Military Green Welded Gabion Defensive Barrier Box
Multi-Function Defensive Barrier for Shooting Range
CE / ISO 9000 Certified protective solution for military and peacekeeping installations
Defensive barriers—also known as sand barriers, military barriers, or military fencing systems—provide efficient, cost-effective protection for personnel, vehicles, structures, and equipment. Recognized as the most significant innovation in field fortifications since World War II, these barriers offer substantial advantages in deployment speed and labor efficiency.
A 10-meter-long barrier wall can be assembled in approximately 20 minutes using just two workers and one front loader. In comparison, constructing an equivalent wall with sandbags requires three times the filling materials, eight workers, and over eight hours of construction time.
Constructed from welded wire mesh and heavy-duty non-woven polypropylene geotextile, these defensive barriers form robust, durable structures. Available in both standard and reusable configurations to meet diverse operational requirements for military perimeter protection.
Operational Principle
Spring-connected mesh panels form rectangular containers with multiple or single cells. Fill with sand, earth, cement, stone, or other materials to create protective walls and fencing systems.
Technical Specifications
- Wire Diameter: 4-5mm
- Mesh Size: 3" (75x75mm, 50x50mm, 80x80mm)
- Panel Size: 13 standard sizes for comprehensive security protection
- Geotextile: Heavy-duty non-woven polypropylene
- Color Options: Grey, Military Green, Sand color
- Finish: Hot-dipped galvanized, Galfan wire
- Packing: Palletized for secure transport
Product Dimensions
| Product |
Height |
Width |
Length |
| MIL1 5442 R | 54" (1.37M) | 42" (1.06M) | 32'9" (10M) |
| MIL2 2424 R | 24" (0.61M) | 24" (0.61M) | 4' (1.22M) |
| MIL3 3939 R | 39" (1.00M) | 39" (1.00M) | 32'9" (10M) |
| MIL4 3960 R | 39" (1.00M) | 60" (1.52M) | 32'9" (10M) |
| MIL5 2424 R | 24" (0.61M) | 24" (0.61M) | 10' (3.05M) |
| MIL6 6624 R | 66" (1.68M) | 24" (0.61M) | 10' (3.05M) |
| MIL7 8784 R | 87" (2.21M) | 84" (2.13M) | 91' (27.74M) |
| MIL8 5448 R | 54" (1.37M) | 48" (1.22M) | 32'9" (10M) |
| MIL9 3930 R | 39" (1.00M) | 30" (0.76M) | 30" (9.14M) |
| MIL10 8760 R | 87" (2.21M) | 60" (1.52M) | 100' (32.50M) |
| MIL11 4812 R | 48" (1.22M) | 12" (0.30M) | 4' (1.22M) |
| MIL12 8442 R | 84" (2.13M) | 42" (1.06M) | 108' (33M) |
Applications
Flood Control
Increasingly popular for coastal regions and flood-prone areas, welded defensive barriers provide effective flood protection solutions for countries near coastlines.
Protection Walls
Ideal for residential and commercial protection walls, offering lightweight construction with fast, easy operation for rapid wall assembly.
Key Advantages
Easy Installation
Simply position in desired location, unfold, and fill with sand or earth. Installation can be completed by just 2-3 personnel.
Anti-Corrosion
Manufactured from hot-dipped galvanized wire for exceptional durability, providing 10+ years of reliable outdoor protection performance.
