Blast Wall Against Small-Arms Fire Hesco Barrier Flood Protection Defensive Security ABS Barrier

Basic Properties
Place of Origin: HB
Brand Name: SHUXIN
Certification: CE, ISO, SGS, SASO, PVOC,COC, FM A, FM E
Model Number: SX 1 to SX 19
Trading Properties
Minimum Order Quantity: 100 UNITS
Price: Negotiated
Standard Packaging: Pallet
Delivery Time: 15 working days
Payment Terms: L/C, T/T, Western Union, ,Paypal, T/A
Supply Ability: 50 Units per week
Product Summary
Blast Wall Against Small-Arms Fire Hesco Barrier Flood Protection Defensive Security ABS Barrier The Application for Welded Defensive Barriers: The Defensive barriers, is a modern gabion primarily used for flood control and military fortifications. It is made of a collapsible wire mesh container and ...

Product Details

Highlight:

Flood Protection Defensive Security Barrier

,

ABS Defensive Security Barrier

,

ABS Barrier Hesco Barrier

Material: Q195
Mesh Hole: 3"
Mesh Diameter: 4.0 Mm
Parts: Mesh Panel, Spring, Geotextile Lined
Geotextile Weight: 200g-400g
T / S: 500 - 800 MPA
Product Description

Blast Wall Against Small-Arms Fire Hesco Barrier Flood Protection Defensive Security ABS Barrier



The Application for Welded Defensive Barriers:



The Defensive barriers, is a modern gabion primarily used for flood control and military fortifications. It is made of a collapsible wire mesh container and heavy duty fabric liner, and used as blast wall against small-arms fire and/or explosives.



Blast Wall Against Small-Arms Fire Hesco Barrier Flood Protection Defensive Security ABS Barrier



Brief Introduction of Hesco barrier Flood Protection Defensive security ABS Barrier



1. Wire Diameter: 4.00mm

2. Mesh Size: 3" (76.2x76.2mm), Sometimes according to Panel size to adjust the Hole size.

3. Panel Size: 0.61x0.61M

4. Diameter of Spring: 4.0mm, which is used for connecting the panels,

5. Geotextile:heavy duty UV non-woven polypropylene;

6. Color: Grey and Military Green,Sand color etc.

7. Total Size: 0.61x0.61x1.22M

8. No. of Cells: 2 Cells

9. Finish: Hot dipped galvanized

10. Package: Packed in pallet, with Plastic Film or Shrink Film



The Technical Specifications from SX 1 to SX 19



Welded Military Defensive Barrier
Model Height Width Length
SX-1 54"(1.37M) 42"(1.06M) 32'9"(10M)
SX-2 24"(0.61M) 24"(0.61M) 4'(1.22M)
SX-3 39"(1.00M) 39"(1.00M) 32'9"(10M)
SX-4 39"(1.00M) 60"(1.52M) 32'9"(10M)
SX-5 24"(0.61M) 24"(0.61M) 10'(3.05M)
SX-6 66"(1.68M_ 24"(0.61M) 10'(3.05M)
SX-7 87"(2.21M) 84"(2.13M) 91'(27.74M)
SX-8 54"(1.37M) 48"(1.22M) 32'9"(10M)
SX-9 39"(1.00M) 30"(0.76M) 30'(9.14M)
SX-10 87"(2.21M) 60"(1.52M) 100'(32.50M)
SX-11 48"(1.22M) 12"(0.30M) 4'(1.22M)
SX-12 84"(2.13M) 42"(1.06M) 108'(33M)
SX-19 108"(2.74M) 42"(1.06M) 10'5"(3.18M)



Blast Wall Against Small-Arms Fire Hesco Barrier Flood Protection Defensive Security ABS Barrier



operational principle



Used Spring to connect the mesh panel together into a rectangle container, which have many cells or single cell, Fill with sand,earth,cement, stone etc as a wall for protection fence.

Blast Wall Against Small-Arms Fire Hesco Barrier Flood Protection Defensive Security ABS Barrier

Flood Control



1. Flood Prevention Barrier

2. Permanent or Semi-permanent Dike

3. Flood Control Retaining Wall

4. Protection Engineering of Seaside Area

5. Protecting Existing Structures

6. Coastal Erosion Control



The Advantages of Hesco barrier Flood Protection Defensive security ABS Barrier:



1. Lifetime

    The unit must be made of a Wire Mesh basket which is manufactured from Galvanised coated, welded mesh. The mesh must be made of rust protected alloy materials.The Wire Mesh must have a guaranteed life of not less than 5 years while exposed to environment and 10 years when in store.



2. Collapsible

    Mesh Panel is joint by spring which is a circle, Mesh Panle can turn 360° unobstructed, so, when shiping the goods, it is collapsible to save space.





3. Quick Displacement

    When you want to use it in another place,Just to move it, It can use many times



4. Easy to repair

    As a protection Wall to prevent Bullets and shells, there would be small part damage, Just use one piece of welded wire mesh panel insert into the earth and cover the damage part, it can also work long time.



Blast Wall Against Small-Arms Fire Hesco Barrier Flood Protection Defensive Security ABS Barrier
