Heavy Zinc Coated Fabric Lined Gabion basket Use For Defensive Barrier Protection Fortifications and Explosion-Proof Walls
Gabion basket Use For Defensive Barrier , Hesco Bastions was originally mainly used for protection, fortifications, explosion-proof walls, etc. It is made of foldable welded gabion net and ultraviolet protection heavy geotextile lining. The common surface treatment is hot dip galvanizing before welding, welding after galvanizing and Galfan coating. They all have a long service life. It is widely used in Iraq, Afghanistan and Africa.
Defensive barrier specifications:
1. Wire diameter: 4mm 5mm
2. Mesh size: 3x3 inches (7.62*7.62 cm)
3. Panel Size: 13 species
4. Application: used for any security protection and sudden attack
5. Geotextiles: Heavy Non-woven Polypropylene
6. Color: gray, green, sand, etc
7. Surface Treatment: Hot Dip Galvanizing, Galvanizing Wire
8. Packaging: Packaging with shrink film or pallet
The Standard Technical Defensive Barrier Specifications from KN 1 to KN 19
| Welded Military Sand Filled Barrier for Retaining Wall |
| Model |
Height |
Width |
Length |
| KN-1 |
54"(1.37M) |
42"(1.06M) |
32'9"(10M) |
| KN-2 |
24"(0.61M) |
24"(0.61M) |
4'(1.22M) |
| KN-3 |
39"(1.00M) |
39"(1.00M) |
32'9"(10M) |
| KN-4 |
39"(1.00M) |
60"(1.52M) |
32'9"(10M) |
| KN-5 |
24"(0.61M) |
24"(0.61M) |
10'(3.05M) |
| KN-6 |
66"(1.68M_ |
24"(0.61M) |
10'(3.05M) |
| KN-7 |
87"(2.21M) |
84"(2.13M) |
91'(27.74M) |
| KN-8 |
54"(1.37M) |
48"(1.22M) |
32'9"(10M) |
| KN-9 |
39"(1.00M) |
30"(0.76M) |
30'(9.14M) |
| KN-10 |
87"(2.21M) |
60"(1.52M) |
100'(32.50M) |
| KN-11 |
48"(1.22M) |
12"(0.30M) |
4'(1.22M) |
| KN-12 |
84"(2.13M) |
42"(1.06M) |
108'(33M) |
| KN-19 |
108"(2.74M) |
42"(1.06M) |
10'5"(3.18M) |
Defensive barrier characteristics:
Easy to handle and install
High strength and impact resistance
Long service life and normal use
Can be filled with sand, cement, stone, soil.
Application of Defensive Barrier:
Peripheral security and defense wall
Equipment protection
Shelter for personnel and materials
Observation point
Defensive firing position sentry
Explosive and contraband search area
Highway inspection station
Border crossing checkpoint
Protect existing structures
Flood control retaining wall beach erosion
Coastal Area Protection Project
Advantages of Defensive Barrier:
1. Removable
It is assembled by panels and spring wires, and can be folded into a whole during loading and transportation.
2. Anticorrosion
The raw material is hot-dip galvanized wire, which can be used for 10 years or more and is suitable for external protection.
3. Easy installation
When you get it, open it in a spacious place and fill it with sand and mud. Even 2-3 people can finish it.
4. Rapid displacement
When you want to use it in another place, just move it and it can be used many times.
5. Easy to repair
If a part is damaged, throw it away and connect it with a new one.
