL10
|
87''(2.21m)
|
60''(1.52m)
|
100'(30.5m)
|
4*5 cells
|
|
SHUXIN MIL11
|
48''(1.22m)
|
12''(0.3m)
|
4'(1.22m)
|
4 cells
|
|
SHUXIN MIL12
|
84''(2.13m)
|
42''(1.06m)
|
108'(33m)
|
6*5 cells
|
|
SHUXIN MIL19
|
108''(2.74m)
|
42''(1.06m)
|
10'5''(3.18m)
|
3 cells
|
Application:
The hesco barriers is a modern gabion primarily used for flood control and military fortifications. It is made of a collapsible wire mesh container and heavy duty fabric liner, and used as a temporary to semi-permanent levee or blast wall against explosions or small-arms. It has seen considerable use in Iraq and Afghanistan.
Export term:FOB Tianjin port
CIF Port
Package:
1. several pieces in bundle+pallet+plastic film.
2. one set/carton, then on pallet.
3. other packing according to buyer's requirement.
