Heavy Zinc Coated Defensive Barrier Non Woven Polypropylene Geotextile 300 Gsm Lined

Basic Properties
Place of Origin: CN
Brand Name: SHUXIN
Certification: CE, ISO, SGS, SASO, PVOC,COC, FM A, FM E, CO
Model Number: SHUXIN-FPS
Trading Properties
Minimum Order Quantity: 50 UNITS
Price: Negotiated
Standard Packaging: Pallet
Delivery Time: 15 working days
Payment Terms: L/C, T/T, Western Union, ,Paypal, T/A
Supply Ability: 200 Units per week
Product Summary
Heavy Zinc coated Non-woven Polypropylene Geotextile 300 gsm Lined Hesco Bastion Defensive Barrier for Iraq Afghanistan Hesco Bastions defensive barrier was originally mainly used for protection, fortifications, explosion-proof walls, etc. It is made of foldable welded gabion net and ultraviolet ...

Product Details

Highlight:

heavy zinc coated defensive barrier

,

nonwoven polypropylene geotextile defensive barrier

,

300 gsm lined defensive barrier

Raw Material: Steel Wire
Geotextile: 300 G/㎡ Standard
Mesh Diameter: 4.0mm Diameter Wire
Apeture: 3" (76.2mm×76.2mm)
T/S: 500 - 800 MPA
Accessories: Joint Pin
Product Description

Heavy Zinc coated Non-woven Polypropylene Geotextile 300 gsm Lined Hesco Bastion Defensive Barrier for Iraq Afghanistan





Hesco Bastions defensive barrier was originally mainly used for protection, fortifications, explosion-proof walls, etc. It is made of foldable welded gabion net and ultraviolet protection heavy geotextile lining. The common surface treatment is hot dip galvanizing before welding, welding after galvanizing and Galfan coating. They all have a long service life. It is widely used in Iraq, Afghanistan and Africa.

Heavy Zinc Coated Defensive Barrier Non Woven Polypropylene Geotextile 300 Gsm Lined

Defensive barrier specifications:

1. Wire diameter: 4mm 5mm

2. Mesh size: 3x3 inches (7.62*7.62 cm)

3. Panel Size: 13 species

4. Application: used for any security protection and sudden attack

5. Geotextiles: Heavy Non-woven Polypropylene

6. Color: gray, green, sand, etc

7. Surface Treatment: Hot Dip Galvanizing, Galvanizing Wire

8. Packaging: Packaging with shrink film or pallet



The Standard Technical Defensive BarrierSpecifications from SX 1 to SX 19



Welded Military Sand Filled Barrier for Retaining Wall
Model Height Width Length
KN-1 54"(1.37M) 42"(1.06M) 32'9"(10M)
KN-2 24"(0.61M) 24"(0.61M) 4'(1.22M)
KN-3 39"(1.00M) 39"(1.00M) 32'9"(10M)
KN-4 39"(1.00M) 60"(1.52M) 32'9"(10M)
KN-5 24"(0.61M) 24"(0.61M) 10'(3.05M)
KN-6 66"(1.68M_ 24"(0.61M) 10'(3.05M)
KN-7 87"(2.21M) 84"(2.13M) 91'(27.74M)
KN-8 54"(1.37M) 48"(1.22M) 32'9"(10M)
KN-9 39"(1.00M) 30"(0.76M) 30'(9.14M)
KN-10 87"(2.21M) 60"(1.52M) 100'(32.50M)
KN-11 48"(1.22M) 12"(0.30M) 4'(1.22M)
KN-12 84"(2.13M) 42"(1.06M) 108'(33M)
KN-19 108"(2.74M) 42"(1.06M) 10'5"(3.18M)



Defensive barrier characteristics:

Easy to handle and install

High strength and impact resistance

Long service life and normal use

Can be filled with sand, cement, stone, soil.



Application of Defensive Barrier:

Peripheral security and defense wall

Equipment protection

Shelter for personnel and materials

Observation point

Defensive firing position sentry

Explosive and contraband search area

Highway inspection station

Border crossing checkpoint

Protect existing structures

Flood control retaining wall beach erosion

Coastal Area Protection Project



Advantages of Defensive Barrier:

1. Removable

It is assembled by panels and spring wires, and can be folded into a whole during loading and transportation.

2. Anticorrosion

The raw material is hot-dip galvanized wire, which can be used for 10 years or more and is suitable for external protection.

3. Easy installation

When you get it, open it in a spacious place and fill it with sand and mud. Even 2-3 people can finish it.

4. Rapid displacement

When you want to use it in another place, just move it and it can be used many times.

5. Easy to repair

If a part is damaged, throw it away and connect it with a new one.



Heavy Zinc Coated Defensive Barrier Non Woven Polypropylene Geotextile 300 Gsm Lined
