MIL1 1.37m High Welded Gabion Hesco Barrier for Property Protection Retaining Wall
There are many models of Defensive Barrier, from MIL1 to MIL 19, each model with different width, length and height. From 0.61m to 2.74m. it can meet different needs.
Many military fortifications prefer to combine different specifications for enhanced protection. For example, the MIL10 can be used as the base, with MIL3 stacked on top to create perimeter walls over 3 meters high. Installing a layer of razor wire at the top turns the structure into an extremely difficult-to-breach defensive barrier.
In addition, MIL7 and MIL2 are widely used to build temporary military command posts, observation towers, field ammunition depots, personnel shelters, and quick-deployment defensive positions.
These versatile structures are also extensively applied in flood control, emergency disaster relief, temporary retaining walls, sandbag barriers, property protection, border security, industrial site safety isolation, and high-security perimeter protection for factories, warehouses, power stations, and residential compounds. Their quick assembly, easy transportation, and wide availability of filling materials make them ideal for both military and civilian scenarios.
Source Factory
Hebei KN Wire Mesh can supply different type of desing for you reference, we had been dedicated to the production and improvement of blast walls for more than 10 years. Our monthly output has grown from 2 x 40ft containers to 20 x 40ft containers, with significant improvements in production efficiency and cost control.
We exercise strict quality control over our products. Special personnel are responsible for inspecting raw materials upon arrival and testing the welding firmness of mesh panels. We help customers eliminate potential engineering safety hazards and achieve faster project payment recovery.
- City Protection: During the 2019 Watertown, South Dakota floods, Hesco barriers were deployed to safeguard the city from rising waters
- Mobile Home Parks: In Iowa City, a mile-long Hesco flood wall was installed to protect Cole and Thatcher Mobile Home Parks
- Airport Security: Bangkok's Don Mueang Airport used Hesco barriers during severe flooding, erected by the Royal Thai Army
- Urban Infrastructure: Many cities use them to protect utilities, subway entrances, and critical infrastructure during flash floods
- Waterfront Homes: Protect properties from shoreline erosion, reducing soil loss by up to 90%
- Riverbanks: Tested effective on 35° inclines, stabilizing slopes prone to washing away
- Marsh & Beach Protection: The original design purpose (created by British ex-miner Jimi Heselden) was for coastal erosion control
- Lakeside Development: Used to prevent shoreline collapse in residential areas along lakeshores
- Worksite Perimeters: Create secure fencing around construction sites that resists wind and falling debris
- Sound Barriers: Instant noise reduction walls along residential construction zones
- Traffic Management: Temporary barriers for highway construction, directing vehicles safely around work zones
- Industrial Safety: Separate hazardous zones in manufacturing plants while containing pollutants
- Warehouse Protection: Defend storage facilities from flood damage during rainy seasons
| Attribute |
Value |
| Raw Material |
Hot dipped galvanized wire |
| Geotextile |
250 - 300 g/㎡ Standard |
| Mesh Diameter |
4.0 / 5.0mm Diameter |
| Aperture |
3" (76.2mm×76.2mm) |
| Color |
Military Green, sand color |
| Accessories |
Staple, Joint Pin |
| Brand |
KESCO, not HESCO |
| Sample |
Free sample available |
| Stock |
Some types in stock - welcome to inquire |
The Hesco Barrier Guard Tower is constructed from galvanized welded boxes, combining rectangular mesh wire with canvas-draped panels to create versatile base defense structures. These units serve as essential building blocks for military and police security installations.
Designed for rapid deployment, these barriers can be installed by just 2-3 personnel, making them ideal for creating shelters or guard towers quickly in field conditions.
Standard Technical Specifications (KN1 to KN19)
| Model |
Height |
Width |
Length |
| KN-1 |
54" (1.37M) |
42" (1.06M) |
32'9" (10M) |
| KN-2 |
24" (0.61M) |
24" (0.61M) |
4' (1.22M) |
| NK-3 |
39" (1.00M) |
39" (1.00M) |
32'9" (10M) |
| KN-4 |
39" (1.00M) |
60" (1.52M) |
32'9" (10M) |
| KN-5 |
24" (0.61M) |
24" (0.61M) |
10' (3.05M) |
| KN-6 |
66" (1.68M) |
24" (0.61M) |
10' (3.05M) |
| KN-7 |
87" (2.21M) |
84" (2.13M) |
91' (27.74M) |
| KN-8 |
54" (1.37M) |
48" (1.22M) |
32'9" (10M) |
| KN-9 |
39" (1.00M) |
30" (0.76M) |
30' (9.14M) |
| KN-10 |
87" (2.21M) |
60" (1.52M) |
100' (32.50M) |
| KN-11 |
48" (1.22M) |
12" (0.30M) |
4' (1.22M) |
| KN-12 |
84" (2.13M) |
42" (1.06M) |
108' (33M) |
| KN-19 |
108" (2.74M) |
42" (1.06M) |
10'5" (3.18M) |
Primary Applications of Welded Gabion Barrier
Key Advantages of Welded Defensive Barriers
1. Extended Lifetime:
Constructed from galvanized, rust-protected alloy wire mesh with a guaranteed minimum lifespan of 5 years in exposed environments and 10 years when stored properly.
2. Collapsible Design:
Mesh panels connected by spring joints allow 360° rotation, enabling compact storage and transportation while maintaining structural integrity.
3. Superior Protection:
Combination of heavy-duty mesh panels with thick geotextile fabric creates exceptionally strong protective barriers for various applications.
