Product Details:
|
Mesh Size: | 7.62*7.62cm | Accessories: | Spring, Joint Pin, Geotextile |
---|---|---|---|
Geotextile: | 300 G/m2,waterproof, Good Penetration Geotextile | Application: | Hesco Barriers,River Pretection |
Feature: | Easy To Assemble,Good Permeability. | Raw Materials: | Hot Dipped Galvanized |
Highlight: | Mil 10 Defensive Barrier,River Protection Defensive Barrier,Mil 10 Hesco Barrier |
Mil 10 Defensive Hesco Barrier With 300g Sand Color Geotextile
Hesco Barrier Description:
Hot galvanized wire mesh, It is widely used for military defense and flood control.
Details of Hesco Barrier:
Model | Height | Width | Length | Internal Cells |
SX-1 | 54”(1.37m) | 42”(1.06m) | 32’9”(10m) | 5+4=9 cells |
SX-2 | 24”(0.61m) | 24”(0.61m) | 4’(1.22m) | 2 cells |
SX-3 | 39”(1.0m) | 39”(1.0m) | 32’9”(10m) | 5+5=10 cells |
SX-4 | 39”(1.0m) | 60”(1.52m) | 32’9”(10m) | 5+5=10 cells |
SX-5 | 24”(0.61m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
SX-6 | 66”(1.68m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
SX-7 | 87”(2.21m) | 84”(2.13m) | 91’(27.74m) | 5+4+4=13 cells |
SX-8 | 54”(1.37m) | 48”(1.22m) | 32’9”(10m) | 5+4=9 cells |
SX-9 | 39”(1.0m) | 30”(0.76m) | 30’(9.14m) | 6+6=12 cells |
SX-10 | 87”(2.21m) | 60”(1.52m) | 100’(30.5m) | 5+5+5+5=20 cells |
SX-11 | 48”(1.22m) | 12”(0.30m) | 4’(1.22m) | 2 cells |
SX-12 | 84”(2.13m) | 42”(1.06m) | 108’(33m) | 5+5+5+5+5+5=30 cells |
SX-19 | 108”(2.74m) | 42”(1.06m) | 10’5”(3.18m) | 6 cells |
Applications of the Military Barrier:
Peripheral security and defense wall | Observation point |
Equipment protection | Defensive firing position sentry |
Shelter for personnel and materials | Explosive and contraband search area |
