Portable Welded Square 3x3 inches Military Barrier Defensive Stone Box Barriers
Material : All wires conform to BS EN10218-2012,Zinc-Alunminum coating are to BS EN 10244-2:2009
Geotextile: heavy duty geotextile, non-woven,permeable,
polypropulene farbric
Geotextile color: beige or green color
Mesh Hole: 3” X 3”
Unit Size : 2.13m x 1.06m x 33m
Cells:1unit=5 cells+5cells+5cells+5cells+5cells+5cells=30cells
| Name: |
Mlitiary barrier |
Material: |
Geotextile and welded gabion |
| Wire Diameter: |
4.0 4.5 5.0mm |
Hole Shape: |
Square Hole |
| Hole Size: |
76.2*76.2mm/3''*3'' etc |
Highth: |
1.37m 0.61m 1.0m 1.6m2.2m 2.5m etc |
| wire Surface: |
Galvanized or galfan |
Geotextile Color: |
Green or beigeMilitary barrier |
| Geotextile Weight: |
250-500g/m2 |
Connection: |
Spiral |
| Feature: |
Easily Assembled |
Application: |
Military Sand Wall, Flood barrier |
| Usage: |
Protection |
Packing: |
Plastic film then on pallet |
Features:
1.easy to handle and install
2.High tensile and anti-impact capability
3.long life time
The Standard Technical Specifications from SX1 to SX19
| Welded Military Used Shooting Range Barrier |
| Model |
Height |
Width |
Length |
| KN-1 |
54"(1.37M) |
42"(1.06M) |
32'9"(10M) |
| KN-2 |
24"(0.61M) |
24"(0.61M) |
4'(1.22M) |
| KN-3 |
39"(1.00M) |
39"(1.00M) |
32'9"(10M) |
| KN-4 |
39"(1.00M) |
60"(1.52M) |
32'9"(10M) |
| KN-5 |
24"(0.61M) |
24"(0.61M) |
10'(3.05M) |
| KN-6 |
66"(1.68M_ |
24"(0.61M) |
10'(3.05M) |
| KN-7 |
87"(2.21M) |
84"(2.13M) |
91'(27.74M) |
| KN-8 |
54"(1.37M) |
48"(1.22M) |
32'9"(10M) |
| KN-9 |
39"(1.00M) |
30"(0.76M) |
30'(9.14M) |
| KN-10 |
87"(2.21M) |
60"(1.52M) |
100'(32.50M) |
| KN-11 |
48"(1.22M) |
12"(0.30M) |
4'(1.22M) |
| KN-12 |
84"(2.13M) |
42"(1.06M) |
108'(33M) |
| KN-19 |
108"(2.74M) |
42"(1.06M) |
10'5"(3.18M) |
The defensive barrier is a modern gabion primarily used for flood control and fortifications . It is made of a collapsible wire mesh container and heavy duty fabric liner, and used as a temporary to semi-permanent levee or blast wall against explosions or small-arms . It has seen considerable use in many countries .
Defensive barriers are walls that are resistant to blast shock waves, limiting the destructive effects of explosions to a certain range. Compared with concrete explosion-proof wall, it has the advantages of light weight, easy installation, easy disassembly and recycling.
Advantages:
Secure & reliable
Once filled with soil, sand or gravel, forms a solid and strong barrier with exceptional strength and structural integrity to protect personnel and equipment from enemy fire. For example:
Two feet thick barriers can be used to stop rifle bullets and shell fragments.
Four feet thick barriers can prevent most car bombs.
Five feet thick barriers is ideal for preventing penetration and explosion fragments from rocket propelled grenade.
Convenient usage
HESCO bastion barrier can be used in separate cell or some cells joined together by joint pins to suit different needs of your projects. Almost any locally filling material can be used such as soil, sand, gravel, crushed rock and various other granular materials.
Labor saving design
Can be collapsed and stacked on pallets for easy package, handling and transport, so that it efficiently saves labor cost.
Quick & easy assembly
Provides the easiest deploy methods - just unfold it and fill it using minimal manpower or commonly available equipment. Previously, sandbag barrier is considered a slow undertaking as a person can only fill about 20 sandbags per hour. Yet our KNSCO do ten times the work.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=5000 USD, 100% in advance. Payment>=5000 USD, 50% T/T in advance ,balance before shipment.
If you have another question, please feel free to contact us .
