Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile

Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile
Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile
Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile

Large Image :  Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile

Product Details:
Place of Origin: Hebei, CHINA
Brand Name: SHUXIN
Certification: ISO CE SGS
Model Number: SX-Defensive Barrier
Payment & Shipping Terms:
Minimum Order Quantity: 10000 Set/Sets per Week
Packaging Details: Wrapped with shrink film or packed in pallet
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100/SETS+15PER

Hot Galvanized Welded 4mm Hesco Barricades Boxes With Geotextile

Description
Product Name: Hot Galvanized Welded Military Defensive HESCO Barrier Boxes With Geotextile Material: Galvanized
Application: Military Defensive Mesh Size: 3'' *3''(7.62*7.62cm)
Type: Welded Mesh Hole Shape: Square
High Light:

hot galvanized hesco barricades

,

4mm hesco barricades

,

welded boxes defensive barrier

Hot Galvanized Welded Military Defensive HESCO Barrier Boxes With Geotextile





Mesh gabion box specifications:

1. Wire diameter: 4-5mm

2. Mesh size: 3x3 inches (7.62*7.62 cm)

3. Panel Size: 13 species

4. Application: used for any security protection and sudden attack

5. Geotextiles: Heavy Non-woven Polypropylene

6. Color: gray, military green, sand, etc

7. Surface Treatment: Hot Dip Galvanizing, Galvanizing Wire

8. Packaging: Packaging with shrink film or pallet



  • Introduction

Hot dip galvanized gabion boxes with geotextile are also called fortresses, protective walls, sand cages, welded gabion boxes, etc. This is a multi-cellular system made of galvanized welded mesh and lined with non-woven fabric. The provided connection extension and connection unit may be used. It is easy to install and requires minimal manpower and commonly available equipment. After expansion, it is filled with sand and stones, and then welded with gabion barriers like defense walls or bunkers. It is widely used for military defense and flood control.

  • Working principle

It is made of galvanized welded mesh plate, spring belt and other accessories, which can be filled with sand, soil, cement and stone, and can be used alone or connected by some defense barriers.

  • Quality assurance

Our factory has been verified on site by SGS Group, the world's leading inspection company. Our products strictly follow ISO9001, SGS and CE certification. Our products comply with BS EN 10244-2:2009 and BS EN 1208-2:2012



Defensive HESCO Barrier have the following properties:



-A non-deforming upright wall will significantly reduce the peak blast overpressure and impulse in an area between 4 and 6 wall heights behind it
-Similar protection occurs at greater distances behind the wall, but to a diminishing extent
Blast walls perform best if the explosion is relatively close to the front of the wall
-"Canopied" walls (with a top section overhanging the front face) show some improved blast protection over plane walls
-A 90-degree canopy is more effective than a 45-degree one
-Walls containing sand or water work well, and cause little damage if they fail
-A wall has to stay intact long enough to "interact" with the blast in order to have any effect



Specifications of defensive barrier (SX1-SX12):



Model Height Width Length NO.of cells
SX-1 4'6''(1.37m) 3'6'' (1.06m) 32' (10m) 9 cells (1*4,1*5)
SX-2 7' (2.1m) 3'6'' (1.06m) 108' (33m) 30 cells(6*5)
SX-3 2'(0.61m) 2'(0.61m) 4' (1.21m) 2 cells
SX-4 3'3'' (1.0m) 3'3'' (1.0m) 32' (10m) 10 cells (2*5)
SX-5 2'(0.61m) 2'(0.61m) 10' (3.05m) 5 cells
SX-6 5'6'' (1.68m) 2'(0.61m) 10' (3.05m) 5 cells
SX-7 7'3'' (2.21m) 7' (2.1m) 90' (27.74m) 13 cells (2*4,1*5)
SX-8 4'6'' (1.37m) 4' (1.22m) 32' (10m) 9 cells (1*4,1*5)
SX-9 3'3'' (1.0m) 2'6'' (0.76m) 30' (9.14m) 12 cells (2*6)
SX-10 7' (2.1m) 5' (1.52m) 95' (30.5m) 20 cells (4*5)
SX-11 3'3'' (1.0m) 3'3'' (1.0m) 3'3'' (1.0m) 1 cell
SX-12 7'3'' (2.21m) 7'3'' (2.21m) 7'3'' (2.21m) 1 cell



Defensive Barriers Advantages:

Secure & reliable

Once filled with soil, sand or gravel, forms a solid and strong barrier with exceptional strength and structural integrity to protect personnel and equipment from enemy fire. For example:

Two feet thick barriers can be used to stop rifle bullets and shell fragments.

Four feet thick barriers can prevent most car bombs.

Five feet thick barriers is ideal for preventing penetration and explosion fragments from rocket propelled grenade.

Convenient usage

HESCO bastion barrier can be used in separate cell or some cells joined together by joint pins to suit different needs of your projects. Almost any locally filling material can be used such as soil, sand, gravel, crushed rock and various other granular materials.

Labor saving design

Can be collapsed and stacked on pallets for easy package, handling and transport, so that it efficiently saves labor cost.

Quick & easy assembly

Provides the easiest deploy methods - just unfold it and fill it using minimal manpower or commonly available equipment. Previously, sandbag barrier is considered a slow undertaking as a person can only fill about 20 sandbags per hour. Yet our KNSCO do ten times the work.
