High Duration Military Barrier Gabion Stone Fence With Geotextile

High Duration Military Barrier Gabion Stone Fence With Geotextile
High Duration Military Barrier Gabion Stone Fence With Geotextile High Duration Military Barrier Gabion Stone Fence With Geotextile High Duration Military Barrier Gabion Stone Fence With Geotextile

Large Image :  High Duration Military Barrier Gabion Stone Fence With Geotextile

Product Details:
Place of Origin: CN
Brand Name: KESCO
Certification: ISO CE SGS COC
Model Number: SX Series
Payment & Shipping Terms:
Minimum Order Quantity: 10 units
Price: Negotiated
Packaging Details: Wooden Pallet
Delivery Time: 15 business days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 150 units per week

High Duration Military Barrier Gabion Stone Fence With Geotextile

Description
Material: Q195, Low Carbon Steel Wire Mesh Wire: 5.0mm
Spring Wire: 4.0mm Geotextile: 300 GSM Heavy Geotextile
Surface Treatment: Hot Dipped Galvanized Life Duration: Around 25 Years
High Light:

hesco defensive barriers

,

hesco bastion

China KESCO Barrier, not HESCO Price / Gabion Stone Fence with Geotextile

Material: Hot-dipped galvanized wire, galfan wire(zinc-aluminum wire)


Welded Gabion military sand wall barrier with Geotextile is also named as Welded bastion, Welded defense wall, Welded Barrier,Sand Cage, Welded Gabion box, etc. It is a prefabricated, multi-cellular system, made of Galvanized welded mesh and lined with non-woven geotextile. Units can be extended and joined using the provided joining pins. It is easy installed with using minimal manpower and commonly available equipment, so it is widely used for military fortification and flood control.


The hesco barrier concertainer unit is a multi-cellular wall system manufactured from welded Zinc-Aluminum coated /hot dipped galvanized steel wire mesh and joined with vertical,helical coil joints.


The concertainer MIL units are lined with either beige or green colored heavy-duty non-woven polypropylene geotextile.Hesco barrier /hesco bastion can be filled with sand, earth, cement,stone, then as a defence wall or bunker and widely used in the military to protect safety.

High Duration Military Barrier Gabion Stone Fence With Geotextile 0

Material: Galvanized steel wire or Galfan/

zinc-5%aluminum wire

Service Life: 15-20 years

Price:19.8$-99.8$/set

Wire diameter: 3.0mm- 6.0mm

Aperture:50*50mm 75*75mm, 76.2*76.2mm 80*80mm 100*100mm etc

Color of geotextile:Grey and Military, Green,Sand color etc

Gram Weight of geotextile:200g/m2 or 300g/m2

Finish:hot dipped galvanized,Galfan wire.

Welded method:welded after galvanized or galvanized after welded

Packing:Wrapped with shrink film then packed in wood pallet or iron pallet



Model Height Width Length Internal Cells
SX-1(Mil 1) 54”(1.37m) 42”(1.06m) 32’9”(10m) 5+4=9 cells
SX-2(Mil 2) 24”(0.61m) 24”(0.61m) 4’(1.22m) 2 cells
SX-3(Mil 3) 39”(1.0m) 39”(1.0m) 32’9”(10m) 5+5=10 cells
SX-4(Mil 4) 39”(1.0m) 60”(1.52m) 32’9”(10m) 5+5=10 cells
SX-5(Mil 5) 24”(0.61m) 24”(0.61m) 10’(3.05m) 5 cells
SX-6(Mil 6) 66”(1.68m) 24”(0.61m) 10’(3.05m) 5 cells
SX-7(Mil 7) 87”(2.21m) 84”(2.13m) 91’(27.74m) 5+4+4=13 cells
SX-8(Mil 8) 54”(1.37m) 48”(1.22m) 32’9”(10m) 5+4=9 cells
SX-9(Mil 9) 39”(1.0m) 30”(0.76m) 30’(9.14m) 6+6=12 cells
SX-10(Mil 10) 87”(2.21m) 60”(1.52m) 100’(30.5m) 5+5+5+5=20 cells
SX-11(Mil 11) 48”(1.22m) 12”(0.30m) 4’(1.22m) 2 cells
SX-12(Mil 12) 84”(2.13m) 42”(1.06m) 108’(33m) 5+5+5+5+5+5=30 cells
SX-19(Mil 19) 108”(2.74m) 42”(1.06m) 10’5”(3.18m) 6 cells



High Duration Military Barrier Gabion Stone Fence With Geotextile 1

Defensive Barrier Application :



1. landscaping, as retaining walls, landscape urban landscape and parks.
2. or high salt pollution in the environment, Gore can be used where welded wire mesh technology.
3. within the welded wire mesh filled with stone or natural cobblestone highway together protection, slope, roadway, bridge and so on.
4. welded wire mesh is widely used in earth or soil reinforcement such as desertification, slope protection, river, coastal protection, reservoirs, canals and pipelines renovation, Rock failure protection, bridge protection, protective net.

High Duration Military Barrier Gabion Stone Fence With Geotextile 2
