Galvanized Welding Anti-corrosion HESCO Defensive Military Barrier Wall With Dark Green In Canada

Basic Properties
Place of Origin: CN
Brand Name: SHUXIN
Certification: CE, ISO, SGS, SASO, PVOC,COC, FM A, FM E, CO
Model Number: From SX1 to SX 19
Trading Properties
Minimum Order Quantity: 100 UNITS
Price: Negotiated
Standard Packaging: Pallet
Delivery Time: 15 working days
Payment Terms: L/C, T/T, Western Union, ,Paypal, T/A
Supply Ability: 200 Units per week
Product Summary
Galvanized Welding Anti-corrosion HESCO Defensive Military Barrier Wall With Dark Green In Canada Defensive Barriers, also known as explosion-proof wall and flood-proof wall, are new products assembled and sewed by welded gabion mesh and geotextile. It can hold fine sand, dirt and stones, can ...

Product Details

Highlight:

Anti-corrosion Military Barrier

,

Galvanized Welding Military Barrier

,

HESCO Defensive Military Barrier

Raw Material: Hot Dippled Galvanized Wire
Geotextile: 300 G/㎡ Standard
Mesh Diameter: 5.0mm Diameter
Apeture: 3" (76.2mm×76.2mm)
Color: Military Green, Sand Color
Accessories: Staple, Joint Pin
Brand: KESCO, Not HESCO
Sample: Free Sample
Stock: Some Types Have Stock, Welcome To Inquiry
Product Description

Galvanized Welding Anti-corrosion HESCO Defensive Military Barrier Wall With Dark Green In Canada





Defensive Barriers, also known as explosion-proof wall and flood-proof wall, are new products assembled and sewed by welded gabion mesh and geotextile. It can hold fine sand, dirt and stones, can replace sandbags in traditional bunkers, and can be recycled.

Defensive Barriers are different from traditional gabion baskets. It can hold not only stones but finer silts as well. Filling is made from local materials and is especially suitable for downstream or coastal use where stones are scarce. With the help of advanced tools such as excavators and forklifts, the installation efficiency is dozens or even hundreds of times that of traditional sandbags.



Material : All wires conform to BS EN10218-2012,Zinc-Alunminum coating are to BS EN 10244-2:2009

Geotextile: heavy duty geotextile, non-woven,permeable, polypropulene farbric

Geotextile color: beige or green color

Mesh Hole: 3” X 3”

Unit Size : 2.13m x 1.06m x 33m

Cells:1unit=5 cells+5cells+5cells+5cells+5cells+5cells=30cells



The Standard Technical Specifications from SX1 to SX19



Welded Military Used Shooting Range Barrier
Model Height Width Length
SX-1 54"(1.37M) 42"(1.06M) 32'9"(10M)
SX-2 24"(0.61M) 24"(0.61M) 4'(1.22M)
SX-3 39"(1.00M) 39"(1.00M) 32'9"(10M)
SX-4 39"(1.00M) 60"(1.52M) 32'9"(10M)
SX-5 24"(0.61M) 24"(0.61M) 10'(3.05M)
SX-6 66"(1.68M_ 24"(0.61M) 10'(3.05M)
SX-7 87"(2.21M) 84"(2.13M) 91'(27.74M)
SX-8 54"(1.37M) 48"(1.22M) 32'9"(10M)
SX-9 39"(1.00M) 30"(0.76M) 30'(9.14M)
SX-10 87"(2.21M) 60"(1.52M) 100'(32.50M)
SX-11 48"(1.22M) 12"(0.30M) 4'(1.22M)
SX-12 84"(2.13M) 42"(1.06M) 108'(33M)
SX-19 108"(2.74M) 42"(1.06M) 10'5"(3.18M)



Defensive barrier specifications:

1. Wire diameter: 4-5mm

2. Mesh size: 3x3 inches (7.62*7.62 cm)

3. Panel Size: 13 species

4. Application: used for any security protection and sudden attack

5. Geotextiles: Heavy Non-woven Polypropylene

6. Color: gray, green, sand, etc

7. Surface Treatment: Hot Dip Galvanizing, Galvanizing Wire

8. Packaging: Packaging with shrink film or pallet



Application of Defensive Barrier:



1. Military fortifications

Most armies use defense barriers to build military fortifications because they can be stacked on top of each other. You can change the width and height according to your requirements. More simple and flexible.

2. Shooting range

Nowadays, many people use defense barriers to build shooting ranges because of its high defense strength and safety.

3. Flood control

Defense barriers are becoming more and more popular and easy to assemble, and good permeability. Most countries near coastlines choose defense barriers as flood prevention walls. Even around the hotel, they erected protective walls.



Advantages of Defensive Barrier:

1. Removable

It is assembled by panels and spring wires, and can be folded into a whole during loading and transportation.

2. Anticorrosion

The raw material is hot-dip galvanized wire, which can be used for 10 years or more and is suitable for external protection.

3. Easy installation

When you get it, open it in a spacious place and fill it with sand and mud. Even 2-3 people can finish it.

4. Rapid displacement

When you want to use it in another place, just move it and it can be used many times.

5. Easy to repair

If a part is damaged, throw it away and connect it with a new one.





Galvanized Welding Anti-corrosion HESCO Defensive Military Barrier Wall With Dark Green In Canada
