Defensive Barrier Welded Mesh Wall For River Flood Protection And Flood Control

Large Image : Defensive Barrier Welded Mesh Wall For River Flood Protection And Flood Control

Product Details:

Place of Origin:	CN
Brand Name:	SHUXIN
Certification:	ISO:9001
Model Number:	SX-Hesco Barrier

Payment & Shipping Terms:

Minimum Order Quantity:	300 pcs
Price:	Negotiated
Packaging Details:	Plastic and then Pallet
Delivery Time:	10 working days
Payment Terms:	L/C, T/T, Western Union,Paypal
Supply Ability:	100 pcs per day

Contact Now

Detailed Product Description

Mesh Size:	75×75mm, 100×100mm	Surface Treatment:	Hot Dipped Galvanized
Wire:	5mm	Geotextile:	Sand Color 300gsm
Stock:	1000 Pcs	Package:	Plastic And Then Pallet
Filling Material:	Sand, Soil, Gravel	Spring Wire:	5mm
Highlight:	Welded Mesh Wall Defensive Barrier , River Flood Protection Defensive Barrier , Flood Control Defensive Barrier

Protection Wall Anti Blast Wall Welded Wire Mesh Hesco Barrier Wall

Defensive Barrier Welded Mesh Wall is a modular flood defense system made of high-strength welded steel mesh, designed for rapid deployment along riverbanks, flood-prone areas, and emergency flood control lines. It can be filled with sand, gravel, or concrete to form a stable, water-resistant barrier.

Defensive Barrier Welded Mesh Wall For River Flood Protection And Flood Control

Technical Specifications

Item	Specification
Material	Low carbon steel wire, hot-dip galvanized
Wire Diameter	3.0mm – 5.0mm
Mesh Size	50×50mm, 75×75mm, 100×100mm
Panel Size	1m×1m, 1.5m×1m, 2m×1m (customizable)
Surface Treatment	Hot-dip galvanized / PVC coated
Filling Material	Sand, gravel, concrete
Application	River flood, flood control, emergency barrier

Quick Details

Unit Type	Height (M)	Width (M)	Length (M)	Internal Cells
SX-mil1	1.37	1.06	10	9
SX-mil2	0.61	0.61	1.22	2
SX-mil3	1.0	1.0	10	10
SX-mil4	1.0	1.52	10	6
SX-mil5	0.61	0.61	3.05	5
SX-mil6	1.68	0.61	3.05	5
SX-mil7	2.21	2.13	27.74	4
SX-mil8	1.37	1.22	10	9
SX-mil9	1.0	0.76	9.14	9
SX-mil10	2.21	1.52	30.5	5

Defensive Barrier Welded Mesh Wall For River Flood Protection And Flood Control

Detail Specification

1. Wire diameter: 4-5mm

2. Mesh size: 3" (75x75mm,50x50mm)

3. Panel size: 12 type size for any security protection,suddenly burst attacks

4. Geotextile: in heavy duty non-woven polypropylene;

5. Color: Grey and Military Green,Sand color etc.

6. Finish: hot dipped galvanized, Galfan wire.

7. Packing: wrapped with shrink film or packed in pallet

Defensive Barrier Welded Mesh Wall For River Flood Protection And Flood Control

Application Scenarios

Riverbank flood protection
Emergency flood control
Coastal defense
Temporary water diversion
Disaster relief

Defensive Barrier Welded Mesh Wall For River Flood Protection And Flood Control

Packing & Delivery

Panels packed on pallet, wrapped with shrink film
Accessories in carton or woven bag
OEM / ODM available

Defensive Barrier Welded Mesh Wall For River Flood Protection And Flood Control
