SGS Square Shape Military Defensive Barrier Gabion Barriers 300GSM In Ghana

Basic Properties
Place of Origin: Hebei, China
Brand Name: SHUXIN
Certification: CE, ISO, SGS, SASO, PVOC,COC, FM A, FM E
Model Number: SX-Mil1 to SX-Mil19
Trading Properties
Minimum Order Quantity: 10 SETS
Price: Negotiated
Standard Packaging: Wrapped with shrink film and packed in pallet
Delivery Time: 15 working days
Payment Terms: L/C, T/T, Western Union, ,Paypal, T/A
Supply Ability: 10 Pieces of 40ft container per month
Product Summary
High Quality Military Square Shape Defensive Galvanized Gabion Barriers In Ghana 1. Defensive Barriers Introduction Hot dip galvanized gabion boxes with geotextile are also called fortresses, protective walls, sand cages, welded gabion boxes, etc. This is a multi-cellular system made of galvanized ...

Product Details

Highlight:

SGS Defensive Barrier

,

SGS Gabion Barriers

,

Gabion Barriers 300GSM

Product Name: High Quality Military Square Shape Defensive Galvanized Gabion Barriers In Ghana
Wire Diameter: 4.0mm To 5.0mm
Material: Galvanized Galfan Steel Wire
Mesh Hole: 3*3'(7.62*7.62cm)
Surface: Hot Dipped Galvanized, Galfan Coated
Key Word: Welded Gabion, HESCO Barriers,Defensive Barriers
Application: Fence Mesh,Gabions, Defensive Barriers, Hesco Barriers
Processing Service: Welding, Cutting
Product Description

High Quality Military Square Shape Defensive Galvanized Gabion Barriers In Ghana





1. Defensive Barriers Introduction

Hot dip galvanized gabion boxes with geotextile are also called fortresses, protective walls, sand cages, welded gabion boxes, etc. This is a multi-cellular system made of galvanized welded mesh and lined with non-woven fabric. The provided connection extension and connection unit may be used. It is easy to install and requires minimal manpower and commonly available equipment. After expansion, it is filled with sand and stones, and then welded with gabion barriers like defense walls or bunkers. It is widely used for defensive barriers and flood control.

2. Working principle:

It is made of galvanized welded mesh plate, spring belt and other accessories, which can be filled with sand, soil, cement and stone, and can be used alone or connected by some defense barriers.

3. Quality assurance:

Our factory has been verified on site by SGS Group, the world's leading inspection company. Our products strictly follow ISO9001, SGS and CE certification. Our products comply with BS EN 10244-2:2009 and BS EN 1208-2:201



Wire Diameter: 5.0mm (Standard), 4.0mm
Surface treatment: Hot dipped galvanized
Mesh Hole: 76.2*76.2mm (Standard), 80*80mm
Hole shape: Square
Processing Service: Welding, Cutting
Diameter of Spring: 4.0mm
Diameter of Joint Pin: 4.0mm
Cells per Set: 1 cell, 2 cells, 3 cells, 4 cells, 5 cells
Color of Geotextile: Military Green, Beige, Brown, Sand Color
Weight of Geotextile: 300GSM (Standard)
Mesh Opening: 50*50mm, 75*75mm, 76.2*76.2mm, 50*100mm, 100*100mm, ect
Panel Size: 0.61x0.61m,1x1m,2.13x2.21m,other size can be produced as requested

Model Height Width Length Internal Cells
SX-1(Mil 1) 54”(1.37m) 42”(1.06m) 32’9”(10m) 5+4=9 cells
SX-2(Mil 2) 24”(0.61m) 24”(0.61m) 4’(1.22m) 2 cells
SX-3(Mil 3) 39”(1.0m) 39”(1.0m) 32’9”(10m) 5+5=10 cells
SX-4(Mil 4) 39”(1.0m) 60”(1.52m) 32’9”(10m) 5+5=10 cells
SX-5(Mil 5) 24”(0.61m) 24”(0.61m) 10’(3.05m) 5 cells
SX-6(Mil 6) 66”(1.68m) 24”(0.61m) 10’(3.05m) 5 cells
SX-7(Mil 7) 87”(2.21m) 84”(2.13m) 91’(27.74m) 5+4+4=13 cells
SX-8(Mil 8) 54”(1.37m) 48”(1.22m) 32’9”(10m) 5+4=9 cells
SX-9(Mil 9) 39”(1.0m) 30”(0.76m) 30’(9.14m) 6+6=12 cells
SX-10(Mil 10) 87”(2.21m) 60”(1.52m) 100’(30.5m) 5+5+5+5=20 cells
SX-11(Mil 11) 48”(1.22m) 12”(0.30m) 4’(1.22m) 2 cells
SX-12(Mil 12) 84”(2.13m) 42”(1.06m) 108’(33m) 5+5+5+5+5+5=30 cells
SX-19(Mil 19) 108”(2.74m) 42”(1.06m) 10’5”(3.18m) 6 cells



Application of Defensive Barriers:

Peripheral security and defense wall

Equipment protection

Shelter for personnel and materials

Observation point

Defensive firing position sentry

Explosive and contraband search area

Highway inspection station

Border crossing checkpoint

Protect existing structures

Flood control retaining wall beach erosion

Coastal Area Protection Project



Advantages of Defensive Barrier:

1. Removable

It is assembled by panels and spring wires, and can be folded into a whole during loading and transportation.

2. Anticorrosion

The raw material is hot-dip galvanized wire, which can be used for 10 years or more and is suitable for external protection.

3. Easy installation

When you get it, open it in a spacious place and fill it with sand and mud. Even 2-3 people can finish it.

4. Rapid displacement

When you want to use it in another place, just move it and it can be used many times.

5. Easy to repair

If a part is damaged, throw it away and connect it with a new one.



SGS Square Shape Military Defensive Barrier Gabion Barriers 300GSM  In Ghana

SGS Square Shape Military Defensive Barrier Gabion Barriers 300GSM  In Ghana
