Product Details:
|
| Material: | Steel Wire | Mesh Wire: | 5.0mm |
|---|---|---|---|
| Aperture: | 3" (76.2mm) X 3" (76.2mm) | Surface Treatment: | Heavy Hot Dipped Galvanized |
| Geotextile: | 300 Gsm Sand Color,Green Color | Life Duration: | 25 Years |
| Warranty: | 3 Years | Geotextile Color: | Beige-sand Color |
| Height: | 2' | Mil: | 6 |
| High Light: | galvanized defensive barrier,defensive barrier galvanized,coc defensive barrier |
||
Height 2' Mil 2 Defensive Barrier Hesco Barrier Galvanized Gabion Wire Mesh Retaining Wall
1. Defensive Barrier Hesco Barrier Introduction :
Military Gabion Box (steel weld mesh gabion)are good.
Solution for emergency flood control,shelter house,military defence wall.
2. Defensive Barrier Hesco Barrier Material:
It is made of galvanized welded mesh,spring with other fittings,can be filled with sand,earth,cement,stone,can be used in separate cell or some cells joint together.
3. Defensive Barrier Hesco Barrier Finish: electro galvanized,hot dipped galvanized,galfan coated,
4. Defensive Barrier Hesco Barrier barrier Specifications:
1) wire diameter: 4mm-5mm
2) hole: 2''x2'',3''x3'',4''x4''
3) size: 0.61x0.61m,1x1m,2.13x2.21m,other size can be produced as requested.
4) geotextile: in non-woven geotextile,color can be white,beige-sand color.
Defensive Barrier Hesco Barrier Specification
| Model | Height | Width | Length | Internal Cells |
| SX-1 | 54”(1.37m) | 42”(1.06m) | 32’9”(10m) | 5+4=9 cells |
| SX-2 | 24”(0.61m) | 24”(0.61m) | 4’(1.22m) | 2 cells |
| SX-3 | 39”(1.0m) | 39”(1.0m) | 32’9”(10m) | 5+5=10 cells |
| SX-4 | 39”(1.0m) | 60”(1.52m) | 32’9”(10m) | 5+5=10 cells |
| SX-5 | 24”(0.61m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| SX-6 | 66”(1.68m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| SX-7 | 87”(2.21m) | 84”(2.13m) | 91’(27.74m) | 5+4+4=13 cells |
| SX-8 | 54”(1.37m) | 48”(1.22m) | 32’9”(10m) | 5+4=9 cells |
| SX-9 | 39”(1.0m) | 30”(0.76m) | 30’(9.14m) | 6+6=12 cells |
| SX-10 | 87”(2.21m) | 60”(1.52m) | 100’(30.5m) | 5+5+5+5=20 cells |
| SX-11 | 48”(1.22m) | 12”(0.30m) | 4’(1.22m) | 2 cells |
| SX-12 | 84”(2.13m) | 42”(1.06m) | 108’(33m) | 5+5+5+5+5+5=30 cells |
| SX-19 | 108”(2.74m) | 42”(1.06m) | 10’5”(3.18m) | 6 cells |
Defensive Barrier Hesco Barrier Use Deatils:
Unpack---Pull out and set up-----Connect together---- Fill and compact----Finished
Defensive Barrier Hesco Barrier Application :
♦ Perimeter security and defense walls
♦ Equipment revetments
♦ Personnel and material bunkers
♦ Observation points
♦ Defensive firing positions
♦ Guard posts
♦ Protection engineering of seaside area
♦ Border crossing checkpoints
♦ Protecting existing structures
♦ Flood control retaining wall
