Hesco Mil 10 Non Woven Geotextile Fabric Perimeter Fence Weld Mesh Gabion defensive barrier

Large Image : Hesco Mil 10 Non Woven Geotextile Fabric Perimeter Fence Weld Mesh Gabion defensive barrier

Product Details:

Place of Origin:	CHINA
Brand Name:	KESCO
Certification:	ISO CE SGS COC
Model Number:	mil 10

Payment & Shipping Terms:

Minimum Order Quantity:	10 unit
Price:	Negotiated
Packaging Details:	pallet and plastic film outside
Delivery Time:	15 working days
Payment Terms:	Western Union, MoneyGram, T/T, L/C
Supply Ability:	100 units per week

Contact Now

Detailed Product Description

Material:	Zinc-5% Aluminum Alloy Wire	Mesh Wire:	5.0 Mm
Spring Wire:	5.0 Mm	Standard:	ASTM B750 ASTM A856
Geotextile:	Non-woven Polypropylene Geotextile Fabric	Geotextile Color:	Beige, Green, Tan,
Component:	Mesh Panel , Spiral Wire Hinges, Connect Pins	Application:	Flood Control , Militay Defence , Hotel Protection
Highlight:	Non Woven Geotextile Fabric Barrier , Perimeter Fence Weld Mesh Gabion , Hesco Mil 10 Defensive Barrier

Hesco Mil 10 Non Woven Geotextile Fabric Perimeter Fence Weld Mesh Gabion defensive barrier

Our High-Security Defensive Barrier is an engineered perimeter protection system designed to provide reliable, certified protection against vehicle-borne threats and forced intrusion. Constructed from the highest grade materials, it is the premier choice for securing critical infrastructure, government facilities, and public spaces.

Hesco Mil 10 Non Woven Geotextile Fabric Perimeter Fence Weld Mesh Gabion defensive barrier 0
welded gabion box also named as sand cage, defensive barrier , wire mesh gabion box, stone cage.

--- Material have galvanized , galfan coated wire
--- Experienced factory in manufacturing .
--- U.S Military approved quality .
--- Short shipping time.

Parameter	Description
Primary Material	High-Yield Steel (Hot-Dip Galvanized), Reinforced Concrete, Stainless Steel Components
Crash Rating	PAS 68 (e.g., V/7500/N2/80/90:0/25), ASTM F2656-07 (M30, M40, M50, K4/L3), IWA 14-1
Installation Type	Fixed (Shallow Foundation), Semi-Fixed, or Fully Portable
Surface Treatment	Hot-Dip Galvanized (Standard), Powder Coating (Custom RAL Colors)
Operational Modes	Manual, Electro-Hydraulic, Solar-Powered
Customization	Custom heights, lengths, and finishes available

Common Types & Models

Fixed Bollard Systems:
- Description: Retractable or static posts providing discreet yet powerful vehicle access control at entry points.
- Image: https://via.placeholder.com/200x200?text=Fixed+Bollards
Road Blockers & Crash Beams:
- Description: Heavy-duty barriers designed to stop high-speed, high-mass vehicle attacks. Ideal for main gatehouses.
- Image: https://via.placeholder.com/200x200?text=Road+Blocker
Shallow Foundation Barriers:
- Description: Offers high-level protection with minimal groundworks, reducing installation time and cost.
- Image: https://via.placeholder.com/200x200?text=Shallow+Foundation
Portable/Scissor Barriers:
- Description: Mobile, rapidly deployable barriers for temporary traffic control, event security, and emergency perimeters.
- Image: https://via.placeholder.com/200x200?text=Portable+Barrier

Applications

Government & Military Buildings: Embassies, ministries, military bases.
Critical Infrastructure: Power plants, water treatment facilities, telecommunications hubs.
**Commercial & Public Spaces

Weld Mesh Gabion Used

1: Flood control and military fortifications .

2: Temporary to semi-permanent levee or blast wall against explosions or small-arms . It has seen considerable use in many countries .

3: Suitable for filling with earth ,sand,gravel,crushed rock and other granular materials.

Mil 10 Weld Mesh Gabion Specification:

Material : All wires conform to BS EN10218-2012,

Zinc-Alunminum coating are to BS EN 10244-2:2009

Geotextile: heavy duty geotextile, non-woven,permeable,

polypropulene farbric

Geotextile color: beige or green color

Mesh Hole: 3” X 3”

Unit Size : 2.21m x 1.52m x 30.5m

Cells: 1 unit = 5 cells+5cells+5cells+5cells = 20 cells

Item No.

Height

Width

Length

all dimensions and weight are nominal ,Diagrams and products are for illustrative purpose only.

SX10 (Mil 10)

7’3”

(2.21m)

5’

(1.52m)

100’

(30.5m)

Weld Mesh Gabion technology :

Hesco Mil 10 Non Woven Geotextile Fabric Perimeter Fence Weld Mesh Gabion defensive barrier 2

Hesco Mil 10 Non Woven Geotextile Fabric Perimeter Fence Weld Mesh Gabion defensive barrier 3

Hesco Mil 10 Non Woven Geotextile Fabric Perimeter Fence Weld Mesh Gabion defensive barrier 4
