3x3 Inches Military Barrier Hesco Welded Square Barriers Green color Geotextile
Defensive barrier characteristics:
Easy to handle and install
High strength and impact resistance
Long service life and normal use
Can be filled with sand, cement, stone, soil.
Hot galvanized wire
Usually, the materials for welding gabion boxes are hot-dip galvanized wire and Galfan coated wire, which are corrosion resistant, high in strength and long in service life. Wire diameter: 5.0mm (thick enough to withstand impact)
Spring wire for connecting mesh plates
Usually, the spring wire is made of the same wire as the metal panel. It informs the net cage to load sand or stones together with the panel. Spring wire diameter: 4.0 mm
Welded mesh plate
We have a full-automatic machine, which is mainly used for thick-line welding of screen plates, and deep welding points make the screen plates firmer. Mesh: 75mm * 75mm (standard and strong) You can also make bigger holes according to customer's requirements.
Geotextile
It has various colors: sand, brown, gray and green. Generally, the weight of geotextile is 300 GSM and our geotextile is uniform in thickness, reaching the national standard.
The Standard Technical Specifications from SX1 to SX19
| Welded Military Used Shooting Range Barrier |
| Model |
Height |
Width |
Length |
| SX-1 |
54"(1.37M) |
42"(1.06M) |
32'9"(10M) |
| SX-2 |
24"(0.61M) |
24"(0.61M) |
4'(1.22M) |
| SX-3 |
39"(1.00M) |
39"(1.00M) |
32'9"(10M) |
| SX-4 |
39"(1.00M) |
60"(1.52M) |
32'9"(10M) |
| SX-5 |
24"(0.61M) |
24"(0.61M) |
10'(3.05M) |
| SX-6 |
66"(1.68M_ |
24"(0.61M) |
10'(3.05M) |
| SX-7 |
87"(2.21M) |
84"(2.13M) |
91'(27.74M) |
| SX-8 |
54"(1.37M) |
48"(1.22M) |
32'9"(10M) |
| SX-9 |
39"(1.00M) |
30"(0.76M) |
30'(9.14M) |
| SX-10 |
87"(2.21M) |
60"(1.52M) |
100'(32.50M) |
| SX-11 |
48"(1.22M) |
12"(0.30M) |
4'(1.22M) |
| SX-12 |
84"(2.13M) |
42"(1.06M) |
108'(33M) |
| SX-19 |
108"(2.74M) |
42"(1.06M) |
10'5"(3.18M) |
Application of Defensive Barrier:
~Military Defense
~Perimeter Security Barrier and Defence Wall
~Temporary Fort and Command Post
~Observation Points and Border Checkpoints
~Military Barrier Fortification System
~Equipment Revetment
~Explosives and Contraband Search Areas
| Technical Specification for Barrier Panel |
| steel wire |
Low carbon steel |
| wire thickness |
3.5mm-5.0mm |
| wire tensile |
500-800Mpa |
| welding tensile |
50-100% of wire tensile strength |
| mesh size |
76.2mm*76.2mm, 100mm*50mm,100mm*100mm |
| surface treatment |
Zinc coating or Zinc-Al coating 40-600g/m2 |
Advantages of Defensive Barrier:
1. Removable
It is assembled by panels and spring wires, and can be folded into a whole during loading and transportation.
2. Anticorrosion
The raw material is hot-dip galvanized wire, which can be used for 10 years or more and is suitable for external protection.
3. Easy installation
When you get it, open it in a spacious place and fill it with sand and mud. Even 2-3 people can finish it.
4. Rapid displacement
When you want to use it in another place, just move it and it can be used many times.
5. Easy to repair
If a part is damaged, throw it away and connect it with a new one.
Our services
Selected high-quality materials and processes follow strict international standards.
A team of technical experts who produce high-quality products.
Products that have been certified or inspected for the third time can be provided as required.
Analyze or suggest the best transportation plan to save costs.
Feedback or reply to you in a timely manner through excellent customer service.
Provide OEM services
One-stop sales team delivers goods quickly
Our promise: Professionalism, Efficiency, Faithful
