Modern Rapidly Deployable Gabion Defensive Barrier with Galvanized Wire for Explosion-Proof Military Fortification
Basic Properties
Place of Origin:
CN-HB
Brand Name:
KN/DEFENSIVE BARRIER
Certification:
CE, ISO, SGS, SASO, PVOC,COC, FM A, FM E
Model Number:
SX-1 to SX-19
Trading Properties
Minimum Order Quantity:
100 UNITS
Price:
Negotiated
Standard Packaging:
Pallet
Delivery Time:
15 working days
Payment Terms:
L/C,T/T,Western Union,,Paypal,T/A
Supply Ability:
500 Units per week
Product Summary
Modern Rapidly Deployable Gabion Defensive Barrier System The Modern Rapidly Deployable Gabion Defensive Barrier System is a highly efficient, cost-effective protective structure designed for military fortifications, peacekeeping operations, and flood control applications. Recognized as a major ...
Product Details
Highlight:
Rapidly Deployable Gabion Defensive Barrier
,Galvanized Wire Hesco Barrier
,Explosion-Proof Military Defensive Barrier
Features:
Strong, Anti-Rust
Material:
Galvanized Wire, Q195, Low Carbion Steel Wire
Type:
MIL1 - MIL19
Diameter Of Mesh:
4.0mm, 5.0mm
Mesh Hole:
3", 8*8cm, 10*10cm
Color:
Beige Or Military Green
Geotextile Weight:
250 G/㎡, 220g, 300g, 350g
Usage:
Defensive Sand Wall Barrier Bastion
Yeas Of Experience:
15 Years
Sample:
Free
Product Description
Modern Rapidly Deployable Gabion Defensive Barrier System
The Modern Rapidly Deployable Gabion Defensive Barrier System is a highly efficient, cost-effective protective structure designed for military fortifications, peacekeeping operations, and flood control applications. Recognized as a major advancement in field fortification technology, this system offers exceptional deployment speed—a 10-meter barrier wall can be erected in approximately 20 minutes with just two workers and one front loader, significantly outperforming traditional sandbag construction in both time and labor efficiency.
Constructed from high-strength welded wire mesh and non-woven polypropylene geotextile, the barrier provides reliable protection for personnel, vehicles, structures, and equipment. Available in standard and reusable designs to suit diverse operational scenarios, this system combines robust performance, quick installation, and strong adaptability for military defense, emergency flood control, and temporary perimeter protection.
Technical Specifications
| Item | Specification Parameters | Implementation Standard |
|---|---|---|
| Model | ML10 (Mil 10) | Military-Grade Defensive Barrier Standard |
| Overall Dimensions | 2.21m×1.53m×30.5m (H × W × L) | BS EN 10218-2012 |
| Number of Cells | 20 groups (5+5+5+5 cells) | Modular Design Specification |
| Steel Wire Diameter | Mesh surface: 4 or 5 mm; Spiral fixing wire: 4mm | High-Carbon Steel Wire Mechanical Standard |
| Anti-Corrosion Treatment | Hot-dip galvanizing + zinc-aluminum alloy coating | BS EN 10244-2:2009 |
| Geotextile Specifications | 250g or 300g, 350g geotextile cloth, beige/green | ISO 9001 Certification |
| Explosion-Proof Grade | Resists 14.5mm armor-piercing projectiles and TNT-equivalent explosions | Military Standard Explosion-Proof Test Standard |
| Installation Efficiency | Single unit ≤ 30 minutes (operated by 2-3 people) | On-Site Deployment Operation Specification |
Military Applications
- Perimeter Security and Defence Walls
- Equipment Revetments
- Personnel and Material Bunkers
- Observation Points
- Defensive Firing Positions
- Guard Posts
- Explosives and Contraband Search Areas
- Highway Checkpoints
- Border Crossing Checkpoints
- Protecting Existing Structures
- Flood Control Retaining Wall
- Protection Engineering of Seaside Area
Key Features
- Pre-fabricated gabion of galvanized welded mesh fitted with UV-protecting polypropylene geotextile liner
- Filling material is an easily obtained mix of sand and small stones
- Can be connected to any length and stacked for additional height
Standard Specifications
- Wire Diameter: 4-5mm
- Mesh Size: 3" (75x75mm, 50x50mm) 80x80mm
- Panel Size: 13 type sizes for any security protection and sudden burst attacks
- Geotextile: Heavy duty non-woven polypropylene, weight from 220g - 350g
- Color: Grey, Military Green, Sand color etc.
- Finish: Hot dipped galvanized, Galfan wire
- Packing: Packed in pallet
- Accessories: Joint Pin and Spiral Wire
Product Specification List
| PRODUCT | HEIGHT | WIDTH | LENGTH |
|---|---|---|---|
| MIL1 5442 R | 54''(1.37M) | 42''(1.06M) | 32'9''(10M) |
| MIL2 2424 R | 24'' (0.61M) | 24''(0.61M) | 4'(1.22M) |
| MIL3 3939 R | 39''(1.00M) | 39''(1.00M) | 32'.9''(10M) |
| MIL4 3960 R | 39''(1.00M) | 60''(1.52M) | 32'.9''(10M) |
| MIL5 2424 R | 24''(0.61M) | 24''(0.61M) | 10'(3.05M) |
| MIL6 6624 R | 66''(1.68M) | 24''(0.61M) | 10'(3.05M) |
| MIL7 8784 R | 87''(2.21M) | 84''(2.13M) | 91'(27.74M) |
| MIL8 5448 R | 54''(1.37M) | 48''(1.22M) | 32'.9''(10M) |
| MIL9 3930 R | 39''(1.00M) | 30''(0.76M) | 30''(9.14M) |
| MIL10 8760 R | 87''(2.21M) | 60''(1.52M) | 100'(32.50M) |
| MIL11 4812 R | 48''(1.22M) | 12''(0.30M) | 4'(1.22M) |
| MIL12 8442 R | 84''(2.13M) | 42''(1.06M) | 108'(33M) |
Product Detail Showcase
Connection System
The defensive barrier is connected with spiral wire, allowing the gabion mesh box to be folded up for easy loading and transportation. When deployed, it can be quickly shaped, filled with soil or stones, and put into application. The springs are all made of high strength steel wire, greatly improving the sturdiness of the defensive barrier.
Primary Applications
Flood Control
The Military Defensive Barrier is increasingly popular for flood protection applications. Countries near coastlines frequently choose this system for effective flood control measures.
Protection Wall
More users are employing Welded Defensive Barriers as protection walls for residential security. The lightweight design and easy operation enable rapid wall construction.
Key Advantages
Easy Installation
Simply position the barrier in the desired location, open it, and fill with sand and earth. Installation can be completed by just 2-3 people.
Anti-Corrosion
Made from Hot Dipped Galvanized Wire, the barrier can withstand outdoor conditions for 10+ years, making it ideal for external protection applications.
Quality Assurance
