Product Details:
|
Wire Gauge: | 4mm, 5mm | Mesh Size: | 76.2X76.2mm |
---|---|---|---|
Geotextile: | Heavy Duty Non-woven Polypropylene | Panel Size: | 1.37m X1.06m |
Life Span: | ≥ 25 Years | Material: | Zinc-aluminium Wire Mesh |
Color: | Beige, Brown, Sand , ArmyGreen | Usage: | Protection, Prevention Of Floods |
Highlight: | military protection hesco blast walls,galvanized hesco blast walls,hesco blast walls galvanized |
Military Protection Galvanized Wire Mesh Standard Defensive Hesco Wall Barriers In Israel
Product Description
Galvanized Wire Mesh Standard Defensive Hesco Wall Barriers come in many sizes. Most fences can also be stacked and packed into a compact set. Whether used as protective barriers or to define borders, security barriers and T-walls are used to protect equipment, facilities, vehicles and personnel in military, peacekeeping, humanitarian and civil operations.
Material: All wires conform to BS EN10218-2012,Zinc-Alunminum coating are to BS EN 10244-2:2009
Mesh size: 3x3 inches (7.62*7.62 cm)
Panel Size: 13 species
Unit Size: 2.13m x 1.06m x 33m
Cells: 1unit=5 cells+5cells+5cells+5cells+5cells+5cells=30cells
Surface Treatment: Hot Dip Galvanizing, Galvanizing Wire
Packaging: Packaging with shrink film or pallet
Geotextile: heavy duty geotextile, non-woven,permeable, polypropulene farbric
Geotextile color: Beige, Brown, Sand , ArmyGreen
A geotextile lined unit for general use as an earth filled barrier .
The units are suitable for filling with earth ,sand,gravel,crushed rock and other granular materials.
The unit fulfills a wide range of users,including the construction of protective walls and barriers.
Defensive Barriers Specification:
Galvanized Wire Mesh Standard Defensive Hesco Wall Barriers | |
SX-1 | 1.37m* 1.06m*10.0m |
SX-2 | 0.61m* 0.61m*1.22m |
SX-3 | 1.0m*1.0m*10.0m |
SX-4 | 1.0m*1.5m*10.0m |
SX-5 | 0.61m* 0.61m*3.05m |
SX-6 | 0.61m* 0.61m*6.10m |
SX-7 | 2.21m*2.13m*8.52m |
SX-8 | 1.37m*1.22m*10.0m |
SX-9 | 1.0m*0.76m*9.14m |
SX-10 | 2.13m*1.52m*7.62m |
Defensive Barriers Applications:
Defensive Barriers Features:
1. A pre-fabricated gabion of galvanised welded-mesh steel fitted with a UV-protected Polypropylene geo-textile liner.
2. Filling material is an easily-obtained mix of sand and small stones.
3. Can be connected together to any length, and can be stacked for additional height.
4. Primary military use is as force protection against blast and projectiles.
5. One of the best features of the defensive barrier is the ease in which it is set up. Get it flown in or pull it off a truck, unfold it, use a front end loader or other heavy equipment to fill it up with dirt, sand or gravel.
