5mm Hesco 2m Height Galvanized Military Barrier

Basic Properties
Place of Origin: CHINA
Brand Name: SHUXIN
Certification: CE SGS ISO COC
Model Number: Military gabion
Trading Properties
Minimum Order Quantity: 100 unit
Price: Negotiated
Standard Packaging: pallet and plastic film
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union,
Supply Ability: 500 units per week
Product Summary
Height 7'3" 5mm Hesco 2m Height Galvanized Hesco Barriers Hesco Mil8 For Sale With Geotextile Filter Fabric Introduction of Barriers Hesco : Barriers Hesco rapidly deployable fortification systems Whether used to define boundaries or as a preventative barrier, units have been employed to safeguard ...

Product Details

Highlight:

galvanized military barrier

,

2m height military barrier

,

galvanized military barrier 5mm

Accessories: Spring, Joint Pin, Geotextile
Sureface Treatment: Heavy Galvanized
Mesh Hole: 3" X 3"
Wire: 5.0mm 4.0mm
Warranty: ≥ 3 Years
Height: 7'3"
Product Description

                 Height 7'3" 5mm Hesco 2m Height Galvanized Hesco Barriers Hesco Mil8 For Sale With Geotextile Filter Fabric



Introduction of Barriers Hesco :



Barriers Hesco rapidly deployable fortification systems



Whether used to define boundaries or as a preventative barrier,  units have been employed to safeguard personnel, vehicles, equipment, facilities and other vulnerable target areas in a variety of military, peacekeeping, humanitarian and civilian operations. units have also been extensively used in civil applications in flood management, erosion control and slope stability applications.



Quick View of Barriers Hesco:



Material : Low-carbon steel wire
Wire Diameter : 4-5.0mm
Spring Diameter : 4.0-4.5mm
Mesh Hole : 76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm
Panel Size : 2.21× 2.13m, 1.37× 1.06m, 0.61× 0.61m, 1.37× 1.22m
Geotextile : In heavy duty non-woven polypropylene.
Finish : Hot Dipped Galvanized after /before welding, Galfan Coated before welding



The Militarybarriers come in a variety of sizes. Most of the barriers can also be stacked, and they are shipped collapsed in compact sets. Example dimensions of typical configurations are 1.4m x 1.1m x 9.8m (4'6" x 3'6" x 32') to 2.1m x 1.5m x 30m (7' x 5' x 100').

The Common Specification of Barriers Hesco as followed:

                                                          Barriers Hesco Specification



Model Height Width Length Internal Cells
SX-1 54”(1.37m) 42”(1.06m) 32’9”(10m) 5+4=9 cells
SX-2 24”(0.61m) 24”(0.61m) 4’(1.22m) 2 cells
SX-3 39”(1.0m) 39”(1.0m) 32’9”(10m) 5+5=10 cells
SX-4 39”(1.0m) 60”(1.52m) 32’9”(10m) 5+5=10 cells
SX-5 24”(0.61m) 24”(0.61m) 10’(3.05m) 5 cells
SX-6 66”(1.68m) 24”(0.61m) 10’(3.05m) 5 cells
SX-7 87”(2.21m) 84”(2.13m) 91’(27.74m) 5+4+4=13 cells
SX-8 54”(1.37m) 48”(1.22m) 32’9”(10m) 5+4=9 cells
SX-9 39”(1.0m) 30”(0.76m) 30’(9.14m) 6+6=12 cells
SX-10 87”(2.21m) 60”(1.52m) 100’(30.5m) 5+5+5+5=20 cells
SX-11 48”(1.22m) 12”(0.30m) 4’(1.22m) 2 cells
SX-12 84”(2.13m) 42”(1.06m) 108’(33m) 5+5+5+5+5+5=30 cells
SX-19 108”(2.74m) 42”(1.06m) 10’5”(3.18m) 6 cells

]5mm Hesco 2m Height Galvanized Military Barrier

Barriers Hesco Features :

Barriers Hesco walls can be built to any required length and to any height. The unique joining system allows the user great flexibility in configurations and requirements. One of the key advantages of the system is that any readily available infill material can be utilised. Sand, rubble, rocks, soil, concrete and even snow have been successfully used.



Rapid construction is another key feature of the product. A typical wall of units equivalent to approximately 1500 sandbags, can be erected and filled by two men and a single common loader in less than twenty minutes. An equivalent wall constructed of sandbags would take 10 men 7 hours to build.



5mm Hesco 2m Height Galvanized Military Barrier

Barriers Hesco Our sevice:



  1. Provide free sample for you to check the quality
  2. Can supply Certificate of Original, Form E, CCPIT, SONCAP, etc. As your import requirements.
  3. Solve after-sales problems
  4. All kinds of instant messaging tools, more convenient communication
  5. Reply your email within 12 hours
  6. OEM& ODM are available



5mm Hesco 2m Height Galvanized Military Barrier
