Galvanized Sand Wall Defense Barrier, Defense Welded Gabion Mesh Defense Bastion Blast Wall
Defensive Bastion Barriers Wall Details:
Defensive barrier, also known as gabion barrier and defensive bastion, is a new product assembled and sewn from welded gabion mesh and geotextile, which has the ability to resist explosive shock waves and limit the destructive effects of explosions to a certain range. Compared with reinforced concrete explosion-proof walls, it has the advantages of light weight, easy installation, disassembly and recycling.
The Sand Wall Barrier is a kind of modern gabion for fortification and Flood control. It is made of a collapsible wire mesh container and heavy duty fabric liner, it can be used in separate cell or some cells joint together.It can be filled with sand,earth, cement, stones.
Defensive Bastion Barriers units can be used for perimeter protection, border control and temporary accommodation bunkers.
Defensive Bastion Barriers wall is a kind of modern gabion for Military fortification and Flood control. It is made of a collapsible wire mesh container and heavy duty fabric liner, it can be used in separate cell or some cells joint together , and lined with heavy-duty non-woven polypropylene geotextile.
Quick View of Defensive Bastion Barriers :
Material : Low-carbon steel wire
Wire Diameter : 4-5.0mm
Spring Diameter : 4.0-4.5mm
Mesh Hole : 76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm
Panel Size : 2.21× 2.13m, 1.37× 1.06m, 0.61× 0.61m, 1.37× 1.22m
Geotextile : In heavy duty non-woven polypropylene.
Finish : Hot Dipped Galvanized after /before welding, Galfan Coated before welding
Defensive Bastion Barriers Specification
| Model |
Height |
Width |
Length |
Internal Cells |
| KN-1 |
54”(1.37m) |
42”(1.06m) |
32’9”(10m) |
5+4=9 cells |
| KN-2 |
24”(0.61m) |
24”(0.61m) |
4’(1.22m) |
2 cells |
| KN-3 |
39”(1.0m) |
39”(1.0m) |
32’9”(10m) |
5+5=10 cells |
| KN-4 |
39”(1.0m) |
60”(1.52m) |
32’9”(10m) |
5+5=10 cells |
| KN-5 |
24”(0.61m) |
24”(0.61m) |
10’(3.05m) |
5 cells |
| KN-6 |
66”(1.68m) |
24”(0.61m) |
10’(3.05m) |
5 cells |
| KN-7 |
87”(2.21m) |
84”(2.13m) |
91’(27.74m) |
5+4+4=13 cells |
| KN-8 |
54”(1.37m) |
48”(1.22m) |
32’9”(10m) |
5+4=9 cells |
| KN-9 |
39”(1.0m) |
30”(0.76m) |
30’(9.14m) |
6+6=12 cells |
| KN-10 |
87”(2.21m) |
60”(1.52m) |
100’(30.5m) |
5+5+5+5=20 cells |
| KN-11 |
48”(1.22m) |
12”(0.30m) |
4’(1.22m) |
2 cells |
| KN-12 |
84”(2.13m) |
42”(1.06m) |
108’(33m) |
5+5+5+5+5+5=30 cells |
| KN-19 |
108”(2.74m) |
42”(1.06m) |
10’5”(3.18m) |
6 cells |
Defensive Bastion Barriers Application :
1. Military Defense
- Perimeter Security Barrier and Defence Wall
- Temporary Fort and Command Post
- Observation Points and Border Checkpoints
- Military Barrier Fortification System
- Equipment Revetment
- Explosives and Contraband Search Areas
- Guard Posts
- Personnel and Material Bunkers
2. Flood Control
- Flood Prevention Barrier
- Permanent or Semi-permanent Dike
- Flood Control Retaining Wall
- Protection Engineering of Seaside Area
- Protecting Existing Structures
- Coastal Erosion Control
