Efficiently Protect with Military Hesco Barrier Defensive Barrier for Shooting Range
The Dimension / Specification for Military HESCO Barrier:
|
Product Name
|
Hesco Barrier
|
|
Product Type
|
Welded Mesh
|
|
Material
|
Galvanized Steel Wire or Galfan/zinc-5% Aluminum Wire
|
|
Wire Diameter
|
4.0, 5.0mm, Spring Wire Diameter: 4mm
|
|
Geotextile
|
250g-400g
|
|
Geotextile colour
|
Sand clolor, Brown, Gray,and Military Green.
|
|
Mesh hole
|
76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm
|
Brief Introduction:
Wire diameter: 4mm, 5mm
Mesh size: 50mmx50mm, 75mmx75mm,76.2mmx76.2mm,100mmx100mm
Panel size: 2.21mx2.13m, 1.37mx1.06m, 0.61mx0.61m, it also can be customized according to customers requirement
Geotextile: in heavy duty non-woven polypropylene
Finish: hot dipped galvanized, galfan coated after welded
Packing: wrapped with shrink film or packed in pallet.
History of development for Military HESCO Bastion in Shuxin Factory:
Hesco barrier also named as hesco bastion,hesco defense wall,sand cage,welded gabion box,etc.It is aprefabricated,multi- cellular system,made of zinc coated steel welded mesh and lined with non-woven geo- textile.Units can be extended and joined using the provided joining pins.It is easy installed with using minimal manpower and commonly available equipment.After extended,it is filled into sand,stone,then hesco barrier likes a defence wallor bunker.It is widely used for military.
We are the designated supplier of the United Nations.
The Size Sheet for Military HESCO Barrier:
| MODEL |
Height |
Width |
Length |
NO. of Cells |
| SX-1 |
4'6"(1.37M) |
3'6"(1.06M) |
32'(10M) |
9 cells(1*4, 1*5) |
| SX-2 |
7'(2.1M) |
3'6"(1.06M) |
108'(33M) |
30 cells(6*5) |
| SX-3 |
2'(0.61M) |
2'(0.61M) |
4'(1.21M) |
2 cells |
| SX-4 |
3'3"(1.0M) |
3'3"(1.0M) |
32'(10M) |
10 cells(2*5) |
| SX-5 |
2'(0.61M) |
2'(0.61M) |
10'(3.05M) |
5 cells |
| SX-6 |
5'6"(1.68M) |
2'(0.61M) |
10'(3.05M) |
5 cells |
| SX-7 |
7'3"(2.21M) |
7'(2.13M) |
90'(27.74M) |
13 cells(2*4,1*5) |
| SX-8 |
4'6"(1.37M) |
4'(1.22M) |
32'(10M) |
9 cells(1*4, 1*5) |
| SX-9 |
3'3"(1.0M) |
2'6"(0.76M) |
30'(9.14M) |
12 cells(2*6) |
| SX-10 |
7'(2.12M) |
5'(1.52M) |
95'(30.5M) |
20 cells(4*5) |
| SX-11 |
3'3"(1.0M |
3'3"(1.0M) |
3'3"(1.0M) |
1 Cell |
| SX-12 |
7'3"(2.21M) |
7'3"(2.21M) |
7'3"(2.21M) |
1 Cell |
The Detailed Explanation of Application for HESCO Barrier:
1. Military Fortifications
Most Army Used HESCO Barrier build up a Military Fortifications, Because it can stack on each other, You can change the width and height by your demands. More easy and flexible.
2. Shooting Range
Nowadays, A lot of people use HESCO Barrier to build a shooting range, because its High Strength Defense, more safety.
3. Flood Control
We Mentioned above, The HESCO Barrier is more and more popular and Homemade. Most Countries Near the coastline choose the HESCO Barrier as Flood Protection Wall.Even around the hotel they stand up the HESCO Barrier for Protection Wall.
The Advantages for HESCO Barrier:
1. Collapsible
It is assembled by Panel and Spring Wire, When Loading and transportation, It is Foldable into one piece.
2. Anti-Corrosion
The Raw material is Hot Dipped Galvanized Wire, it can use 10 years even more longer, fit for outside protection.
3. Easy Installation
After getting it, Just put it in the right place and open it, Full filled the sand and earth is okay. Even 2-3 persons can finish it.
4. Quick Displacements
When you want to use it in another place,Just to move it, It can use many times
5. Easy to repair
If some part is destroyed, Just left it and connect the new one is okay.
