Product Details:
|
Product Name: | 8*10cm 2*1*1m Galvanized Woven Gabion Baskets | Wire Diameter: | 2.0-4.00mm |
---|---|---|---|
Type: | Weave Wire Mesh | Material: | Galvanized Iron Wire |
Surface Treatment: | Hot Galvanized / PVC Coated | Hole Size: | 60*80/80*100/100*120 Mm |
Hole Shape: | Hexagonal | Usage: | River Slope,Prevent The Water And Soil Lost |
Technique: | Twisted Weaving | Application: | Retaining Wall,Bridge Protection |
High Light: | hole 8*10cm steel gabion baskets,river slope steel gabion baskets,woven 2m x 1m x 1m gabion baskets |
Hole 8*10cm Gabion Used For River Slope 2*1*1m Galvanized Woven Gabion Baskets
Introduction of Gabion basket:
Gabion baskets, also called gabion boxes, are made of corrosion-resistant, high-strength and ductile galvanized wire or PVC coated wire through mechanical weaving. Wire material is zinc -5% aluminum alloy (galfan), low carbon steel, stainless steel or iron.
Gabion mattress is similar to gabion basket. But gabion mattress's height is lower than gabion basket, structure is flat and big. Gabion basket and gabion mattress are stone containers, uniformly partitioned into internal cells, interconnected with other containers and filled with stone at site to form flexible, permeable, monolithic structures to control and guide water or flood, protect dam or seawall, or used as retaining walls, channel lining and other applications.
Galvanized Woven Gabion Baskets | |||
Gabion box (mesh size): 80*100mm 100*120mm |
Mesh wire Dia. | 2.7mm | zinc coating:60g,245g, ≥270g/m2 |
Edge wire Dia. | 3.4mm | zinc coating:60g,245g, ≥270g/m2 | |
Tie wire Dia. | 2.2mm | zinc coating:60g,≥220g/m2 | |
Gabion mattress(mesh size): 60*80mm |
Mesh wire Dia. | 2.2mm | zinc coating:60g, ≥220g/m2 |
Edge wire Dia. | 2.7mm | zinc coating:60g,245g, ≥270g/m2 | |
Tie wire Dia. | 2.2mm | zinc coating:60g, ≥220g/m2 | |
Available gabions of special sizes | Mesh wire Dia. | 2.0~4.0mm | superior quality,competitive price and considerate service |
Edge wire Dia. | 2.7~4.0mm | ||
Tie wire Dia. | 2.0~2.2mm |
Introduction to the use of gabion baskets:
The structure can be used for side slope support, foundation pit support, mountain rock surface hanging net shotcrete, side slope vegetation (greening), railway highway isolation fence, it can also be made into box cages, net pads, used in rivers, rivers, Erosion protection of dams and seawalls, as well as cages for the closure of reservoirs and rivers.
●Control and guide rivers and floods
The most serious disaster of rivers is the destruction of river banks by water, which caused flooding, resulting in massive losses of lives and properties and massive soil erosion. The application of the ecological gabion net structure can permanently protect the river bed and bank.
●Channel canal bed
The construction of the channel involves the stability of the slope and river bed. It can effectively and permanently protect the river bank or riverbed, control the flow of water, prevent water loss, and has excellent effects in environmental protection and water quality maintenance.
●Slope protection
The application of ecological grid structure to river bank protection and slope toe protection is a very successful example. It gives full play to the advantages of ecological grid and achieves the ideal effect that other methods cannot achieve.
Advantages of gabion basket structure:
1. The flexible structure can adapt to the changes of the slope without being destroyed, and has better safety and stability than the rigid structure;
2. Strong anti-scouring ability, can withstand the maximum water flow speed up to 6m/s;
3. The structure is inherently water-permeable, and has strong tolerance to the natural and filtering effects of groundwater. Suspended matter and silt in the water can be deposited in the rockfill, which is beneficial to the growth of natural plants. Restore the original ecological environment.
